MAINBOARD T-WOLF TW-B760M4 PLUS (LGA1700/CPU Gen 12-13-14th/2*DDR4/DP-HDMI-VGA/LAN 1000/2*NVMe-M.2 Sata)/M.2 Wifi/PCIe16X/PCIe1X)

CPU Socket	LGA (2011 V3/V4)
Chipset	BGA (X99)
Graphics Interface	1*PCIe 3.0 x16
Memory Type	4 channel DDR3 1066/1333/1666/1866 MHZ
Memory DIMMs	4*DIMMs Upto 128GB
Expansion Slots	1*PCIe 3.0 x1
Sata USB	3*Sata3.0+6*USB2.0+2*USB3.0
M.2	1*M.2 (M.2 Sata3.0/NVMe)Auto Switch
Lan	1*Realtek 100M/1000M
USB Front	1*F_USB2.0+1/F_USB3.0
Audio	Realtel 6HD
COM	1*COM
Keyboard Mouse	PS/2
Power	8 pin + 24 pin
BIOS initial restore	JCMOS
Form Factor (mm)	186mm x 215mm

Intel X99 Chipset
Support LGA 2011-3 Socket Xeon E5 v3/v4 Family CPU
Support dual-channel DDR42133/2400MHz Register ECC, Memory upto 256GB
AMI BIOS
2*M.2 PCIe NVMe/NGFF slot

Thông số kỹ thuật
CPU    Support LGA 2011-3 Socket Xeon E5 v3/v4 Family CPU
Chipset    Intel X99 Chipset
Memory    8*288-pin DDR4 slots
Memory upto 256GB
Support dual-channel DDR42133/2400MHz Register ECC
BIOS    AMI BIOS
I/O interface    2*PS/2 port
4*USB2.0 port
4*USB3.0 port
1*RJ45 port
Audio port (Line in/Line out/MIC in)
Onboard interface    1*24-pin ATX power conector
2*8-pin ATX 12V power connector
1*USB 2.0 connector (can support 2*USB 2.0)
1*USB 3.0 connector (can support 2*USB 3.0)
1*F_AUDIO connector
1*F_PANEL connector
4*FAN connector
8*SerialATA ports
Intergrated sound    7.1 channel Realtek® ALC 897 HD Audio codec
Intergrated LAN    LAN 10/100/1000 Mbps onboard
Expansion slot    2*PCI Express x16 slot
2*PCI Express x1 slot
2*M.2 PCIe NVMe/NGFF slot
Dimension    E-ATX (281mm x 295mm)
