Nguồn máy tính SEASONIC PRIME ULTRA 1000TR 1000W

TỔNG CÔNG SUẤT: 1300W
CHỨNG NHẬN: 80 PLUS®Gold
DC OUTPUT: 12V 108A (MAX. 1296W)
FAN: FDB 135mm, Premium Hybrid Fan Control - điều khiển tốc độ thông minh
CÁP: dạng RỜI (toàn bộ), sợi dẹt màu đen
Active PFC Full Range: 100 ~ 240V
KÍCH THƯỚC: 150 mm (W) x 170 mm (L) x 86 mm (H)
KẾT NỐI: MB 20+4pin * 1 / CPU 4+4pin * 2 / PCI-E * 12 / SATA * 12 / Molex 4pin * 5

SPECIFICATIONS

SSR-1300GD

Technical Specifications
80PLUS®		Gold
Cybenetics Efficiency Level		TBA
Cybenetics Noise Level		TBA
Form Factor		Intel ATX 12 V
Dimensions		170 mm (W) x 150 mm (L) x 86 mm (H)
Fan Information	Fan Size	135 mm
	Fan Control	Premium Hybrid Fan Control
	Fan Bearing	Fluid Dynamic Bearing
	Life Expectancy	50,000 hours at 40 °C, 15 % - 65 % RH
Cable Information	Modularity	Fully Modular
	Cable type	Webbed cables (MB, CPU, PCIe) Flat black cables
Electrical Features	Operating Temperature	0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
	MTBF @ 25 °C, excl. fan	150,000 hours
	AC Input	Full Range
	Protection	OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental	Safety and EMC	cTUVus, TUV, CB, CCC, BSMI, EAC
	Environmental Compliance	Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty		12 Years

Power Output
AC Input	Voltage: 100 V - 240 V
	Current: 15 A–7.5 A
	Frequency: 50 Hz–60 Hz
DC Output	Rail	+3.3 V	+5 V	+12 V	-12 V	+5 VSB
	Maximum Power	25 A	25 A	108 A	0.3 A	3 A
		125 W		1296 W	3.6 W	15 W
	Total continuous power	1320 W

CABLES

SSR-1300GD

Connector	Connector count	Cable count	Cable
Main Power (24/20 pins)	1	1
CPU (8/4 pins)	2	2
PCIe (8/6 pins)	12	0
		6
SATA	12	3
		0
		0
		0
		0
Peripheral	5	1
		1
Floppy	1	1

SSR-550FM

Technical Specifications
80PLUS®		Gold
Form Factor		Intel ATX 12 V
Dimensions		140 mm (W) x 150 mm (L) x 86 mm (H)
Fan Information	Fan Size	120 mm
	Fan Control	S2FC
	Fan Bearing	Fluid Dynamic Bearing
	Life Expectancy	50,000 hours at 40 °C, 15 % - 65 % RH
Cable Information	Modularity	Semi-modular
	Cable type	Webbed cables (attached) Flat black cables(modular)
Electrical Features	Operating Temperature	0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
	MTBF @ 25 °C, excl. fan	100,000 hours
	AC Input	Full Range
	Protection	OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental	Safety and EMC	cTUVus, TUV, CB, CCC, BSMI, EAC, CE
	Environmental Compliance	Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty		7 Years

Power Output
AC Input	Voltage: 100 V - 240 V
	Current: 8 - 4 A
	Frequency: 50 Hz - 60 Hz
DC Output	Rail	+3.3 V	+5 V	+12 V	-12 V	+5 VSB
	Maximum Power	20 A	20 A	45 A	0.3 A	3 A
		100 W		540 W	3.6 W	15 W
	Total continuous power	550 W

• TỔNG CÔNG SUẤT: 750W
• CHỨNG NHẬN: 80 PLUS®Gold
• DC OUTPUT: 12V 62A (MAX. 744W)
• FAN: FDB 120mm, Hybrid Silent Fan Control - điều khiển tốc độ thông minh
• CÁP: dạng RỜI (toàn bộ), sợi dẹt màu đen
• Active PFC Full Range: 100 ~ 240V
• KÍCH THƯỚC: 150 mm (W) x 140 mm (L) x 86 mm (H)
• KẾT NỐI: MB 20+4pin * 1 / CPU 4+4pin * 2 / PCI-E * 4 / SATA * 8 / Molex 4pin * 3

• FOCUS Plus 750 Gold
  AC Input	Voltage: 100 V - 240 V
  	Current: 10 - 5 A
  	Frequency: 50 Hz - 60 Hz
  DC Output	Rail	+3.3 V	+5 V	+12 V	-12 V	+5 VSB
  	Maximum Power	20 A	20 A	62 A	0.3 A	3 A
  		100 W		744 W	3.6 W	15 W
  	Total continuous power	750 W

  FOCUS PLUS 750 Gold Technical Specifications
  80PLUS®		Gold
  Form Factor		Intel ATX 12 V
  Dimensions		150 mm (W) x 140 mm (L) x 86 mm (H)
  Fan Information	Fan Size	120 mm
  	Fan Control	Hybrid Silent fan Control
  	Fan Bearing	Fluid Dynamic Bearing
  	Life Expectancy	70,000 hours at 40 °C, 15 % - 65 % RH
  Cable Information	Modularity	Fully Modular
  	Cable type	Flat black cables
  Electrical Features	Operating Temperature	0 - 50 °C
  	MTBF @ 25 °C, excl. fan	100,000 hours
  	AC Input	Full Range
  	Protection	OPP, OVP, UVP, OCP, OTP, SCP
  Safety and Environmental	Safety and EMC	cTUVus, TUV, CB, CCC, BSMI, EAC, RCM
  	Environmental Compliance	Energy Star, RoHS, WEEE, ErP Lot 6, REACH
