Mainboard MSI B450M PRO-VDH MAX

Sản phẩm	Bo mạch chủ
Tên Hãng	MSI
CPU hỗ trợ	AMD
Chipset	B650
RAM hỗ trợ	4x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support DDR5 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports AMD EXPO™ Max. overclocking frequency: • 1DPC 1R Max speed up to 7200+ MHz • 1DPC 2R Max speed up to 6000+ MHz • 2DPC 1R Max speed up to 6000+ MHz • 2DPC 2R Max speed up to 5400+ MHz
Khe cắm mở rộng	1x PCI-E x16 slot • Supports x16 (For Ryzen™ 7000 Series processors) • Supports x8 (For Ryzen™ 7 8700G and Ryzen™ 5 8600G processors) • Supports x4 (For Ryzen™ 5 8500G processor) 2x PCI-E x1 slot PCI_E1 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E2 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset)
Ổ cứng hỗ trợ	2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G
Cổng kết nối (Internal)	1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 3x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 2x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports 1x USB 3.2 Gen2 Type C ports
Cổng kết nối (Back Panel)	DisplayPort 2.5G LAN USB 3.2 Gen 2 10Gbps (Type-A) USB 3.2 Gen 1 5Gbps (Type-A) Wi-Fi / Bluetooth Flash BIOS Button HDMI™ USB 3.2 Gen 2 10Gbps (Type-A) USB 3.2 Gen 2 10Gbps (Type-C) Audio connectors
LAN / Wireless	Realtek® RTL8125BG 2.5Gbps LAN AMD Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth® 5.3
Kích cỡ	mATX 243.84mmx243.84mm

Sản phẩm	Bo mạch chủ
Tên Hãng	MSI
Model	B550-A PRO
Socket	AM4
Hỗ trợ CPU	Supports 3rd Gen AMD AM4 Ryzen™ / Future AMD Ryzen™ Processors
Chipset	AMD B550
Hỗ trợ RAM	4 DIMMs, Dual Channel DDR4-4400 MHz (OC)
Cạc đồ họa	VGA onboard
Âm thanh	7.1 CH HD Audio with Content Protection (Realtek ALC1200 Audio Codec)
Cạc mạng	Realtek®  RTL8111H Gigabit LAN
Khe cắm trong	1 x M.2 Gen4 x4, 1 x M.2 Gen3 x4 slot 6x SATA 6Gb/s ports
Cổng giao tiếp ngoài	2x USB 3.2 Gen 2 10Gbps (1 Type-A + 1 Type-C) + 5x USB 3.2 Gen 1 5Gbps (4 Type-A+ 1 Type-C) + 8 x USB 2.0 DisplayPort, HDMI – Requires Processor Graphics
Kích thước	ATX
Phụ kiện kèm theo	Sách, đĩa, cáp SATA, …

Processor

Supports 2nd and 3rd Gen AMD Ryzen™ / Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics Desktop Processors for Socket AM4

See supported processors

Chipset

AMD^® X570 Chipset

Memory

• 4x DDR4 memory slots, support up to 128GB ¹
  • 3rd Gen AMD Ryzen™ Processors support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133/ 4266/ 4400/ 4533/ 4600+ Mhz by A-XMP OC MODE
  • 2nd Gen AMD Ryzen™ Processors, 1st and 2nd Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors support DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 Mhz by JEDEC, and 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466+ Mhz by A-XMP OC MODE
• Dual channel memory architecture
• Supports non-ECC UDIMM memory
• Supports ECC UDIMM memory (non-ECC mode)
• Supports un-buffered memory

1. Please refer www.msi.com for more information on compatible memory.

See supported memory

Expansion Slots

• 1x PCIe 4.0/3.0 x16 slot (PCI_E1)
  • 3rd Gen AMD Ryzen™ support PCIe 4.0 x16 mode
  • 2nd Gen AMD Ryzen™ support PCIe 3.0x16 mode
  • Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics support PCIe 3.0 x8 mode
• 1x PCIe 4.0/3.0 x16 slot (PCI_E3), supports x4 mode
• 2x PCIe 3.0 x1 slots

1. The speeds may vary for different devices

Onboard Graphics

• 1x HDMI 1.4 port, supports a maximum resolution of 4096x2160 @24Hz ^1 2

1. Only support when using Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics Processors
2. Maximum shared memory of 2048 MB

Multi-GPU

• Supports 2-Way AMD^® CrossFire™ Technology

LAN

• 1x Realtek^® 8125B 2.5Gbps LAN Controller

Wireless LAN & Bluetooth^®

Intel^® Wi-Fi 6 AX200

• Supports 802.11 a/b/g/n/ac/ax, MU-MINO Rx, 2.4GHz-5GHz (160MHz) up to 2.4Gbps
• Supports Bluetooth^® 5.1
• The Wireless module is pre-install in the M2_WIFI1 (Key-E) slot

Storage

• 6x SATA 6Gb/s ports (from AMD^® X570 Chipset)
• 2x M.2 slots (Key M) ¹
  • M2_1 slot (from AMD^® Processor)
    • Supports PCIe 4.0 x4 (3rd Gen AMD Ryzen™)
    • Supports PCIe 3.0 x4 (2nd Gen AMD Ryzen™/ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics)
    • Supports 2242/ 2260/ 2280/ 22110 storage devices
  • M2_2 slot (from AMD^® X570 Chipset)
    • Supports PCIe 4.0 x4 (3rd Gen AMD Ryzen™)
    • Supports PCIe 3.0 x4 (2nd Gen AMD Ryzen™/ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics)
    • Supports SATA 6Gb/s
    • Supports 2242/ 2260/ 2280 storage devices

1. The speeds may vary for different devices

RAID

• Supports RAID 0, RAID 1 and RAID 10

USB

AMD^® X570 Chipset

• 3x USB 3.2 Gen 2 10Gbps ports (2 Type-A ports on the back panel, 1 Type-C internal connector)
• 4x USB 3.2 Gen 1 5Gbps ports available through the internal USB 3.2 Gen 1 5Gbps connectors
• 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports available through the internal USB 2.0 connectors)

AMD^® Processor

• 2x USB 3.2 Gen 2 10Gbps (3rd Gen AMD Ryzen™) or USB 3.2 Gen 1 5Gbps (2nd Gen AMD Ryzen™/ Ryzen™ with Radeon™ Vega Graphics and 2nd Gen AMD Ryzen™ with Radeon™ Graphics) ports (1x Type-A & 1x Type-C) on the back panel
• 2x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel

Audio

Realtek^® ALC1200 Codec

• 7.1-Channel High Definition Audio
• Supports Optical S/PDIF output

Internal connectors

• 1x 24-pin ATX main power connector
• 1x 8-pin ATX 12V power connector
• 1x 4-pin ATX 12V power connector
• 6x SATA 6Gb/s connectors
• 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
• 2x USB 3.2 Gen 1 5Gbps connectors (supports additional 4 USB 3.2 Gen 1 5Gbps ports)
• 1x USB 3.2 Gen 2 10Gbps Type-C Port
• 1x 4-pin CPU fan connector
• 1x 4-pin water-pump connector
• 4x 4-pin system fan connectors
• 1x Front panel audio connector
• 2x System panel connectors
• 1x TPM module connector
• 1x Serial port connector
• 1x Clear CMOS jumper
• 1x Chassis Intrusion connector
• 2x 4-pin RGB LED connectors
• 2x 3-pin RAINBOW LED connectors
• 4x EZ Debug LEDs

Back panel ports

1. Keyboard / Mouse
2. Wireless / Bluetooth
3. USB 3.2 Gen 1 5Gbps Type A
4. USB 3.2 Gen 2 10Gbps Type A
5. 2.5G LAN port
6. Audio Connectors
7. Flash BIOS button
8. USB 2.0
9. HDMI port
10. USB 3.2 Gen 2 10Gbps Type C
11. USB 3.2 Gen 2 10Gbps Type A
12. Optical S/PDIF out

I/O Controller

• NUVOTON NCT6797 Controller Chip

Hardware Monitor

• CPU/ System/ Chipset temperature detection
• CPU/ System/ Chipset fan speed detection
• CPU/ System/ Chipset fan speed control

BIOS Features

• 1x 256 Mb flash
• UEFI AMI BIOS
• ACPI 6.1, SM BIOS 2.8
• Multi-language

Form Factor

• ATX Form Factor
• 12 in. x 9.6 in. (30.5 cm x 24.4 cm)

Box content

• Thương hiệu: MSI
• Bảo hành: 36 tháng
• Tên sản phẩm: B550M PRO
• CPU hỗ trợ: Ryzen Gen 3, Ryzen 4000 G-Series
• Socket: AM4
• Kích thước: M-ATX
• Chipset: AMD B550
• Loại ram: DDR4, Dual
• Số khe ram: 2 Slost
• Bus ram hỗ trợ: 1866/2333/2400/…/ 4400 / 4600+ MHz bởi A-XMP OC Mode
• Bộ nhớ tối đa: 64GB
• Khe PCI-E X16: 1 Slost
• Thế hệ PCI-E: Gen4 / Gen3
• Khe PCI-E X1: 2 Slost
• Khe ổ cứng SATAIII: 4 Slost
• Khe ổ cứng: M.2: 1 Slost
• Raid: 0/1/10
• Lan: Realtek RTL8111H Gigabit LAN
• Cổng USB 3.2: 2 (Gen 1, Loại A)
• Cổng USB 3.2: 4 (Gen 1, Loại A)
• Cổng USB 2.0: 4 Slost
• Cổng USB 2.0: 2 Slost
• Cổng nối tiếp:1 Slost
• Cổng âm thanh: Realtek ALC892 / ALC897
• Xuất màn hình: 1 x Displayport / 1 x Vga / 1 x HDMI
• Hỗ trợ Directx: 12
• Hệ điều hành: Hỗ trợ cho Windows 10 64-bit
