Sản phẩm tương tự
Nguồn máy tính SEASONIC Prime 1300PD 13000W
Seasonic PRIME 1300PD 80 PLUS PLATINUM
Công suất: 1300W
Chứng nhận: 80 PLUS®Platinum
Chuẩn nguồn: ATX 12V
Kích thước: 150 mm (W) x 170 mm (L) x 86 mm (H)
Cáp kết nối: MB 20+4pin x 1 / CPU 4+4pin x 2 / PCI-E x 12 / SATA x 12 / Molex 4pin x 5
Nguồn máy tính SEASONIC PRIME ULTRA 1000TR 1000W
- TỔNG CÔNG SUẤT: 1000W
- CHỨNG NHẬN: 80 PLUS®TItanium
- DC OUTPUT: 12V 83A (MAX. 996W)
- FAN: FDB 135mm, Premium Hybrid Fan Control - điều khiển tốc độ thông minh
- CÁP: dạng RỜI (toàn bộ), sợi dẹt màu đen
- Active PFC Full Range: 100 ~ 240V
- KÍCH THƯỚC: 150 mm (W) x 170 mm (L) x 86 mm (H)
- KẾT NỐI: MB 20+4pin * 1 / CPU 4+4pin * 2 / PCI-E * 8 / SATA * 14 / Molex 4pin * 5
| Power Output | ||||||
|---|---|---|---|---|---|---|
| AC Input | Voltage: 100 V - 240 V | |||||
| Current: 11 - 5.5 A | ||||||
| Frequency: 50 Hz - 60 Hz | ||||||
| DC Output | Rail | +3.3 V | +5 V | +12 V | -12 V | +5 VSB |
| Maximum Power | 25 A | 25 A | 83 A | 0.5 A | 3 A | |
| 125 W | 996 W | 6.0 W | 15 W | |||
| Total continuous power | 1000 W | |||||
| Technical Specifications | ||
|---|---|---|
| 80PLUS® | Titanium | |
| Form Factor | Intel ATX 12 V | |
| Dimensions | 150 mm (W) x 170 mm (L) x 86 mm (H) | |
| Fan Information | Fan Size | 135 mm |
| Fan Control | Premium Hybrid Fan Control | |
| Fan Bearing | Fluid Dynamic Bearing | |
| Life Expectancy | 50,000 hours at 40 °C, 15 % - 65 % RH | |
| Cable Information | Modularity | Fully Modular |
| Cable type | Flat black cables | |
| Electrical Features | Operating Temperature | 0 - 50 °C |
| MTBF @ 25 °C, excl. fan | 150,000 hours | |
| AC Input | Full Range | |
| Protection | OPP, OVP, UVP, OCP, OTP, SCP | |
| Safety and Environmental | Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, EAC |
| Environmental Compliance | Energy Star, RoHS, WEEE, ErP Lot 6, REACH | |
Nguồn máy tính SEASONIC Prime Ultra 1300GD 1300W
TỔNG CÔNG SUẤT: 1300W
CHỨNG NHẬN: 80 PLUS®Gold
DC OUTPUT: 12V 108A (MAX. 1296W)
FAN: FDB 135mm, Premium Hybrid Fan Control - điều khiển tốc độ thông minh
CÁP: dạng RỜI (toàn bộ), sợi dẹt màu đen
Active PFC Full Range: 100 ~ 240V
KÍCH THƯỚC: 150 mm (W) x 170 mm (L) x 86 mm (H)
KẾT NỐI: MB 20+4pin * 1 / CPU 4+4pin * 2 / PCI-E * 12 / SATA * 12 / Molex 4pin * 5
SPECIFICATIONS
SSR-1300GD
| Technical Specifications | ||
|---|---|---|
| 80PLUS® | Gold | |
| Cybenetics Efficiency Level | TBA | |
| Cybenetics Noise Level | TBA | |
| Form Factor | Intel ATX 12 V | |
| Dimensions | 170 mm (W) x 150 mm (L) x 86 mm (H) | |
| Fan Information | Fan Size | 135 mm |
| Fan Control | Premium Hybrid Fan Control | |
| Fan Bearing | Fluid Dynamic Bearing | |
| Life Expectancy | 50,000 hours at 40 °C, 15 % - 65 % RH | |
| Cable Information | Modularity | Fully Modular |
| Cable type | Webbed cables (MB, CPU, PCIe) Flat black cables |
|
| Electrical Features | Operating Temperature | 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C) |
| MTBF @ 25 °C, excl. fan | 150,000 hours | |
| AC Input | Full Range | |
| Protection | OPP, OVP, UVP, OCP, OTP, SCP | |
| Safety and Environmental | Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, EAC |
| Environmental Compliance | Energy Star, RoHS, WEEE, ErP Lot 6, REACH | |
| Warranty | 12 Years | |
| Power Output | ||||||
|---|---|---|---|---|---|---|
| AC Input | Voltage: 100 V - 240 V | |||||
| Current: 15 A–7.5 A | ||||||
| Frequency: 50 Hz–60 Hz | ||||||
| DC Output | Rail | +3.3 V | +5 V | +12 V | -12 V | +5 VSB |
| Maximum Power | 25 A | 25 A | 108 A | 0.3 A | 3 A | |
| 125 W | 1296 W | 3.6 W | 15 W | |||
| Total continuous power | 1320 W | |||||
CABLES
SSR-1300GD
| Connector | Connector count | Cable count | Cable |
|---|---|---|---|
| Main Power (24/20 pins) | 1 | 1 | ![]() |
| CPU (8/4 pins) | 2 | 2 | ![]() |
| PCIe (8/6 pins) | 12 | 0 | ![]() |
| 6 | ![]() |
||
| SATA | 12 | 3 | ![]() |
| 0 | ![]() |
||
| 0 | ![]() |
||
| 0 | ![]() |
||
| 0 | ![]() |
||
| Peripheral | 5 | 1 | ![]() |
| 1 | ![]() |
||
| Floppy | 1 | 1 | ![]() |
Nguồn máy tính SEASONIC S12II-520W
|
Mô tả chi tiết |
|
|
Thương hiệu |
SeaSonic |
|
Chủng loại |
S12II 520 Bronze |
|
Chuẩn nguồn |
ATX12V V2.3 / EPS 12V V2.91 |
|
Tiêu chuẩn chất lượng |
80 PLUS BRONZE Certified (>=89%) / Active PFC |
|
Màu sắc |
Màu Đen |
|
Công suất danh định |
520W |
|
Hỗ trợ SLI & CrossFire / Modular |
Có / Không Modular |
|
Đầu cấp điện cho main |
20+4Pin |
|
Đầu cấp điện cho hệ thống |
Chuẩn Intel Form factor ATX / 1 x cho bo mạch chủ (20+4Pin) / 1 x 4+4 Pin ATX12V / 1 x 8 Pin EPS 12V / 6 x Ổ quang / 9 x SATA / 2 x ổ mềm / 2 x PCIE 6pin + 2pin cho VGA cao cấp |
|
Quạt |
Quạt sứ 135mm Sanyo Denki của Nhật không ồn |
|
Nhà máy sản xuất (OEM) |
SeaSonic |
|
Kích cỡ nguồn |
3.4" x 5.5" x 5.9" |
|
Đường điện vào |
100 - 240 V |
|
Công suất đầu ra |
Over Voltage Protection (Bảo vệ quá tải dòng điện) / SCP (Short Circuit Protection) and OCP (Over Current Protection) / UL, FCC, TUV, CB / +3.3V@25A, +5V@25A, +12V1@63A, -12V@0.5A, +5VSB@3.0A |
Nguồn máy tính SEASONIC M12II-520W EVO
TỔNG CÔNG SUẤT: 520W
CHỨNG NHẬN: 80 PLUS®Bronze
DC OUTPUT: 12V 40A (MAX. 480W)
FAN: FDB 120mm, S2FC - điều khiển tốc độ thông minh
CÁP: dạng RỜI (toàn bộ), sợi dẹt màu đen
Active PFC Full Range: 100 ~ 240V
KÍCH THƯỚC: 150 mm (W) x 140 mm (L) x 86 mm (H)
KẾT NỐI: MB 20+4pin * 1 / CPU 4+4pin * 1 / PCI-E * 2 / SATA * 6 / Molex 4pin * 5
Nguồn máy tính SEASONIC Focus GM-750 750W 80 PLUS GOLD
| Technical Specifications | ||
|---|---|---|
| 80PLUS® | Gold | |
| Form Factor | Intel ATX 12 V | |
| Dimensions | 140 mm (L) x 150 mm (W) x 86 mm (H) | |
| Fan Information | Fan Size | 120 mm |
| Fan Control | S2FC | |
| Fan Bearing | Fluid Dynamic Bearing | |
| Life Expectancy | 50,000 hours at 40 °C, 15 % - 65 % RH | |
| Cable Information | Modularity | Semi-modular |
| Cable type | Webbed cables (attached) Flat black cables(modular) |
|
| Electrical Features | Operating Temperature | 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C) |
| MTBF @ 25 °C, excl. fan | 100,000 hours | |
| AC Input | Full Range | |
| Protection | OPP, OVP, UVP, OCP, OTP, SCP | |
| Safety and Environmental | Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, EAC, CE |
| Environmental Compliance | Energy Star, RoHS, WEEE, ErP Lot 6, REACH | |
| Warranty | 5 Years | |
| Power Output | ||||||
|---|---|---|---|---|---|---|
| AC Input | Voltage: 100 V - 240 V | |||||
| Current: 10 - 5 A | ||||||
| Frequency: 50 Hz - 60 Hz | ||||||
| DC Output | Rail | +3.3 V | +5 V | +12 V | -12 V | +5 VSB |
| Maximum Power | 20 A | 20 A | 62 A | 0.3 A | 3 A | |
| 100 W | 744 W | 3.6 W | 15 W | |||
| Total continuous power | 750 W | |||||
Nguồn máy tính SEASONIC Focus Plus GX-750 White 750W 80 PLUS GOLD
Mã hàng: SSR-750GX
Bảo hành: 60 Tháng
Hãng sản xuất: SEASONIC
TỔNG CÔNG SUẤT: 750W
CHỨNG NHẬN: 80 PLUS®Gold
DC OUTPUT: 12V 62A (MAX. 744W)
FAN: FDB 120mm, Hybrid Silent Fan Control - điều khiển tốc độ thông minh
CÁP: dạng RỜI (toàn bộ), sợi dẹt màu đen
Active PFC Full Range: 100 ~ 240V
KÍCH THƯỚC: 150 mm (W) x 140 mm (L) x 86 mm (H)
KẾT NỐI: MB 20+4pin * 1 / CPU 4+4pin * 2 / PCI-E * 4 / SATA * 8 / Molex 4pin * 3
Nguồn máy tính SEASONIC Focus Plus FM-750
SSR-750FM
| Technical Specifications | ||
|---|---|---|
| 80PLUS® | Gold | |
| Form Factor | Intel ATX 12 V | |
| Dimensions | 140 mm (W) x 150 mm (L) x 86 mm (H) | |
| Fan Information | Fan Size | 120 mm |
| Fan Control | S2FC | |
| Fan Bearing | Fluid Dynamic Bearing | |
| Life Expectancy | 50,000 hours at 40 °C, 15 % - 65 % RH | |
| Cable Information | Modularity | Semi-modular |
| Cable type | Webbed cables (attached) Flat black cables(modular) |
|
| Electrical Features | Operating Temperature | 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C) |
| MTBF @ 25 °C, excl. fan | 100,000 hours | |
| AC Input | Full Range | |
| Protection | OPP, OVP, UVP, OCP, OTP, SCP | |
| Safety and Environmental | Safety and EMC | cTUVus, TUV, CB, CCC, BSMI, EAC |
| Environmental Compliance | Energy Star, RoHS, WEEE, ErP Lot 6, REACH | |
| Warranty | 7 Years | |
| Power Output | ||||||
|---|---|---|---|---|---|---|
| AC Input | Voltage: 100 V - 240 V | |||||
| Current: 10 - 5 A | ||||||
| Frequency: 50 Hz - 60 Hz | ||||||
| DC Output | Rail | +3.3 V | +5 V | +12 V | -12 V | +5 VSB |
| Maximum Power | 20 A | 20 A | 62 A | 0.3 A | 3 A | |
| 100 W | 744 W | 3.6 W | 15 W | |||
| Total continuous power | 750 W | |||||
