Mainboard NZXT N7 Z590 Matte White (Intel)

CPU

• AMD Socket AM5 Ryzen™ 7000 Series Processors:Supported

CHIPSET

• AMD:B650

MEMORY

• DIMM Slots:4, DDR5 only

• Max Memory Support:128GB

• Memory Architecture:Dual-Channel

• OC Frequency:DDR5 Non-ECC, Un-buffered Memory up to 6000+ (OC). Please refer to Memory QVL on NZXT’s website (www.nzxt.com) for more information.

• Extreme Memory Profile (XMP):Supported

• EXTended Profiles for Overclocking (EXPO):Supported

EXPANSION SLOTS

• PCIe 5.0 ×16 slot (PCIEX16_1), supports ×16 mode:1 (Supports NVMe SSD as boot disks)

• PCIe 4.0 ×16 slots (PCIEX16_2 and PCIEX16_3), support ×2 mode:2 (Supports NVMe SSD as boot disks)

• M.2 Socket (Key E), supports Type 2230 Wi-Fi/BT PCIe Wi-Fi module:1

INTEGRATED GRAPHICS

• Integrated AMD RDNA™ 2 graphics:Supported

• HDMI 2.1 TMD Compatible:1

• HDR:Supported

• HDCP 2.3:max. resolution up to 4K 60Hz

STORAGE

• M.2_1, Type 2242/2260/2280 (PCIe 5.0 ×4 mode):1

• M.2_2, Type 2242/2260/2280 (PCIe 4.0 ×4 mode):1

• M.2_3, Type 2242/2260/2280 (PCIe 4.0 ×2 mode):1

• SATA 6Gb/s ports:4

• RAID 0/1/10 for SATA storage devices:Supported

• RAID 0/1/10 for M.2 NVMe storage devices:Supported

• NVMe SSD as boot disks:Supported

LAN

• Realtek®:RTL8125BG 2.5G LAN

WIRELESS

• 802.11ax Wi-Fi 6E Module:Supported

• Bluetooth:V5.2

AUDIO

• Realtek®:ALC1220 Codec

REAR I/O

• Wireless antenna SMA connectors:2

• HDMI™ port:1

• USB 2.0:2

• USB 3.2 Gen 2 Type-C port:1

• USB 3.2 Gen 2 ports:2

• USB 3.2 Gen 1 ports:4

• Clear CMOS button:1

• BIOS Flashback button:1

• LAN (RJ45) port:1

• Audio jacks:5

• Optical S/PDIF Out port:1

INTERNAL I/O

• 24-pin ATX power connector:1

• 8+4-pin ATX 12V power connector:1

• 4-pin CPU_FAN connector:1

• 4-pin AIO_PUMP connector:1

• 4-pin SYS_FAN connectors:5

• NZXT RGB LED connectors:4

• 5V ARGB LED connector:2

• USB 2.0 header (Up to 6 USB 2.0 ports):3

• USB 3.2 Gen1 header (Up to 4 USB 3.2 Gen 1 ports):2

• USB 3.2 Gen2x2 front panel header (For USB Type-C):1

• Front panel audio connector:1

• Power button:1

• Reset button:1

• POST LEDs:4

GENERAL

• System Requirements:NZXT CAM software requires Microsoft Windows® 11/10 operating system.

• Form Factor:ATX

• Warranty:3 years

• Hãng sản xuất: NZXT
• Tình trạng: mới 100%
• Bảo hành: 36 tháng
• CPU & Socket LGA socket 1200
• Model: NZXT N7 Z590 Matte Black
• Kích thước: ATX
• Hỗ trợ: Intel® Socket LGA1200 cho 10th và 11th
• Hỗ trợ công nghệ Intel Turbo Boost 2.0
• Chipset Intel® Z590
• Memory 4 x DIMM, Tối đa 128GB, DDR4
  4600 (OC) / 4133 (OC) / 4000 (OC) / 3866 (OC) / 3733…2666 (OC) / 2400 (OC) / 2933/2800/2666/2400/22133 MHz
• Hỗ trợ cấu hình bộ nhớ cao cấp Intel® (XMP) 2.0
• Hỗ trợ đầu ra đồ họa đơn: Cổng HDMI
  – HDMI™ 2.0/HDMI1.4b với tối đa độ phân giải 4096×2160 @ 60Hz
• Hỗ trợ đa GPU Hỗ trợ công nghệ AMD 2-Way CrossFireX ™
  Cổng cắm lưu trữ:
  – M.2 Type 2242/2260/2280 (PCIe x4 mode)
  – x2 (11th Gen CPUs – PCIe 4.0, 10th Gen CPUs – PCIe 3.0)
  – 4 x cổng SATA 6Gb / s
• Hỗ trợ RAID 0/1/5/10
• Hỗ trợ Công nghệ
  – Phản hồi thông minh
  – Intel® Công nghệ lưu trữ nhanh
  – Intel® 15 Sẵn sàng cho bộ nhớ Intel® Optane
  – LAN: LAN Realtek® RTL8125BG 2.5G LAN
  – Wi-Fi băng tần kép Intel® AX200 Wi-Fi 6
  – Wi-Fi 802.11 a / b / g / n / ac / ax
  – Bluetooth Bluetooth V5.2
  – Âm thanh Realtek® ALC1220 Codec
  – Âm thanh độ nét cao 8 kênh, DAC 32-bit / 192KHz
  – Tụ âm thanh dòng Nichicon Fine Gold Series
• Cổng I/O phía sau
  – 1 x USB 3.2 Gen 2×2 (Type-C)
  – 1 x USB 3.2 Gen 2 (Type-A)
  – 4 x USB 3.2 Gen 1 (Type-A)
  – 2 x USB 2.0
  – 1 x HDMI™ 2.0
  – Ăn ten không giây
  – LAN (RJ45) Port
  – 5.1-Channel Audio Jacks
  – Optical S/PDIF
  – Clear CMOS Button

Sản phẩm	Bo mạch chủ
Tên Hãng	NZXT
Model	N7 B550 Matte White
CPU hỗ trợ	AMD
Chipset	B550
RAM hỗ trợ	Memory Channels: 4DDR4 (Dual channel) Max Memory Size:128GB OC Frequency (Vermeer CPUs): 4666+ MHz OC Frequency (Matisse CPUs): 4666+ MHz OC Frequency (Renoir APUs): 4733+ MHz Base Frequency: 3200/ 2933/ 2667/ 2400/ 2133
Khe cắm mở rộng	PCIe x16 (x16 mode) x 1 (Vermeer & Matisse - PCIe 4.0, Renoir - PCIe 3.0) PCIe x16 (x4 mode) x 1 PCIe 3.0 x1 x 2
Ổ cứng hỗ trợ	M.2 Type 2242/2260/2280 (x4 mode) x 1 (Vermeer & Matisse - PCIe 4.0, Renoir - PCIe 3.0) M.2 Type 2242/2260/2280 (PCIe 3.0 x2 & SATA mode) x 1 SATA 6Gb/s x 6* (M2_2 and SATA3_5_6 share lanes)
Cổng kết nối (Internal)	USB 3.2 Gen 2 (Type-C) x 1 USB 3.2 Gen 2 (Type-A) x 3 USB 3.2 Gen 1 (Type-A) x 4 USB 2.0 x 2 HDMI™ 2.1 x 1 Wireless Antenna x 2 (2T2R) LAN (RJ45) Port x 1 5.1-Channel Audio Jacks x 1 Optical S/PDIF x 1 BIOS Flashback Button x 1 Clear CMOS Button x 1
Cổng kết nối (Back Panel)	M.2 (M Key), Type 2242/2260/2280 x 1 (PCIe 4.0/3.0 x4 mode), 1 (PCIe 3.0 x2 & SATA mode) M.2 (E Key) (For wireless cards) x 1 SATA 6Gbps Ports x 6 USB 3.2 Gen 2 Header (Type-C) x 1 USB 3.2 Gen 1 Header x 1 (Up to 2 ports) USB 2.0 Header x 3 (Up to 6 ports) Front Panel Audio x 1 CPU_FAN Connector x 1 (Up to 24W) AIO_PUMP Connector x 1 (Up to 24W) SYS_FAN Connector x 5 (Up to 24W) NZXT RGB LED Header x 2 5V ARGB Header x 1 12V RGB Header x 1 24-pin EATX Power x 1 8-pin ATX 12V Power x 1 4-pin ATX 12V Power x 1 Power Button x 1 Reset Button x 1 POST LEDs x 4
LAN / Wireless	Realtek®: RTL8125BG 2.5G AX210 Wi-Fi 6E, 802.11 V5.2
Kích cỡ	ATX
