Nguồn máy tính SEASONIC Focus Plus FX-750 750W

Công suất: 500W

Chứng nhận: 80 PLUS®Bronze

DC output: 12V 40A (MAX. 480W)

Fan: FDB 120mm, S2FC - điều khiển tốc độ thông minh

Cáp: dạng LIỀN, sợi dẹt màu đen

Active PFC Full Range: 110 ~ 240V

Kích Thước: 150 mm (W) x 140 mm (L) x 86 mm (H)

Kết nối: MB 20+4pin * 1 / CPU 4+4pin * 1 / PCI-E * 2 / SATA * 4 / Molex 4pin * 3

Mã hàng: SSR-750GX
Bảo hành: 60 Tháng
Hãng sản xuất: SEASONIC

TỔNG CÔNG SUẤT: 750W
CHỨNG NHẬN: 80 PLUS®Gold
DC OUTPUT: 12V 62A (MAX. 744W)
FAN: FDB 120mm, Hybrid Silent Fan Control - điều khiển tốc độ thông minh
CÁP: dạng RỜI (toàn bộ), sợi dẹt màu đen
Active PFC Full Range: 100 ~ 240V
KÍCH THƯỚC: 150 mm (W) x 140 mm (L) x 86 mm (H)
KẾT NỐI: MB 20+4pin * 1 / CPU 4+4pin * 2 / PCI-E * 4 / SATA * 8 / Molex 4pin * 3



Technical Specifications
80PLUS®		Gold
Cybenetics Efficiency Level		TBA
Cybenetics Noise Level		TBA
Form Factor		Intel ATX 12 V
Dimensions		140 mm (L) x 150 mm (W) x 86 mm (H)
Fan Information	Fan Size	120 mm
	Fan Control	S3FC - Fanless until 30 % load
	Fan Bearing	Fluid Dynamic Bearing
	Life Expectancy	50,000 hours at 40 °C, 15 % - 65 % RH
Cable Information	Modularity	Fully Modular
	Cable type	Flat black cables
Electrical Features	Operating Temperature	0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
	MTBF @ 25 °C, excl. fan	100,000 hours
	AC Input	Full Range
	Protection	OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental	Safety and EMC	cTUVus, TUV, CB, CCC, BSMI, EAC, CE
	Environmental Compliance	Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty		10 Years

Power Output
AC Input	Voltage: 100 V - 240 V
	Current: 13 - 6.5 A
	Frequency: 50 Hz - 60 Hz
DC Output	Rail	+3.3 V	+5 V	+12 V	-12 V	+5 VSB
	Maximum Power	25 A	25 A	83 A	0.3 A	3 A
		125 W		996 W	3.6 W	15 W
	Total continuous power	1000 W







SSR-750FM

Technical Specifications
80PLUS®		Gold
Form Factor		Intel ATX 12 V
Dimensions		140 mm (W) x 150 mm (L) x 86 mm (H)
Fan Information	Fan Size	120 mm
	Fan Control	S2FC
	Fan Bearing	Fluid Dynamic Bearing
	Life Expectancy	50,000 hours at 40 °C, 15 % - 65 % RH
Cable Information	Modularity	Semi-modular
	Cable type	Webbed cables (attached) Flat black cables(modular)
Electrical Features	Operating Temperature	0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
	MTBF @ 25 °C, excl. fan	100,000 hours
	AC Input	Full Range
	Protection	OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental	Safety and EMC	cTUVus, TUV, CB, CCC, BSMI, EAC
	Environmental Compliance	Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty		7 Years

Power Output
AC Input	Voltage: 100 V - 240 V
	Current: 10 - 5 A
	Frequency: 50 Hz - 60 Hz
DC Output	Rail	+3.3 V	+5 V	+12 V	-12 V	+5 VSB
	Maximum Power	20 A	20 A	62 A	0.3 A	3 A
		100 W		744 W	3.6 W	15 W
	Total continuous power	750 W
