Thiết bị chuyển mạch Switch RUIJIE RG-ES124GD 24-Port 10/100/1000Mbps

- 8 cổng 1000BASE-T ports (7x POE/POE+), tổng công suất 135W

- Hỗ trợ lên đến 2 cổng WAN

- Memory: 512M

- Flash: 4GB EMMC

- Cache: 750MB

- Hỗ trợ 300 user

- Dễ dàng quản lý và cấu hình qua Ruijie cloud

- Hỗ trợ 16 kênh VPN (IPsec)

- Hỗ trợ quảng cáo

- Cân bằng tải giữa các đường truyền internet

- Hỗ trợ cập nhật thư viện signature của các ứng dụng mobile/windows (facebook, youtube, torrent..) để quản lý/ngăn chặn.

- Nguồn điện: 100-240VAC, 50-60Hz, 3A

- Kích thước: 200 × 200 x 43.6 mm

- Nhiệt độ hoạt động: 0°C~45°C

- Hỗ trợ 48 cổng GE RJ45.

- 4 cổng 10GE SFP+.

- Tốc độ chuyển mạch: 598Gbps.

- Tốc độ chuyển gói tin: 252Mpps.

- Kích thước (WxDxH): 440 x 300 x 44 mm.

- Nhiệt độ hoạt động: 0°C~50°C.

Đặc tính kỹ thuật

Model	RG-S5750C-48GT4XS-H
Fixed port	GE RJ45 port: 48 10GE SFP+ port: 4
Flexible card	Card slot: 2 Card type: 1-port QSFP+ dedicated stack card 4-port 10GE SFP+ interface card
Management port	ETH management port: 1 Console port (RJ45): 1 Console port (Mini USB): 1 USB 2.0 port: 1
Performance	Switching capacity: 598Gbps/5.98Tbps Forwarding rate: 252Mpps MAC table size: 64,000 ARP table size: 20,000 Jumbo frame: 9216 Bytes Packet buffer: 32Mbit
Physical	Dimensions (WxDxH): 440 x 300 x 44 mm Unit weight: 4.2kg
Power supply	- Type: Hot swappable - Redundancy: 1+1 - AC frequency: 50/60Hz - Rated AC voltage: 100~240V - Maximum AC voltage: 90~264V - Rated HVDC voltage: 240V DC - Maximum HVDC voltage: 192~288V DC - Rated DC voltage: -36V ~ -72V DC - Maximum power rating: 140W - Idle power rating: 45W
Heat dissipation system	- Dissipation mode: Air-cooled heat dissipation. Intelligent speed adjustment - Number of fans: 3 - Airflow: Air flows in from the left and exhausts from the right
Certifications	- Safety: EN 60960-1, IEC 60950-1 - EMC: EN 300 386 - Emissions: EN 55022, EN55032 - Immunity generic: EN 55024 - ESD: EN 61000-4-2 - Radiated: EN 61000-4-3 - EFT/Burst: EN 61000-4-4 - Surge: EN 61000-4-5 - Conducted: EN 61000-4-6 - Power frequency magnetic field: EN 61000-4-8 - Voltage dips and interruptions: EN 61000-4-11 - Harmonics: EN 61000-3-2 - Flicker: EN 61000-3-3 - Anti-gascorrosion: GB-T2423.51-2012(Refer to IEC 60068-2-60)
Operating temperature	0°C~ 50°C
Storage temperature	-40°C~ 70°C
Operating humidity	10%~90% RH
Storage humidity	5%~95% RH
Operating altitude	-500 ~ 5000m
MTBF(hours)	513460
Ethernet features	Ethernet: Full-duplex, Half-duplex, Auto negotiation, Flow control on interface, Jumbo frames, Link aggregation(IEEE802.3ad, LACP, maximum 8 member ports per AP), 2048 maximum aggregation ports, Load balancing, Broadcast storm control
	VLAN: IEEE802.1Q, 4094 VLAN ID, 4094 VLANIF interface, Access mode, Trunk mode, Default VLAN, Port-based VLAN, MAC-based VLAN, Protocol based VLAN, IP subnet-based VLAN, Voice VLAN, GVRP, Super VLAN, Private VLAN, Guest VLAN
	MAC: Automatic learning and aging of MAC addresses, Static and dynamic MAC address entries, Interface-based and VLAN-based MAC address learning limiting, Sticky MAC, MAC address spoofing guard
	ARP: Static ARP, Trusted ARP, Gratuitous ARP, Proxy ARP, Local proxy ARP, ARP trustworthiness detection, ARP-based IP guard
	STP: STP(IEEE802.1D), RSTP(IEEE802.1w), MSTP (IEEE802.1s), 64 MST instances, Port Fast, BPDU guard, BPDU filter, TC guard, TC filter, Root guard, Auto edge, BPDU transparent transmission, BPDU tunnel, VLAN-Specific Spanning Tree(VSST, working with PVST, PVST+ and RPVST)
	ERPS: G.8032 v1/v2, Single-ring, Tangent-ring, Intersecting-ring, Load balancing
	L2 multicast: IGMP v1/v2/v3 snooping, IGMP filter, IGMP fast leave, IGMP querier, IGMP security control, IGMP profile, MLD v1/v2 snooping, MLD filter, MLD fast leave, MLD source check
	QinQ: Basic QinQ, Selective QinQ(Flexible QinQ), 1:1 VLAN switching, N:1 VLAN switching VLAN mapping, TPID configuration, MAC address replication, L2 transparent transmission, Priority replication, Priority mapping
IPv4/IPv6	IPv4 unicast routing: IPv4 static routing, RIPv1/v2, OSPFv2, BGP4, MBGP, IS-IS, PBR, VRF, ECMP, WCMP, Routing policies, 12000 IPv4 routing table
	IPv6 unicast routing: IPv6 static routing, RIPng, OSPFv3, BGP4+, IS-ISv6, PBRv6, VRFv6, Packet–based load balancing and flow-based load balancing, 6000 IPv6 routing table
	IPv6 feature: ND (Neighbor Discovery), 10000 ND entries, ND snooping, 6 over 4 manual tunnel, 6 to 4 auto tunnel, ISATAP, IPv4 over IPv6 tunnel, IPv6 over IPv6 tunnel, GRE tunnel (4 over 6), GRE tunnel (6 over 6), IPv6 extender option head, Manually configure local address, Automatically create local address, 0-64 bit mask, 65-128 bit mask
	Multicast routing: IGMPv1/v2/v3, MLDv1/v2, PIM-DM, PIM-SM, PIM-SSM, PIM-DMv6, PIM-SMv6, MSDP, MCE, IGMP proxy, MLD proxy, Multicast static routing, 8000 IPv4 multicast routing table, 4000 IPv6 multicast routing table
	DHCP: DHCP server/relay/client, DHCPv6 server/relay/client, DHCP option 43/82/138
MPLS	MPLS: MPLS labels and forwarding, LSP, LDP, Inter-domain LDP LSP
	MPLS L3 VPN: BGP VPN, IS-IS VPN, OSPF VPN
Reliability	BFD: Single-hop BFD, BFD for IPv4 static routes/OSPF/IS-IS/ BGP4/ VRRP/MPLS/PBR, BFD for IPv6 static routes/OSPFv3/IS-ISv6/BGP4+/VRRPv6/PBRv6
	DLDP: DLDP for IPv4 static routes/OSPF/BGP4/VRRP/PBR
	LLDP: IEEE802.1AB 2005, ANSI/TIA-1057, LLDP, LLDP-MED, LLDP-PoE
	RLDP: Uni-directional link detection, Bi-directional forwarding detection, Downlink loop detection
	VSU: 9 VSU(Virtual Switch Unit) stacked members, 80Gbps maximum stacking bandwidth with service port VSL connection, Traffic balancing
	VRRP: VRRPv3, VRRP+
	REUP: REUP(Ruijie Rapid Ethernet Uplink Protection Protocol for dual uplink backup, VLAN load balancing
	GR: GR for RIP/OSPF/IS-IS/BGP/MPLS L3 VPN/LDP
	RNS: RNS test for ICMP/DNS/TCP, Track support for RNS
QoS	Stream classification: Classification based on IEEE802.1p/DSCP/TOS
	Shaping: Rate-limit on ingress/egress traffic on interface
	Congestion avoidance: RED, WRED, Tail drop
	Congestion management: SP, WRR, DRR, WFQ, SP+WFQ, SP+WRR, SP+DRR, 8 queue priorities per port
ACL	ACL entries: 3500 IPv4/v6 rules
	ACL type: Standard IP ACL, Extended IP ACL, MAC-extended ACL, Time-based ACL, Expert ACL, ACL80, IPv6 ACL, SVI router ACL, ACL logging, ACL counter, ACL remark, ACL redirection, Security channel, Protected port, Port security
Security	ARP security: ARP check, DAI, Trusted ARP, ARP trustworthiness detection, Gateway-targeted ARP spoofing prevention, ARP rate-limit
	Attack defense: CPP (CPU Protection Policy), NFPP(Network Foundation Protection Policy) guard for ARP/IP/ICMP/DHCP/DHCPv6/ND/Self-defined attack, URPF
	IP: IP source guard v4/v6, 3500 IPv4 source guard user capacity, 1500 IPv6 source guard user capacity
	DHCP: DHCP snooping, DHCPv6 snooping, DHCP snooping on option 82
	AAA: Local, RADIUS, RADIUS v6, TACACS+
	IEEE802.1X: IEEE802.1X port/MAC based authentication, Dynamic VLAN and ACL assignment, MAC authentication bypass
	Web portal: Ruijie 1st-Gen and 2nd-Gen portal authentication, Portal authentication/accounting, Portal detection and escape
Configuration	Login: CLI, Console, Telnet, Telnet for IPv6, SSH v1.5/v2.0, SSH for IPv6, SCP, SNMPbased NMS, Web-based UI, Fast deploy(Ruijie Cloud App), Cloud management
	File: Multiple boot configuration, Multiple firmware
Management	Network: Ping(v4/v6), Traceroute(v4/v6), sFlow, SNMPv1/v2c/v3, HTTP, HTTPS, RMON(1,2,3,9), CWMP(TR069), Syslog, MIB,
	Application: DNS client v4/v6, TFTP Server/Client, TFTP Client v6, FTP Server/Client, FTP Server/Client v6, NTP Server/Client, NTP Server/Client v6, SNTP, EEE(IEEE802.3az), OpenFlow v1.0, OpenFlow v1.3, Hot patch, Z-PoE (Non-stop PoE)
	Mirroring: Many-to-one mirroring, One-to-many mirroring, Flow-based mirroring, Over devices mirroring, VLAN-based mirroring, VLAN-filtering mirroring, AP-port mirroring, SPAN, RSPAN, ERSPAN
	Hardware monitoring: Power supply monitoring, Fan status and alarm monitoring

- Bảo hành: 3 năm.

- LAN/WAN switchable SFP port for adding optical fiber connectivity.

- User friendly configuration, easy to learn.

- Intelligent load balancing and link redundancy between multiple WAN ports.

- New efficient way of bandwidth management based on application and user.

- Network interface: 8 x 10/100/1000 Base-T, 1 × 1G Base-X SFP.

- Max. WAN Ports: 4 × 10/100/1000 Base-T.

- CPU: Dual Cores, 880MHz.

- RAM: 256MB DDRIII.

- Recommended Concurrent Users: 200.

- Recommended Bandwidth: 600Mbps.

- Dimension: 202 x 108 x 28 mm.

- Weight: 0.5kg.

- Power Supply: 100~240V AC, 50/60Hz.

- Power Consumption:

- Certifications: CE, ROHS.

- Operating Temperature: 0°C~40°C.

- Bảo hành: 3 năm.

- Support 16 x 110/100/1000M copper ports and 2 x 1000M uplink SFP combo ports: 16 ports for PoE/PoE+, with the maximum PoE power up to 247W.

- Max. PoE budget: 247W.

- Layer Type: Unmanaged.

- Switching capacity: 36Gbps.

- Forwarding rate: 26.78Mpps.

- Dimensions (W x D x H): 440 x 240 x 44 mm.

Specifications

Basic
Downlink Ports	16 x 10/100/1000BASE-T
Uplink Ports	2 x 1000BASE-X SFP
PoE/PoE+ ports	16
Max. PoE budget	247W
Layer Type	Unmanaged
Switching capacity	36 Gbps
Forwarding rate	26.78 Mpps
MAC address table	8000
Dimensions (W x D x H)	440 mm x 240 mm x 44 mm
Weight (With package)	4.0 kg
Software Features
Auto/Full/Half Duplex Negotiation	Yes
Auto MDI/MDIX	Yes
Switching model	Store-and-forward
Cloud Management	Cloud monitoring
Hardware Features
Flow Control	Yes
Port Isolation	Yes
Power Consumption	≤285W
Power Supplies	100V AC to 240V AC, 3.5A
Surge Protection	6kV
Fan	Support
Operating Temperature	0°C to 45°C (32°F to 109°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Operating Humidity	10% to 90% RH
Storage Humidity	5% to 95% RH
Certificate	CE, RoHS

- Bảo hành: 3 năm.
