Máy Tính Bộ PC – MINI PC Intel Core i5-8259U Processor (6M Cache, up to 3.80 GHz), SSD 240GB, RAM 8GB

Sản phẩm

Máy tính đồng bộ

Hãng sản xuất

Intel NUC

Model

RNUC11PAHI30000

Bộ vi xử lý

Intel® Core™ i3-1115G4 (Upto 4.10GHz, 2 nhân 4 luồng, 6MB Cache)

RAM

Không kèm sẵn, DDR4-3200 1.2V SO-DIMM tối đa 64GB

Ổ cứng

Không kèm sẵn, HDD & SSD, 2.5,M.2

Card đồ họa

Intel® UHD Graphics

Ô đĩa

Không có

Kết nối mạng

Ethernet Technology: 2.5 Gigabit Ethernet
Wireless LAN: Yes
Bluetooth: Yes

Keyboard & Mouse

Không có

Cổng kết nối

HDMI: Yes
Total Number of USB Ports: 7
Number of USB 3.1 Gen 2 Ports (Rear): 2
Number of Onboard USB 2.0 Ports: 1
USB Type-C (Rear): Yes
USB Type-C Detail: 2x Type-c
Number of SATA Interfaces: 2
Number of Thunderbolt 3 Ports: 2

Hệ điều hành

No OS

Bảo hành

36 tháng

ESSENTIALS

Supported Operating Systems

Windows 11 Home*, Windows 11 Pro*, Windows 10 Home, 64-bit*, Windows   10 IoT Enterprise*, Windows 10 Pro, 64-bit*, Red Hat Linux*, Ubuntu 20.04   LTS*

Board Number

NUC11TNBv7

Board Form Factor

UCFF (4" x 4")

Socket

Soldered-down BGA

Internal Drive Form Factor

M.2 and 2.5" Drive

# of Internal Drives Supported

3

TDP

28 W

DC Input Voltage Supported

12-20 VDC

Processor Included

Intel® Core™ i7-1185G7 Processor (12M Cache, up to 4.80 GHz, with   IPU)

Intel vPro® Platform Eligibility

Yes

Total Cores

4

Total Threads

8

Lithography

10 nm SuperFin

Max Turbo Frequency

4.80 GHz

MEMORY & STORAGE

Max Memory Size (dependent on memory type)

64 GB

Memory Types

DDR4-3200 1.2V SO-DIMMs

Max # of Memory Channels

2

Max # of DIMMs

2

ECC Memory Supported

No

PROCESSOR GRAPHICS

Integrated Graphics

Yes

Graphics Output

Dual HDMI 2.0b w/HDMI CEC, Dual DP 1.4a via Type C

# of Displays Supported

4

EXPANSION OPTIONS

PCI Express Revision

Gen 4 (m.2 22x80 slot); Gen 3 (otherwise)

PCI Express Configurations

PCIe x4 Gen 4: M.2 22x80 (key M)

PCIe x1 Gen 3: M.2 22x42 (key B)

PCIe x1: M.2 22x30 (key E)

M.2 Card Slot (wireless)

22x30 (E)

M.2 Card Slot (storage)

22x80 NVMe (M); 22x42 SATA (B)

I/O SPECIFICATIONS

# of USB Ports

4

USB Configuration

Front: 2x USB 3.2

Rear: 2x USB 4 (type C), 1x USB 3.2, 1x USB 2.0

Internal: 1x USB 3.2 on m.2 22x42 (pins), 2x USB 2.0 (headers)

Total # of SATA Ports

1

Serial Port via Internal Header

Yes

Integrated LAN

Intel® Ethernet Controller i225-LM

Integrated Wireless

Intel® Wi-Fi 6 AX201

Integrated Bluetooth

Yes

Additional Headers

Front_panel (PWR, RST, 5V, 5Vsby, 3.3Vsby); Internal 2x2 power   connector

# of Thunderbolt™ Ports

1x Thunderbolt™ 4, 1x Thunderbolt™ 3

ADVANCED TECHNOLOGIES

Intel® Optane™ Memory Supported

No

Intel® Virtualization Technology for Directed I/O (VT-d)

Yes

Intel vPro® Platform Eligibility

Yes

Intel® ME Firmware Version

15

TPM

Yes

TPM Version

2.0

Intel® Virtualization Technology (VT-x)

Yes

SECURITY & RELIABILITY

Intel® AES New Instructions

Yes

Intel® Trusted Execution Technology

Yes

• 2 x M.2 PCIe X4 slots (PCH)
• 1 x M.2 PCIe X4 slot (CPU)
• Double-wide PCIe X16 (CPU) slot shared with PCIe X4 (CPU)
• 20cm Chiều dài Card tối đa

• Intel® Wi-Fi 6 AX201
• Bluetooth 5.0

• 1 x Cổng Thunderbolt™ 3
• 1 x USB 3.1 Gen2 Type-A
• 1 x Audio Jack
• Card Reader SDXC with UHS-II

• 1 x HDMI
• 1 x Cổng Thunderbolt™ 3
• 1 x Mini DisplayPort 1.4
• 2 x USB 3.1 Gen1 Type-A
• 1 x Intel® Ethernet Controller i225-V
• 1 x DC-in

Intel Pentium J5005 up to 2.8GHz, 4MB

Không kèm theo, 2x SODIMM support dual channel DDR4, 2133 MHz, 1.2V, 8G max

Không kèm theo, 1x SATA3 S/p 2.5" HDD/SSD

Intel HD Iris Graphics 605

1x SDXC slot with UHS-I support

4x USB 3.0(2+2), 2x USB2.0, 2x HDMI 2.0a Port with 4K 60Hz, Không có Jack 3.5

IEEE 802.11 ac

Bluetooth V.5

LAN 1GB

36 tháng

Intel
