Bo Mạch Chủ – Mainboard MSI MEG Z490 GODLIKE

CPU

Hỗ trợ Bộ xử lý Intel Core, Pentium Gold và Celeron thế hệ thứ 12, 13.

Socket bộ xử lý LGA1700

Chipset

Intel B760

Đồ họa

1x HDMI™

Support HDMI™ 1.4 with HDR, maximum resolution of 4K 30Hz*

1x VGA

Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz

* Chỉ khả dụng trên bộ xử lý có đồ họa tích hợp. Thông số kỹ thuật đồ họa có thể khác nhau tùy thuộc vào CPU được cài đặt.

RAM

2x DDR5, Maximum Memory Capacity 96GB

Memory Support DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC)

Max. overclocking frequency:

• 1DPC 1R Max speed up to 6400+ MHz

• 1DPC 2R Max speed up to 5600+ MHz

Khe mở rộng

1x PCI-E x16 slot

1x PCI-E x1 slot

PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)

PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)

Lưu trữ

1x M.2

M.2_1 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices

4x SATA 6G

* SATA5 will be unavailable when installing M.2 SATA SSD in the M2_1 slot

LAN

Realtek® RTL8111H Gigabit LAN

USB

4x USB 2.0 (Rear)

4x USB 2.0 (Front)

2x USB 3.2 Gen1 Type A (Rear)

2x USB 3.2 Gen1 Type A (Front)

Audio

Realtek® ALC897 Codec

7.1-Channel High Definition Audio

Kết nối nội bộ

1x Power Connector(ATX_PWR)

1x Power Connector(CPU_PWR)

1x CPU Fan

2x System Fan

2x Front Panel (JFP)

1x Chassis Intrusion (JCI)

1x Front Audio (JAUD)

1x Com Port (JCOM)

1x RGB LED connector(JRGB)

1x TPM pin header(Support TPM 2.0)

4x USB 2.0 ports

2x USB 3.2 Gen1 Type A ports

Cổng kết nối phía sau

1. HDMI™

2. VGA

3. Keyboard / Mouse

4. USB 3.2 Gen 1 5Gbps (Type-A)

5. LAN port

6. Audio Connectors

7. USB 2.0

8. USB 2.0

Kích thước

mATX

200mmx236.16mm

Hệ điều hành

Hỗ trợ cho Windows® 11 64-bit, Windows® 10 64-bit

Sản phẩm

Bo mạch chủ

Tên Hãng

MSI

Model

CPU hỗ trợ

Intel

Chipset

INTEL B760

RAM hỗ trợ

2x DDR5, Maximum Memory Capacity 96GB
Memory Support 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
• 1DPC 1R Max speed up to 7200+ MHz
• 1DPC 2R Max speed up to 6600+ MHz

Khe cắm mở rộng

1x PCI-E x16 slot
PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)

Ổ cứng hỗ trợ

2x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280 devices
4x SATA 6G

Cổng kết nối (Internal)

1x Power Connector(ATX_PWR)
1x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
1x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
2x USB 2.0 ports
2x USB 3.2 Gen1 Type A ports
1x USB 3.2 Gen2 Type C ports

BACK PANEL

1. USB 3.2 Gen 1 5Gbps
2. Display Port
3. USB 3.2 Gen 2 10Gbps
4. 2.5G LAN
5. Audio Connectors
6. HDMI™
7. USB 3.2 Gen 2 10Gbps (Type-C)
8. USB 2.0
9. Wi-Fi / Bluetooth

LAN / Wireless

Realtek^® RTL8125BG 2.5Gbps LAN

Intel^® Wi-Fi 6E
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax

Supports Bluetooth^® 5.3, FIPS, FISMA

Kích cỡ

Mini-ITX
170mmx170mm
