Bo Mạch Chủ – Mainboard Asrock X870 Steel Legend Wifi DDR5 AM5

Liên hệ

Thông số kỹ thuật:

×

Tên thông số Giá trị
Nhà sản xuất ASRock
Model
  • X870-STEEL-LEGEND-WIFI
Mainboard Form Factor ATX
Chipset AMD X870 Chipset
Socket CPU LGA AM5
CPU Hỗ trợ
  • AMD Ryzen 7000, 8000, 9000 Series
RAM Hỗ trợ 4x DDR5 DIMM Slot
Dung lượng RAM tối đa 256GB
Khe cắm mở rộng
  • 1x PCIe 4.0 x16 slot (x4 Mode)
  • 1x PCIe 5.0 x16 (AMD Ryzen 9000 & 7000)/ PCIe 4.0 x8 slot (AMD Ryzen 8000-Phoenix 1)/ PCIe 4.0 x4 slot (AMD Ryzen 8000-Phoenix 2)
Lưu trữ mở rộng
  • 1x M.2 2280 PCIe 5.0 x4 (CPU)
  • 1x M.2 2230/2260/2280 PCIe 4.0 x4
  • 1x M.2 2260/2280 PCIe 4.0 x4
  • 4x SATA 6Gb/s
Kết nối không dây
  • 1x M.2 2230 PCle Wifi/BT Socket (Key E)
  • Wi-Fi 7
  • Bluetooth 5.4
Cổng kết nối phía sau
  • 2x Antenna Ports
  • 1x HDMI 2.1
  • 1x Optical S/PDIF Out
  • 2x Thunderbolt 4 (DisplayPort)
  • 3x USB-A 3.2 Gen 1
  • 2x USB-A 3.2 Gen 2
  • 4x USB-A 2.0
  • 1x LAN 2.5Gb
  • 1x BIOS Flashback Button
  • 2x Gold-plated audio Jack
Phụ kiện
  • 2x SATA 6Gb/s cables
  • 2x ASRock WiFi 2.4/5/6 GHz Antennas
  • 1x Thermistor Cable
Thời gian bảo hành 36 tháng
