Bo Mạch Chủ - Mainboard Gigabyte B650 AORUS ELITE AX

Bo Mạch Chủ – Mainboard Gigabyte B650 AORUS ELITE AX

  • CPU

    1. AMD Socket AM5, support for: AMD Ryzen™ 7000 Series Processors
    (Please refer "CPU Support List" for more information.)

  • Chipset

    1. AMD B650

  • Memory

    1. Support for DDR5 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MHz memory modules
    2. 4 x DDR5 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
    3. Dual channel memory architecture
    4. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    5. Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory module
    (Please refer "Memory Support List" for more information.)

  • Onboard Graphics

    Integrated Graphics Processor:
    1. 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz
      * Support for DisplayPort 1.4 version and HDR.
    2. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
      * Support for HDMI 2.1 version and HDCP 2.3.
      ** Support native HDMI 2.1 TMDS compatible ports.
    (Graphics specifications may vary depending on CPU support.)

  • Audio

    1. Realtek® Audio CODEC
    2. High Definition Audio
    3. 2/4/5.1/7.1-channel
      * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.

  • LAN

    1. Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

  • Wireless Communication module

    AMD Wi-Fi 6E RZ616 (MT7922A22M) (For PCB rev. 1.0)
    1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
    2. BLUETOOTH 5.2
    3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
    Intel® Wi-Fi 6E AX210 (For PCB rev. 1.1)
    1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
    2. BLUETOOTH 5.3
    3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
    (Actual data rate may vary depending on environment and equipment.)

  • Expansion Slots

    CPU:
    1. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)
      * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
    Chipset:
    1. 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1/2)

  • Storage Interface

    CPU:
    1. 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 5.0* x4/x2 SSD support) (M2A_CPU)
      * Actual support may vary by CPU.
    2. 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU)
    Chipset:
    1. 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD support) (M2C_SB)
    2. 4 x SATA 6Gb/s connectors
    RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
    RAID 0, RAID 1, and RAID 10 support for SATA storage devices

  • USB

    CPU:
    1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support
    2. 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
    CPU + USB 2.0 Hub:
    1. 4 x USB 2.0/1.1 ports on the back panel
    Chipset:
    1. 1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header
    2. 3 x USB 3.2 Gen 1 ports (1 port on the back panel, 2 ports available through the internal USB header)
    3. 4 x USB 2.0/1.1 ports available through the internal USB headers
    Chipset+USB 3.2 Gen 1 Hub:
    1. 4 x USB 3.2 Gen 1 ports on the back panel

  • Internal I/O Connectors

    1. 1 x 24-pin ATX main power connector
    2. 1 x 8-pin ATX 12V power connector
    3. 1 x 4-pin ATX 12V power connector
    4. 1 x CPU fan header
    5. 1 x water cooling CPU fan header
    6. 3 x system fan headers
    7. 1 x system fan/water cooling pump header
    8. 2 x addressable LED strip headers
    9. 2 x RGB LED strip headers
    10. 1 x CPU cooler LED strip/RGB LED strip header
    11. 3 x M.2 Socket 3 connectors
    12. 4 x SATA 6Gb/s connectors
    13. 1 x front panel header
    14. 1 x front panel audio header
    15. 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
    16. 1 x USB 3.2 Gen 1 header
    17. 2 x USB 2.0/1.1 headers
    18. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
    19. 1 x reset button
    20. 1 x reset jumper
    21. 1 x Clear CMOS jumper

  • Back Panel Connectors

    1. 1 x Q-Flash Plus button
    2. 2 x SMA antenna connectors (2T2R)
    3. 1 x DisplayPort
    4. 1 x HDMI port
    5. 1 x USB Type-C® port, with USB 3.2 Gen 2 support
    6. 2 x USB 3.2 Gen 2 Type-A ports (red)
    7. 5 x USB 3.2 Gen 1 ports
    8. 4 x USB 2.0/1.1 ports
    9. 1 x RJ-45 port
    10. 3 x audio jacks

  • I/O Controller

    1. iTE® I/O Controller Chip

  • H/W Monitoring

    1. Voltage detection
    2. Temperature detection
    3. Fan speed detection
    4. Water cooling flow rate detection
    5. Fan fail warning
    6. Fan speed control
      * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.

  • BIOS

    1. 1 x 256 Mbit flash
    2. Use of licensed AMI UEFI BIOS
    3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

  • Unique Features

    1. Support for GIGABYTE Control Center (GCC)
      * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
    2. Support for Q-Flash
    3. Support for Q-Flash Plus

  • Bundled Software

    1. Norton® Internet Security (OEM version)
    2. LAN bandwidth management software

  • Operating System

    1. Support for Windows 11 64-bit
    2. Support for Windows 10 64-bit

  • Form Factor

    1. ATX Form Factor; 30.5cm x 24.4cm

Bo Mạch Chủ – Mainboard Gigabyte B650 AORUS ELITE AX

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte B650M AORUS ELITE

Bo Mạch Chủ – Mainboard Gigabyte B650M AORUS ELITE

  • CPU

    1. AMD Socket AM5, support for: AMD Ryzen™ 7000 Series Processors
    (Please refer "CPU Support List" for more information.)

  • Chipset

    1. AMD B650

  • Bộ nhớ

    1. Support for DDR5 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MHz memory modules
    2. 4 x DDR5 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
    3. Dual channel memory architecture
    4. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    5. Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules
    (Please refer "Memory Support List" for more information.)

  • Card đồ họa tích hợp

    Integrated Graphics Processor:
    1. 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz
      * Support for DisplayPort 1.4 version and HDR.
    2. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
      * Support for HDMI 2.1 version and HDCP 2.3.
      ** Support native HDMI 2.1 TMDS compatible ports.
    (Graphics specifications may vary depending on CPU support.)

  • Âm thanh

    1. Realtek® Audio CODEC
    2. High Definition Audio
    3. 2/4/5.1/7.1-channel
      * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
    4. Support for S/PDIF Out

  • LAN

    1. Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

  • Khe cắm mở rộng

    CPU:
    1. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)
      * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
    Chipset:
    1. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)

  • Giao diện lưu trữ

    CPU:
    1. 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 5.0* x4/x2 SSD support) (M2A_CPU)
      * Actual support may vary by CPU.
    2. 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU)
    Chipset:
    1. 4 x SATA 6Gb/s connectors
    RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
    RAID 0, RAID 1, and RAID 10 support for SATA storage devices

  • USB

    CPU:
    1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support
    2. 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
    CPU + USB 2.0 Hub:
    1. 4 x USB 2.0/1.1 ports on the back panel
    Chipset:
    1. 1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header
    2. 3 x USB 3.2 Gen 1 ports (1 port on the back panel, 2 ports available through the internal USB header)
    3. 4 x USB 2.0/1.1 ports available through the internal USB headers
    Chipset+USB 3.2 Gen 1 Hub:
    1. 4 x USB 3.2 Gen 1 ports on the back pane

  • Kết nối I/O bên trong

    1. 1 x 24-pin ATX main power connector
    2. 1 x 8-pin ATX 12V power connector
    3. 1 x CPU fan header
    4. 1 x water cooling CPU fan header
    5. 3 x system fan headers
    6. 1 x system fan/water cooling pump header
    7. 2 x addressable LED strip headers
    8. 2 x RGB LED strip headers
    9. 1 x CPU cooler LED strip/RGB LED strip header
    10. 2 x M.2 Socket 3 connectors
    11. 4 x SATA 6Gb/s connectors
    12. 1 x front panel header
    13. 1 x front panel audio header
    14. 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
    15. 1 x USB 3.2 Gen 1 header
    16. 2 x USB 2.0/1.1 headers
    17. 1 x serial port header
    18. 1 x THB_U4 add-in card connector
    19. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
    20. 1 x reset button
    21. 1 x reset jumper
    22. 1 x Clear CMOS jumper

  • Kết nối bảng phía sau

    1. 1 x Q-Flash Plus button
    2. 1 x DisplayPort
    3. 1 x HDMI 2.0 port
    4. 1 x USB Type-C® port, with USB 3.2 Gen 2 support
    5. 2 x USB 3.2 Gen 2 Type-A ports (red)
    6. 5 x USB 3.2 Gen 1 ports
    7. 4 x USB 2.0/1.1 ports
    8. 1 x RJ-45 port
    9. 1 x optical S/PDIF Out connector
    10. 2 x audio jacks

  • Điều khiển I/O

    1. iTE® I/O Controller Chip

  • Theo dõi phần cứng

    1. Voltage detection
    2. Temperature detection
    3. Fan speed detection
    4. Water cooling flow rate detection
    5. Fan fail warning
    6. Fan speed control
      * Whether the fan (pump) speed control function is supported will depend on the fan(pump) you install.

  • BIOS

    1. 1 x 256 Mbit flash
    2. Use of licensed AMI UEFI BIOS
    3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

  • Tính năng duy nhất

    1. Support for GIGABYTE Control Center (GCC)
      * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
    2. Support for Q-Flash
    3. Support for Q-Flash Plus

  • Gói phần mềm

    1. Norton® Internet Security (OEM version)
    2. LAN bandwidth management software

  • Hệ điều hành

    1. Support for Windows 11 64-bit
    2. Support for Windows 10 64-bit

  • Hệ số khuôn

    1. Micro ATX Form Factor; 24.4cm x 24.4cm

Bo Mạch Chủ – Mainboard Gigabyte B650M AORUS ELITE

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte B650M AORUS ELITE AX

Bo Mạch Chủ – Mainboard Gigabyte B650M AORUS ELITE AX

  • CPU

    1. AMD Socket AM5, support for: AMD Ryzen™ 7000 Series Processors
    (Please refer "CPU Support List" for more information.)

  • Chipset

    1. AMD B650

  • Bộ nhớ

    1. Support for DDR5 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MHz memory modules
    2. 4 x DDR5 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
    3. Dual channel memory architecture
    4. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    5. Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules
    (Please refer "Memory Support List" for more information.)

  • Card đồ họa tích hợp

    Integrated Graphics Processor:
    1. 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz
      * Support for DisplayPort 1.4 version and HDR.
    2. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
      * Support for HDMI 2.1 version and HDCP 2.3.
      ** Support native HDMI 2.1 TMDS compatible ports.
    (Graphics specifications may vary depending on CPU support.)

  • Âm thanh

    1. Realtek® Audio CODEC
    2. High Definition Audio
    3. 2/4/5.1/7.1-channel
      * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
    4. Support for S/PDIF Out

  • LAN

    1. Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

  • Wireless Communication module

    AMD Wi-Fi 6E RZ616 (MT7922A22M) (For PCB rev. 1.0)
    1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
    2. BLUETOOTH 5.2
    3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
    Intel® Wi-Fi 6E AX210 (For PCB rev. 1.1)
    1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
    2. BLUETOOTH 5.3
    3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
    (Actual data rate may vary depending on environment and equipment.)

  • Khe cắm mở rộng

    CPU:
    1. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)
      * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
    Chipset:
    1. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)

  • Giao diện lưu trữ

    CPU:
    1. 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 5.0* x4/x2 SSD support) (M2A_CPU)
      * Actual support may vary by CPU.
    2. 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU)
    Chipset:
    1. 4 x SATA 6Gb/s connectors
    RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
    RAID 0, RAID 1, and RAID 10 support for SATA storage devices

  • USB

    CPU:
    1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support
    2. 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
    CPU + USB 2.0 Hub:
    1. 4 x USB 2.0/1.1 ports on the back panel
    Chipset:
    1. 1 x USB Type-C® port with USB 3.2 Gen 2x2 support, available through the internal USB header
    2. 3 x USB 3.2 Gen 1 ports (1 port on the back panel, 2 ports available through the internal USB header)
    3. 4 x USB 2.0/1.1 ports available through the internal USB headers
    Chipset+USB 3.2 Gen 1 Hub:
    1. 4 x USB 3.2 Gen 1 ports on the back pane

  • Kết nối I/O bên trong

    1. 1 x 24-pin ATX main power connector
    2. 1 x 8-pin ATX 12V power connector
    3. 1 x CPU fan header
    4. 1 x water cooling CPU fan header
    5. 3 x system fan headers
    6. 1 x system fan/water cooling pump header
    7. 2 x addressable LED strip headers
    8. 2 x RGB LED strip headers
    9. 1 x CPU cooler LED strip/RGB LED strip header
    10. 2 x M.2 Socket 3 connectors
    11. 4 x SATA 6Gb/s connectors
    12. 1 x front panel header
    13. 1 x front panel audio header
    14. 1 x USB Type-C® header, with USB 3.2 Gen 2x2 support
    15. 1 x USB 3.2 Gen 1 header
    16. 2 x USB 2.0/1.1 headers
    17. 1 x serial port header
    18. 1 x THB_U4 add-in card connector
    19. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
    20. 1 x reset button
    21. 1 x reset jumper
    22. 1 x Clear CMOS jumper

  • Kết nối bảng phía sau

    1. 1 x Q-Flash Plus button
    2. 2 x SMA antenna connectors (2T2R)
    3. 1 x DisplayPort
    4. 1 x HDMI 2.0 port
    5. 1 x USB Type-C® port, with USB 3.2 Gen 2 support
    6. 2 x USB 3.2 Gen 2 Type-A ports (red)
    7. 5 x USB 3.2 Gen 1 ports
    8. 4 x USB 2.0/1.1 ports
    9. 1 x RJ-45 port
    10. 1 x optical S/PDIF Out connector
    11. 2 x audio jacks

  • Điều khiển I/O

    1. iTE® I/O Controller Chip

  • Theo dõi phần cứng

    1. Voltage detection
    2. Temperature detection
    3. Fan speed detection
    4. Water cooling flow rate detection
    5. Fan fail warning
    6. Fan speed control
      * Whether the fan (pump) speed control function is supported will depend on the fan(pump) you install.

  • BIOS

    1. 1 x 256 Mbit flash
    2. Use of licensed AMI UEFI BIOS
    3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

  • Tính năng duy nhất

    1. Support for GIGABYTE Control Center (GCC)
      * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
    2. Support for Q-Flash
    3. Support for Q-Flash Plus

  • Gói phần mềm

    1. Norton® Internet Security (OEM version)
    2. LAN bandwidth management software

  • Hệ điều hành

    1. Support for Windows 11 64-bit
    2. Support for Windows 10 64-bit

  • Hệ số khuôn

    1. Micro ATX Form Factor; 24.4cm x 24.4cm

Bo Mạch Chủ – Mainboard Gigabyte B650M AORUS ELITE AX

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte B650M GAMING PLUS WIFI DDR5

Bo Mạch Chủ – Mainboard Gigabyte B650M GAMING PLUS WIFI DDR5

Hãng sản xuất Gigabyte
Chipset AMD B650
Socket AM5
RAM DDR5 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/4800/4400 MT/s
Hỗ trợ tối đa RAM 256 GB (64 GB mỗi DIMM)
Khe cắm PCI-E 1 x PCI Express x16 (PCIe 4.0), 1 x PCI Express x1 (PCIe 3.0)
Kết nối 1 x M.2 (PCIe 4.0 x4), 4 x SATA 6Gb/s
Khe cắm M.2 1 x M.2 PCIe 4.0 x4
Âm thanh Realtek® Audio CODEC, Âm thanh HD 2/4/5.1/7.1 kênh
Mạng Realtek® 2.5GbE LAN, Realtek® Wi-Fi 6E RTL8852CE (2.4/5/6 GHz), Realtek® Wi-Fi 6 RTL 8851BE (2.4/5 GHz) Bluetooth 5.3
Cổng I/O 1 x PS/2, 1 x USB Type-C®, 3 x USB 3.2 Gen 1, 2 x USB 2.0, 1 x HDMI, 2 x DisplayPorts, 1 x RJ-45 (LAN), 3 x jack âm thanh, 2 x SMA antenna
Kích thước Micro ATX Form Factor; 24.4cm x 24.4cm
Trọng lượng -
Tính năng khác Hỗ trợ GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus

Bo Mạch Chủ – Mainboard Gigabyte B650M GAMING PLUS WIFI DDR5

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte B650M GAMING X AX

Bo Mạch Chủ – Mainboard Gigabyte B650M GAMING X AX

  • CPU

    1. AMD Socket AM5, support for: AMD Ryzen™ 7000 Series Processors
    (Please refer "CPU Support List" for more information.)

  • Chipset

    1. AMD B650

  • Memory

    1. Support for DDR5 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules
    2. 4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory
    3. Dual channel memory architecture
    4. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    5. Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules
    (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.)

  • Onboard Graphics

    Integrated Graphics Processor:
    1. 2 x DisplayPorts, supporting a maximum resolution of 3840x2160@144 Hz
      * Support for DisplayPort 1.4 version.
    2. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
      * Support for HDMI 2.1 version and HDCP 2.3.
      ** Support native HDMI 2.1 TMDS compatible ports.
    (Graphics specifications may vary depending on CPU support.)

    Support for up to 3 displays at the same time

  • Audio

    1. Realtek® Audio CODEC
    2. High Definition Audio
    3. 2/4/5.1/7.1-channel
      * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.

  • LAN

    1. Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

  • Wireless Communication module

    AMD Wi-Fi 6E RZ616 (MT7922A22M) (For PCB rev. 1.0/1.2)
    1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
    2. BLUETOOTH 5.2
    3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
    Intel® Wi-Fi 6E AX210 (For PCB rev. 1.1)
    1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
    2. BLUETOOTH 5.3
    3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
    (Actual data rate may vary depending on environment and equipment.)

  • Expansion Slots

    CPU:
    1. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)
    Chipset:
    1. 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 (PCIEX1)

  • Storage Interface

    CPU:
    1. 2 x M.2 connectors (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD support)
    Chipset:
    1. 4 x SATA 6Gb/s connectors
    RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices
    RAID 0, RAID 1, and RAID 10 support for SATA storage devices

  • USB

    CPU:
    1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support
    2. 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
    CPU + USB 2.0 Hub:
    1. 4 x USB 2.0/1.1 ports on the back panel
    Chipset:
    1. 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
    2. 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
    3. 4 x USB 2.0/1.1 ports available through the internal USB headers

  • Internal I/O Connectors

    1. 1 x 24-pin ATX main power connector
    2. 1 x 8-pin ATX 12V power connector
    3. 1 x CPU fan header
    4. 3 x system fan headers
    5. 1 x addressable LED strip header
    6. 1 x RGB LED strip header
    7. 2 x M.2 Socket 3 connectors
    8. 4 x SATA 6Gb/s connectors
    9. 1 x front panel header
    10. 1 x front panel audio header
    11. 1 x USB Type-C® header, with USB 3.2 Gen 2 support
    12. 1 x USB 3.2 Gen 1 header
    13. 2 x USB 2.0/1.1 headers
    14. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
    15. 1 x serial port header
    16. 1 x reset button
    17. 1 x reset jumper
    18. 1 x Clear CMOS jumper

  • Back Panel Connectors

    1. 4 x USB 2.0/1.1 ports
    2. 1 x PS/2 keyboard/mouse port
    3. 2 x SMA antenna connectors (2T2R)
    4. 2 x DisplayPorts
    5. 1 x HDMI port
    6. 1 x USB 3.2 Gen 2 Type-A port (red)
    7. 1 x USB Type-C® port, with USB 3.2 Gen 2 support
    8. 1 x Q-Flash Plus button
    9. 1 x RJ-45 port
    10. 2 x USB 3.2 Gen 1 ports
    11. 3 x audio jacks

  • I/O Controller

    1. iTE® I/O Controller Chip

  • H/W Monitoring

    1. Voltage detection
    2. Temperature detection
    3. Fan speed detection
    4. Fan fail warning
    5. Fan speed control
      * Whether the fan speed control function is supported will depend on the cooler you install.

  • BIOS

    1. 1 x 256 Mbit flash
    2. Use of licensed AMI UEFI BIOS
    3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

  • Unique Features

    1. Support for GIGABYTE Control Center (GCC)
      * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
    2. Support for Q-Flash
    3. Support for Q-Flash Plus

  • Bundled Software

    1. Norton® Internet Security (OEM version)
    2. LAN bandwidth management software

  • Operating System

    1. Support for Windows 11 64-bit
    2. Support for Windows 10 64-bit

  • Form Factor

    1. Micro ATX Form Factor; 24.4cm x 24.4cm

Bo Mạch Chủ – Mainboard Gigabyte B650M GAMING X AX

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte B760M GAMING WIFI6 PLUS GEN5

Bo Mạch Chủ – Mainboard Gigabyte B760M GAMING WIFI6 PLUS GEN5

  • CPU
    LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors
    (Go to GIGABYTE's website for the latest CPU support list.)
    L3 cache varies with CPU
  • Chipset
    Intel® B760 Express Chipset
  • Bộ nhớ
    Support for DDR5 8000(O.C.) /7800(O.C.) /7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules
    2 x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity) of system memory
    Dual channel memory architecture
    Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
    Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    Support for Extreme Memory Profile (XMP) memory modules
    (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.)
  • Card đồ họa tích hợp
    Integrated Graphics Processor-Intel® HD Graphics support:
    - 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
    - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

    * Support for HDMI 2.1 version and HDCP 2.3.
    ** Support for native HDMI 2.1 TMDS compatible ports.


    - 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz

    * Support for DisplayPort 1.2 version and HDCP 2.3


    (Graphics specifications may vary depending on CPU support.)
    Support for up to triple-display at the same time
  • Âm thanh
    Realtek® Audio CODEC
    High Definition Audio
    2/4/5.1/7.1-channel

    * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.


    Support for S/PDIF Out
  • LAN
    Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
  • Wireless Communication module
    Realtek® Wi-Fi 6 RTL8851BE
    - WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands
    - BLUETOOTH 5.3
    - Support for 11ax 80MHz wireless standard
    (Actual data rate may vary depending on environment and equipment.)
  • Khe cắm mở rộng
    CPU:
    - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16

    * The PCIEX16 slot can only support a graphics card or an NVMe SSD.


    Chipset:
    - 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
  • Giao diện lưu trữ
    CPU:
    - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
    Chipset:
    - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB)
    - 4 x SATA 6Gb/s connectors
    RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
  • USB
    Chipset:
    - 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 1 support
    - 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header)
    - 2 x USB 2.0/1.1 ports on the back panel
    Chipset+USB 2.0 Hub:
    - 4 x USB 2.0/1.1 ports available through the internal USB headers
  • Kết nối I/O bên trong
    1 x 24-pin ATX main power connector
    1 x 8-pin ATX 12V power connector
    1 x CPU fan header
    3 x system fan headers
    2 x addressable RGB Gen2 LED strip headers
    1 x RGB LED strip header
    2 x M.2 Socket 3 connectors
    4 x SATA 6Gb/s connectors
    1 x front panel header
    1 x front panel audio header
    1 x S/PDIF Out header
    1 x USB 3.2 Gen 1 header
    2 x USB 2.0/1.1 headers
    1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
    1 x serial port header
    1 x Q-Flash Plus button
    1 x reset jumper
    1 x Clear CMOS jumper
  • Kết nối bảng phía sau
    2 x USB 2.0/1.1 ports
    1 x PS/2 keyboard/mouse port
    2 x antenna connectors (1T1R)
    1 x D-Sub port (Note)
    1 x HDMI port (Note)
    1 x DisplayPort (Note)
    3 x USB 3.2 Gen 1 ports
    1 x USB Type-C® port, with USB 3.2 Gen 1 support
    1 x RJ-45 port
    3 x audio jacks

    (Note) Actual support may vary by CPU.
  • Điều khiển I/O
    iTE® I/O Controller Chip
  • Theo dõi phần cứng
    Voltage detection
    Temperature detection
    Fan speed detection
    Water cooling flow rate detection
    Fan fail warning
    Fan speed control

    * Whether the fan speed control function is supported will depend on the fan you install.

  • BIOS
    1 x 128 Mbit flash
    Use of licensed AMI UEFI BIOS
    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
  • Tính năng duy nhất
    Support for GIGABYTE Control Center (GCC)

    * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.


    Support for Q-Flash
    Support for Q-Flash Plus
    Support for Smart Backup
  • Gói phần mềm
    Norton® Internet Security (OEM version)
  • Hệ điều hành
    Support for Windows 11 64-bit
    Support for Windows 10 64-bit
  • Hệ số khuôn
    Micro ATX Form Factor; 24.4cm x 22.5cm

Bo Mạch Chủ – Mainboard Gigabyte B760M GAMING WIFI6 PLUS GEN5

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte B85M-D2V Renew CTY BH 36 Tháng

Bo Mạch Chủ – Mainboard Gigabyte B85M-D2V Renew CTY BH 36 Tháng

CPU

Hỗ trợ bộ xử lý Intel® Core ™ i7 / Bộ xử lý Intel® Core ™ i5 / Bộ xử lý Intel® Core ™ i3 / Bộ xử lý Intel® Pentium® / Bộ xử lý Intel® Celeron® trong gói LGA1150

Bộ đệm L3 thay đổi theo CPU

Chipset

Chipset Intel® B85 Express

Bộ nhớ

Ổ cắm DIMM 2 x 1,5V DDR3 hỗ trợ bộ nhớ hệ thống lên đến 16 GB
* Do giới hạn hệ điều hành Windows 32 bit, khi cài đặt hơn 4 GB bộ nhớ vật lý, kích thước bộ nhớ thực được hiển thị sẽ nhỏ hơn kích thước của bộ nhớ vật lý được cài đặt.

Kiến trúc bộ nhớ kênh đôi

Hỗ trợ cho các mô-đun bộ nhớ DDR3 1600/1333 MHz

Hỗ trợ cho các mô-đun bộ nhớ không ECC

Hỗ trợ cho các mô-đun bộ nhớ Extreme Memory Profile (XMP)

(Vui lòng tham khảo “Danh sách hỗ trợ bộ nhớ” để biết thêm thông tin.)

Card đồ họa tích hợp

Bộ xử lý đồ họa tích hợp – Hỗ trợ đồ họa HD Intel®:

Cổng 1 x D-Sub, hỗ trợ độ phân giải tối đa 1920×1200

Cổng 1 x DVI-D, hỗ trợ độ phân giải tối đa 1920×1200
* Cổng DVI-D không hỗ trợ kết nối D-Sub bằng bộ chuyển đổi.

Bộ nhớ chia sẻ tối đa 1 GB

Âm thanh

Bộ giải mã Realtek® ALC887

Âm thanh độ nét cao

2/4 / 5.1 / 7.1-kênh
* Để định cấu hình âm thanh 7.1 kênh, bạn phải sử dụng mô-đun âm thanh bảng mặt trước HD và bật tính năng âm thanh đa kênh thông qua trình điều khiển âm thanh.

Mạng LAN

Chip LAN Realtek® GbE (10/100/1000 Mbit)

Khe cắm mở rộng

1 x khe cắm PCI Express x16, chạy ở x16
(Khe cắm PCI Express x16 phù hợp với tiêu chuẩn PCI Express 3.0.)

2 khe cắm PCI Express x1
(Tất cả các khe cắm PCI Express x1 phù hợp với tiêu chuẩn PCI Express 2.0.)

Giao diện lưu trữ

Chipset:

4 x Đầu nối SATA 6Gb / s (SATA3 0 ~ SATA3 3)

2 x đầu nối SATA 3Gb / s (SATA2 4 ~ SATA2 5)

USB

Chipset:

4 cổng USB 3.0 / 2.0 (2 cổng ở mặt sau, 2 cổng có sẵn thông qua tiêu đề USB bên trong)

8 cổng USB 2.0 / 1.1 (4 cổng ở mặt sau, 4 cổng có sẵn thông qua các tiêu đề USB bên trong)

Kết hợp I / O bên trong

Đầu nối nguồn chính 1 x 24 chân ATX

Đầu nối nguồn 1 x 8 chân ATX 12V

Đầu nối 4 x SATA 6Gb / s

2 x kết nối SATA 3Gb / s

1 x tiêu đề quạt CPU

1 x tiêu đề quạt hệ thống

1 x tiêu đề bảng mặt trước

1 x tiêu đề bảng điều khiển phía trước

1 x USB 3.0 / 2.0 tiêu đề

2 x USB 2.0 / 1.1 tiêu đề

1 x tiêu đề cổng nối tiếp

1 x nhảy CMOS rõ ràng

Kết cấu

1 cổng PS / 2 bàn phím

1 cổng PS / 2 chuột

1 x cổng D-Sub

Cổng 1 x DVI-D

2 cổng USB 3.0 / 2.0

4 cổng USB 2.0 / 1.1

1 x cổng RJ-45

3 x jack âm thanh (Line In, Line Out, Mic In)

Điều khiển I/O

Chip điều khiển I / O iTE®

Theo phần mềm

Phát hiện điện áp hệ thống

Phát hiện nhiệt độ CPU / hệ thống

Phát hiện tốc độ quạt CPU / hệ thống

Cảnh báo CPU / hệ thống quá nóng

Cảnh báo lỗi CPU / hệ thống quạt

Điều khiển tốc độ quạt CPU / hệ thống
* Chức năng điều khiển tốc độ quạt có được hỗ trợ hay không sẽ phụ thuộc vào bộ làm mát bạn cài đặt.

BIOS

Đèn flash 2 x 32 Mbit

Sử dụng BIOS AMI EFI được cấp phép

Hỗ trợ cho DualBIOS ™

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Tính năng duy nhất

Hỗ trợ cho Q-Flash

Hỗ trợ cài đặt Xpress

Hỗ trợ cho Trung tâm APP
* Các ứng dụng có sẵn trong Trung tâm APP có thể khác nhau tùy theo mẫu bo mạch chủ. Các chức năng được hỗ trợ của từng ứng dụng cũng có thể khác nhau tùy thuộc vào thông số kỹ thuật của bo mạch chủ.
@ NOSOS
EasyTune
Cài đặt EZ
Trình chặn USB
Khóa thời gian thông minh
Phục hồi thông minh 2

Hỗ trợ cho phí BẬT / TẮT

Gói phần mềm

Norton® Internet Security (phiên bản OEM)

Công nghệ khởi động nhanh Intel®

Công nghệ kết nối thông minh Intel®

Hệ điều hành

Hỗ trợ cho Windows 10 / 8.1 / 8/7

Hệ số khuôn

Yếu tố hình thức Micro ATX; 22,6cm x 17,4cm



Bo Mạch Chủ – Mainboard Gigabyte B85M-D2V Renew CTY BH 36 Tháng

Liên hệ
Bo Mạch Chủ - MAINBOARD GIGABYTE B860M DS3H DDR5

Bo Mạch Chủ – MAINBOARD GIGABYTE B860M DS3H DDR5

  • CPU
    LGA1851 socket: Support for Intel® Core™ Ultra Processors
    (Go to GIGABYTE's website for the latest CPU support list.)
    L3 cache varies with CPU
  • Chipset
    Intel® B860 Express Chipset
  • Bộ nhớ
    Support for DDR5 9066(O.C)/8800(O.C) /8600(O.C) / 8400(O.C) /8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) /6400/5600 MT/s memory modules
    4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory
    Dual channel memory architecture
    Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
    Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    Support for Extreme Memory Profile (XMP) memory modules
    (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.)
  • Card đồ họa tích hợp
    Integrated Graphics Processor-Intel® HD Graphics support:
    - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

    * Support for HDMI 2.1 version and HDCP 2.3.


    - 2 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz

    * Support for DisplayPort 2.1 version.


    (Graphics specifications may vary depending on CPU support.)
    Support for up to triple-display at the same time
  • Âm thanh
    Realtek® Audio CODEC
    High Definition Audio
    2/4/5.1/7.1-channel

    * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.

  • LAN
    Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
  • Khe cắm mở rộng
    CPU:
    - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)

    * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.


    Chipset:
    - 2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x1 (PCIEX1_2/3)
  • Giao diện lưu trữ
    CPU:
    - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 5.0 x4/x2 SSD support) (M2A_CPU)
    Chipset:
    - 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2N_SB)
    - 4 x SATA 6Gb/s connectors
    RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
  • USB
    Chipset:
    - 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header
    - 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
    - 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
    - 3 x USB 2.0/1.1 ports on the back panel
    Chipset+USB 2.0 Hub:
    - 4 x USB 2.0/1.1 ports available through the internal USB headers
  • Kết nối I/O bên trong
    1 x 24-pin ATX main power connector
    1 x 8-pin ATX 12V power connector
    1 x CPU fan header
    1 x CPU fan/water cooling pump header
    1 x system fan header
    1 x system fan/water cooling pump header
    3 x addressable RGB Gen2 LED strip headers
    1 x RGB LED strip header
    2 x M.2 Socket 3 connectors
    4 x SATA 6Gb/s connectors
    1 x front panel header
    1 x front panel audio header
    1 x USB Type-C® header, with USB 3.2 Gen 1 support
    1 x USB 3.2 Gen 1 header
    2 x USB 2.0/1.1 headers
    1 x Trusted Platform Module header (For the GC-TPM2.0 SPI V2 module only)
    1 x Q-Flash Plus button
    1 x reset jumper
    1 x Clear CMOS jumper
  • Kết nối bảng phía sau
    1 x PS/2 keyboard/mouse port
    1 x HDMI port (Note)
    2 x DisplayPorts (Note)
    1 x USB 3.2 Gen 2 Type-A port (red)
    2 x USB 3.2 Gen 1 ports
    3 x USB 2.0/1.1 ports
    1 x RJ-45 port
    3 x audio jacks

    (Note) Actual support may vary by CPU.
  • Điều khiển I/O
    iTE® I/O Controller Chip
  • Theo dõi phần cứng
    Voltage detection
    Temperature detection
    Fan speed detection
    Water cooling flow rate detection
    Fan fail warning
    Fan speed control

    * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.

  • BIOS
    1 x 256 Mbit flash
    Use of licensed AMI UEFI BIOS
    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
  • Tính năng duy nhất
    Support for GIGABYTE Control Center (GCC)

    * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.


    Support for Q-Flash
    Support for Q-Flash Plus
    Support for Smart Backup
  • Gói phần mềm
    Norton® Internet Security (OEM version)
    LAN bandwidth management software
  • Hệ điều hành
    Support for Windows 11 64-bit
    Support for Windows 10 64-bit
    * The Intel® NPU driver is only supported on Windows 11.
  • Hệ số khuôn
    Micro ATX Form Factor; 24.4cm x 24.4cm

Bo Mạch Chủ – MAINBOARD GIGABYTE B860M DS3H DDR5

Liên hệ
Bo Mạch Chủ - MainBoard GIGABYTE B860M DS3H WIFI6E DDR5

Bo Mạch Chủ – MainBoard GIGABYTE B860M DS3H WIFI6E DDR5

  • CPU
  • Socket LGA1851: Hỗ trợ bộ xử lý Intel® Core™ Ultra
    (Truy cập trang web của GIGABYTE để xem danh sách CPU được hỗ trợ mới nhất).
    Bộ nhớ đệm L3 thay đổi tùy thuộc vào CPU.
  • Chipset
  • Bộ vi xử lý Intel® B860 Express
  • Ký ức
  • Hỗ trợ các module bộ nhớ DDR5 9066(OC)/8800(OC) /8600(OC) / 8400(OC) /8266(OC) / 8200(OC) / 8000(OC) / 7950(OC) / 7900(OC) / 7800(OC) / 7600(OC) / 7400(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6600(OC) /6400/5600 MT/s.
    4 khe cắm DIMM DDR5 hỗ trợ tối đa 256 GB (dung lượng DIMM đơn 64 GB).
    Kiến trúc bộ nhớ kênh đôi
    . Hỗ trợ các module bộ nhớ ECC Un-buffered DIMM 1Rx8/2Rx8 (hoạt động ở chế độ non-ECC).
    Hỗ trợ DIMM non-ECC Un-buffered. Hỗ trợ các mô-đun bộ nhớ 1Rx8/2Rx8/1Rx16.
    Hỗ trợ các mô-đun bộ nhớ Extreme Memory Profile (XMP)
    (Cấu hình CPU và bộ nhớ có thể ảnh hưởng đến các loại bộ nhớ được hỗ trợ, tốc độ truyền dữ liệu và số lượng mô-đun DRAM, vui lòng tham khảo "Danh sách hỗ trợ bộ nhớ" trên trang web của GIGABYTE để biết thêm thông tin.)
  • Đồ họa tích hợp
  • Bộ xử lý đồ họa tích hợp - Hỗ trợ đồ họa Intel® HD:
    - 1 cổng HDMI, hỗ trợ độ phân giải tối đa 4096x2160@60 Hz

    * Hỗ trợ chuẩn HDMI 2.1 và HDCP 2.3.


    - 2 cổng DisplayPort, hỗ trợ độ phân giải tối đa 3840x2160@144 Hz

    * Hỗ trợ DisplayPort phiên bản 2.1.


    (Thông số đồ họa có thể khác nhau tùy thuộc vào khả năng hỗ trợ của CPU.)
    Hỗ trợ tối đa ba màn hình cùng lúc.
  • Âm thanh
  • Bộ giải mã âm thanh Realtek® Audio CODEC
    Âm thanh độ nét cao
    2/4/5.1/7.1 kênh

    * Bạn có thể thay đổi chức năng của giắc cắm âm thanh bằng phần mềm âm thanh. Để cấu hình âm thanh 7.1 kênh, hãy truy cập phần mềm âm thanh để vào cài đặt âm thanh.

  • Mạng LAN
  • Chip mạng LAN Realtek® 2.5GbE (2.5 Gbps/1 Gbps/100 Mbps)
  • Mô-đun truyền thông không dây
  • Intel® Wi-Fi 6E AX211 (PCB phiên bản 1.0)
    - WIFI a, b, g, n, ac, ax, hỗ trợ các băng tần 2.4/5/6 GHz
    - BLUETOOTH 5.3
    - Hỗ trợ chuẩn không dây 11ax 160MHz.
    Realtek® Wi-Fi 6E RTL8852CE (PCB phiên bản 1.1)
    - WIFI a, b, g, n, ac, ax, hỗ trợ các băng tần 2.4/5/6 GHz
    - BLUETOOTH 5.3
    - Hỗ trợ chuẩn không dây 11ax 160MHz
    (Tốc độ truyền dữ liệu thực tế có thể thay đổi tùy thuộc vào môi trường và thiết bị.)
  • Khe mở rộng
  • CPU:
    - 1 khe cắm PCI Express x16, hỗ trợ PCIe 5.0 và hoạt động ở chế độ x16 (PCIEX16)

    * Khe cắm PCIEX16 chỉ hỗ trợ một card đồ họa hoặc một ổ SSD NVMe. Nếu chỉ lắp đặt một card đồ họa, hãy chắc chắn lắp đặt nó vào khe cắm PCIEX16.


    Chipset:
    - 3 khe cắm PCI Express x16, hỗ trợ PCIe 4.0 và hoạt động ở chế độ x1 (PCIEX1_1/2/3)
  • Giao diện lưu trữ
  • CPU:
    - 1 khe cắm M.2 (Socket 3, chuẩn M, hỗ trợ SSD PCIe 5.0 x4/x2 loại 2280) (M2A_CPU)
    Chipset:
    - 1 khe cắm M.2 (Socket 3, chuẩn M, hỗ trợ SSD PCIe 4.0 x4/x2 loại 2280) (M2N_SB)
    - 4 khe cắm SATA 6Gb/s
    Hỗ trợ RAID 0, RAID 1, RAID 5 và RAID 10 cho các thiết bị lưu trữ SATA
  • USB
  • Chipset:
    - 1 cổng USB Type-C® hỗ trợ USB 3.2 Gen 1, có sẵn thông qua đầu cắm USB bên trong
    - 1 cổng USB 3.2 Gen 2 Type-A (màu đỏ) ở mặt sau
    - 4 cổng USB 3.2 Gen 1 (2 cổng ở mặt sau, 2 cổng có sẵn thông qua đầu cắm USB bên trong)
    - 3 cổng USB 2.0/1.1 ở mặt sau
    Chipset + Hub USB 2.0:
    - 4 cổng USB 2.0/1.1 có sẵn thông qua đầu cắm USB bên trong
  • Đầu nối I/O bên trong
  • 1 x đầu nối nguồn chính ATX 24 chân
    1 x đầu nối nguồn ATX 12V 8 chân
    1 x đầu cắm quạt CPU
    1 x đầu cắm quạt CPU/bơm làm mát bằng nước
    1 x đầu cắm quạt hệ thống
    1 x đầu cắm quạt hệ thống/bơm làm mát bằng nước
    3 x đầu cắm dải đèn LED RGB Gen2 có thể điều chỉnh
    1 x đầu cắm dải đèn LED RGB
    2 x đầu nối M.2 Socket 3
    4 x đầu nối SATA 6Gb/s
    1 x đầu cắm bảng điều khiển phía trước
    1 x đầu cắm âm thanh bảng điều khiển phía trước
    1 x đầu cắm USB Type-C®, hỗ trợ USB 3.2 Gen 1
    1 x đầu cắm USB 3.2 Gen 1
    2 x đầu cắm USB 2.0/1.1
    1 x đầu cắm Mô-đun Nền tảng Tin cậy (Chỉ dành cho mô-đun GC-TPM2.0 SPI V2)
    1 x nút Q-Flash Plus
    1 x jumper reset
    1 x jumper Clear CMOS
  • Các đầu nối bảng điều khiển phía sau
  • 1 cổng PS/2 cho bàn phím/chuột
    1 cổng HDMI (Lưu ý)
    2 cổng DisplayPort (Lưu ý)
    1 cổng USB 3.2 Gen 2 Type-A (màu đỏ)
    2 cổng USB 3.2 Gen 1
    3 cổng USB 2.0/1.1
    2 đầu nối anten (2T2R)
    1 cổng RJ-45
    3 giắc cắm âm thanh

    (Lưu ý) Khả năng hỗ trợ thực tế có thể khác nhau tùy thuộc vào CPU.
  • Bộ điều khiển I/O
  • Chip điều khiển I/O iTE®
  • Giám sát phần cứng
  • Phát hiện
    điện áp Phát hiện nhiệt độ Phát hiện
    tốc độ quạt Phát hiện
    lưu lượng nước làm mát
    Cảnh báo lỗi quạt
    Điều khiển tốc độ quạt

    * Chức năng điều khiển tốc độ quạt (bơm) có được hỗ trợ hay không sẽ phụ thuộc vào loại quạt (bơm) bạn lắp đặt.

  • BIOS
  • 1 x bộ nhớ flash 256 Mbit.
    Sử dụng BIOS AMI UEFI được cấp phép.
    Hỗ trợ PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0.
  • Đặc điểm độc đáo
  • Hỗ trợ phần mềm GIGABYTE Control Center (GCC)

    * Các ứng dụng khả dụng trong GCC có thể khác nhau tùy thuộc vào kiểu bo mạch chủ. Các chức năng được hỗ trợ của mỗi ứng dụng cũng có thể khác nhau tùy thuộc vào thông số kỹ thuật của bo mạch chủ.


    Hỗ trợ Q-Flash,
    hỗ trợ Q-Flash Plus,
    hỗ trợ Smart Backup.
  • Phần mềm đi kèm

  • Phần mềm quản lý băng thông mạng LAN Norton® Internet Security (phiên bản OEM)
  • Hệ điều hành
  • Hỗ trợ Windows 11 64-bit
    Hỗ trợ Windows 10 64-bit
    * Trình điều khiển Intel® NPU chỉ được hỗ trợ trên Windows 11.
  • Hình thức
  • Chuẩn Micro ATX; 24,4cm x 24,4cm

Bo Mạch Chủ – MainBoard GIGABYTE B860M DS3H WIFI6E DDR5

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte C246-WU4

Bo Mạch Chủ – Mainboard Gigabyte C246-WU4

Sản phẩm Bo mạch chủ
Tên Hãng Gigabyte
Model C246-WU4
Socket LGA1151
Hỗ trợ CPU Bộ xử lý Intel ® Xeon ® E series/ 9 và thế hệ thứ 8 của Intel ® Core ™ / Intel ® Pentium ® xử lý / Intel ® Celeron ® xử lý.
Chipset C246
Hỗ trợ RAM Dual Channel 4x DDR4 Support for DDR4 2666/2400/2133 MHz. Max 64Gb.
Cạc đồ họa VGA onboard
Âm thanh Bộ giải mã Realtek ® ALC1220-VB. Hỗ trợ cho S / PDIF Out.
Cạc mạng 2 x chip Intel® GbE LAN (10/100/1000 Mbit)
Khe cắm trong 1 x khe PCI Express x16, chạy ở x16 (PCIEX16), 1 x khe PCI Express x16, chạy ở x8 (PCIEX8), 2 x khe PCI Express x16, chạy ở x4 (PCIEX4_1 / PCIEX4_2), 1 x khe cắm PCI. 10 x SATA3, 2 x M.2. Hỗ trợ RAID 0, 1, 5, 10.
Cổng giao tiếp ngoài 1 x PS/2, 2 x DisplayPorts, 1 x Cổng USB Type-C ™, hỗ trợ USB 3.1 Gen 2, 1 x USB 3.1 Gen 2 Cổng loại A (màu đỏ), 4 cổng USB 3.1 Gen 1, 2 cổng USB 2.0 / 1.1.
Kích thước ATX
Tính năng khác Hỗ trợ bộ nhớ DDR4 ECC & Non-ECC Un-buffered. 4 khe cắm PCIe x16 cho nhiều loại thẻ, hỗ trợ cho công nghệ AMD Quad-GPU CrossFire ™ và 4-chiều AMD CrossFire ™. Dual Intel® Server GbE LAN hỗ trợ Công nghệ Intel® vPro. Hỗ trợ Dual M.2. Hỗ trợ bộ nhớ Intel® Optane ™. Âm thanh HD SNC ALC1220 120dB với bộ tai nghe thông minh AMP và WIM.
Phụ kiện kèm theo Sách, đĩa, cáp SATA, …

Bo Mạch Chủ – Mainboard Gigabyte C246-WU4

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte C621-SD8

Bo Mạch Chủ – Mainboard Gigabyte C621-SD8

CPU : 1st and 2nd Generation Intel Xeon Scalable Processors
Chipset : Intel C621 Chipset
Memory : 8 x DDR4 DIMM sockets supporting up to 1 TB of system memory
LAN : 1 x Realtek RTL8211E chip (10/100/1000 Mbit) (LAN1)
2 x Intel 210AT GbE LAN chips (10/100/1000 Mbit) (LAN2, LAN3)
Support for RAID 0, RAID 1, RAID 5, and RAID 10
Output : 1 x D-Sub port

Bo Mạch Chủ – Mainboard Gigabyte C621-SD8

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte GA-B85-D2V/D3V SK 1150 WHITE BOX CTY/3N

Bo Mạch Chủ – Mainboard Gigabyte GA-B85-D2V/D3V SK 1150 WHITE BOX CTY/3N

Bo Mạch Chủ – Mainboard Gigabyte GA-B85-D2V/D3V SK 1150 WHITE BOX CTY/3N

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte H110M-M2 Chính hãng

Bo Mạch Chủ – Mainboard Gigabyte H110M-M2 Chính hãng

  • CPU

    1. Support for 7th/6th Generation Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package
      * For 7th Generation Intel® Core™ processors support need to update the latest BIOS.
    2. L3 cache varies with CPU
    (Please refer "CPU Support List" for more information.)

  • Chipset

    1. Intel® H110 Express Chipset

  • Bộ nhớ

    1. 2 x DDR4 DIMM sockets supporting up to 32 GB of system memory
      * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
    2. Dual channel memory architecture
    3. Support for DDR4 2400/2133 MHz memory modules
    4. Support for ECC UDIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
    5. Support for non-ECC UDIMM 1Rx8/2Rx8/1Rx16 memory modules
    (Please refer "Memory Support List" for more information.)

  • Card đồ họa tích hợp

    1. Integrated Graphics Processor - Intel® HD Graphics support:
      1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
      1 x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
      * Support for HDMI 1.4 version.
    2. Maximum shared memory of 1024 MB

  • Âm thanh

    1. Realtek® ALC887 codec
    2. High Definition Audio
    3. 2/4/5.1/7.1-channel
      * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
    4. Support for S/PDIF Out

  • LAN

    1. Realtek® GbE LAN chip (10/100/1000 Mbit)

  • Khe cắm mở rộng

    1. 1 x PCI Express x16 slot, running at x16
      (The PCI Express x16 slot conform to PCI Express 3.0 standard.)
    2. 2 x PCI Express x1 slots
      (All of the PCI Express x1 slots conform to PCI Express 2.0 standard.)

  • Giao diện lưu trữ

    Chipset:
    1. 4 x SATA 6Gb/s connectors

  • USB

    Chipset:
    1. 4 x USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header)
    2. 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

  • Kết nối I/O bên trong

    1. 1 x 24-pin ATX main power connector
    2. 1 x 4-pin ATX 12V power connector
    3. 4 x SATA 6Gb/s connectors
    4. 1 x CPU fan header
    5. 1 x system fan header
    6. 1 x front panel header
    7. 1 x front panel audio header
    8. 1 x S/PDIF Out header
    9. 1 x USB 3.0/2.0 header
    10. 2 x USB 2.0/1.1 headers
    11. 1 x Trusted Platform Module (TPM) header
    12. 1 x Clear CMOS jumper

  • Kết nối bảng phía sau

    1. 1 x PS/2 mouse port
    2. 1 x PS/2 Keyboard port
    3. 1 x D-Sub port
    4. 1 x HDMI port
    5. 2 x USB 3.0/2.0 ports
    6. 2 x USB 2.0/1.1 ports
    7. 1 x RJ-45 port
    8. 3 x audio jacks (Line In, Line Out, Mic In)

  • Điều khiển I/O

    1. iTE® I/O Controller Chip

  • Theo dõi phần cứng

    1. System voltage detection
    2. CPU/System temperature detection
    3. CPU/System fan speed detection
    4. CPU/System overheating warning
    5. CPU/System fan fail warning
    6. CPU/System fan speed control
      * Whether the fan speed control function is supported will depend on the cooler you install.

  • BIOS

    1. 1 x 64 Mbit flash
    2. Use of licensed AMI UEFI BIOS
    3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

  • Tính năng duy nhất

    1. Support for APP Center
      * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications.
      3D OSD
      @BIOS
      AutoGreen
      Cloud Station
      EasyTune
      Fast Boot
      Smart TimeLock
      Smart Keyboard
      Smart Backup
      System Information Viewer
      USB Blocker
    2. Support for Q-Flash
    3. Support for Smart Switch
    4. Support for Xpress Install

  • Gói phần mềm

    1. Norton® Internet Security (OEM version)
    2. cFosSpeed

  • Hệ điều hành

    1. Windows® 10 64-bit (for 7th Generation Intel® Processors)
    2. Windows® 10 64-bit / Windows® 8.1 64-bit / Windows® 7 32-bit / 64-bits (for 6th Generation Intel® Processors)
      * Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7.

  • Hệ số khuôn

    1. Micro ATX Form Factor; 22.6cm x 17.4cm

Bo Mạch Chủ – Mainboard Gigabyte H110M-M2 Chính hãng

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte H310M D2VX-SI 2.0 C.ty Renew 3Năm

Bo Mạch Chủ – Mainboard Gigabyte H310M D2VX-SI 2.0 C.ty Renew 3Năm

  • CPU Socket: LGA1151 (Supports 8th Gen Intel Processors)
  • Chipset: Intel® H310 Express Chipset
  • Memory:
    • 2 DDR4 DIMM slots (Up to 32GB)
    • Supports Dual-Channel DDR4 2666/2400/2133 MHz
    • ECC & Non-ECC Un-buffered DIMM compatible
    • XMP Support (Requires 8th Gen i7/i5 CPU)
  • Storage:
    • 1 M.2 Slot
    • 4 SATA 3.0 Ports
  • Expansion:
    • 1 PCI Express x16 Slot (PCIe 3.0)
    • 2 PCI Express x1 Slots (PCIe 2.0)
  • Networking:
    • Realtek® GbE LAN (10/100/1000 Mbit)
  • Audio:
    • Realtek® ALC887 Chip
    • High Definition Audio (2/4/5.1/7.1 Channel)
    • S/PDIF Output
  • Display:
    • Integrated Graphics (Intel® HD Graphics)
    • 1 VGA port (up to 1920x1200@60Hz)
    • 1 DVI-D port (up to 1920x1200@60Hz)
    • Max Shared Display Memory: 1GB
  • USB:
    • 4 x USB 3.1 Gen 1 (2 rear panel, 2 internal)
    • 6 x USB 2.0/1.1 (4 rear panel, 2 internal)
  • Form Factor: Micro ATX (22.6cm x 18.5cm)
  • OS Support: Windows 10 64-bit

Bo Mạch Chủ – Mainboard Gigabyte H310M D2VX-SI 2.0 C.ty Renew 3Năm

Liên hệ
Bo Mạch Chủ - Mainboard GIGABYTE H310M DS2V C.ty Renew 3Năm

Bo Mạch Chủ – Mainboard GIGABYTE H310M DS2V C.ty Renew 3Năm

Tên gọi Gigabyte H310M-DS2
CPU hỗ trợ Intel® Socket 1151 for 8th Generation Core™ Processors
Chipset / Socket Intel® B310
Bộ nhớ (RAM) • 2 x DDR4 memory slots, support up to 32GB • Supports DDR4 2400/ 2133 MHz (by JEDEC) • Supports DDR4 2400/ 2133 (by XMP OC) • Supports Dual-Channel mode • Supports non-ECC, un-buffered memory • Supports Intel® Extreme Memory Profile (XMP)
Công nghệ đa GPU • Không hỗ trợ
Khe cắm mở rộng • 1 x PCI Express 3.0 x16 Slots • 2 x PCI Express 3.0 x1 Slots
LAN / Wireless • Realtek® GbE LAN chip (10/100/1000 Mbit)
Âm thanh • Realtek® ALC887 Codec
Cổng kết nối (Internal) • 1 x 24-pin ATX main power connector • 1 x 4-pin ATX 12V power connector • 4 x SATA 6Gb/s connectors • 1 x CPU fan header • 1 x system fan header • 1 x front panel header • 1 x front panel audio header • 1 x USB 3.1 Gen 1 header • 1 x USB 2.0/1.1 header • 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) • 1 x Clear CMOS jumper
Cổng kết nối (Back Panel) • 1 x PS/2 keyboard/mouse port • 1 x parallel port • 1 x serial port • 1 x D-Sub port • 2 x USB 3.1 Gen 1 ports • 4 x USB 2.0/1.1 ports • 1 x RJ-45 port • 3 x audio jacks
Công nghệ độc quyền • Support for APP Center • Support for Q-Flash • Support for Xpress Install
Phụ kiện đi kèm - Quick Installation Guide, Support CD, I/O Shield
Hệ điều hành khuyến nghị • Windows® 10 64-bit
Chuẩn kích cỡ • mATX Form Factor



Bo Mạch Chủ – Mainboard GIGABYTE H310M DS2V C.ty Renew 3Năm

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte H310M M.2 2.0

Bo Mạch Chủ – Mainboard Gigabyte H310M M.2 2.0

Loại Ram

DDR4
Chipset

Intel H310
Socket

LGA1151
Khe Ram

2 khe cắm Ram
Dung lượng Ram hỗ trợ tối đa

32GB
Tốc độ Bus

DDR4 2666/2400/2133 MHz
Cổng xuất hình

1 x D-Sub, 1 x HDMI
Wifi

Không
Bluetooth

Không
Kết nối mạng LAN

10/100/1000 Mbit
Khe cắm

1 x M.2, 4 x SATA 6Gb/s
Giao Tiếp VGA

1 x PCI Express x16 3.0, 2 x PCI Express x1 2.0
Số cổng USB

2 x USB 3.1 Gen 1, 4 x USB 2.0/1.1
Hệ điều hành hỗ trợ

Windows 11 64-bit, Windows 10 64-bit
Kích thước

Micro ATX Form Factor (22.6cm x 17.4cm)

Bo Mạch Chủ – Mainboard Gigabyte H310M M.2 2.0

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte H310M M2 2.0 CHÍNH HÃNG VIỄN SƠN

Bo Mạch Chủ – Mainboard Gigabyte H310M M2 2.0 CHÍNH HÃNG VIỄN SƠN

  • CPU

    1. Support for 9th and 8th Generation Intel® Core™ i9 processors/Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package
    2. L3 cache varies with CPU
    (Please refer "CPU Support List" for more information.)

  • Chipset

    1. Intel® H310 Express Chipset

  • Bộ nhớ

    1. 2 x DDR4 DIMM sockets supporting up to 32 GB of system memory
    2. Dual channel memory architecture
    3. Support for DDR4 2666/2400/2133 MHz memory modules
    4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
    5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    6. Support for Extreme Memory Profile (XMP) memory modules
      * To support 2666 MHz or XMP memory, you must install a 9th or 8th Generation Intel® Core™ i9/i7/i5 processor.
    (Please refer "Memory Support List" for more information.)

  • Card đồ họa tích hợp

    Integrated Graphics Processor-Intel® HD Graphics support:
    1. 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
    2. 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
      * Support for HDMI 1.4 version and HDCP 2.2.
    Maximum shared memory of 1 GB

  • Âm thanh

    1. Realtek® Audio codec
    2. High Definition Audio
    3. 2/4/5.1/7.1-channel
      * To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.

  • LAN

    1. Realtek® GbE LAN chip (10/100/1000 Mbit)

  • Khe cắm mở rộng

    1. 1 x PCI Express x16 slot, running at x16
      (The PCIEX16 slot conforms to PCI Express 3.0 standard.)
    2. 2 x PCI Express x1 slots
      (The PCI Express x1 slots conform to PCI Express 2.0 standard.)

  • Giao diện lưu trữ

    Chipset:
    1. 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe x2 SSD support)
    2. 4 x SATA 6Gb/s connectors

  • USB

    Chipset:
    1. 4 x USB 3.1 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
    2. 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)

  • Kết nối I/O bên trong

    1. 1 x 24-pin ATX main power connector
    2. 1 x 4-pin ATX 12V power connector
    3. 4 x SATA 6Gb/s connectors
    4. 1 x CPU fan header
    5. 1 x system fan header
    6. 1 x front panel header
    7. 1 x front panel audio header
    8. 1 x USB 3.1 Gen 1 header
    9. 1 x USB 2.0/1.1 header
    10. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
    11. 1 x Clear CMOS jumper

  • Kết nối bảng phía sau

    1. 1 x PS/2 keyboard/mouse port
    2. 1 x D-Sub port
    3. 1 x HDMI port
    4. 2 x USB 3.1 Gen 1 ports
    5. 4 x USB 2.0/1.1 ports
    6. 1 x RJ-45 port
    7. 3 x audio jacks

  • Điều khiển I/O

    1. iTE® I/O Controller Chip

  • Theo dõi phần cứng

    1. Voltage detection
    2. Temperature detection
    3. Fan speed detection
    4. Overheating warning
    5. Fan fail warning
    6. Fan speed control
      * Whether the fan speed control function is supported will depend on the cooler you install.

  • BIOS

    1. 1 x 128 Mbit flash
    2. Use of licensed AMI UEFI BIOS
    3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

  • Tính năng duy nhất

    1. Support for APP Center
      * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
      @BIOS
      AutoGreen
      Cloud Station
      EasyTune
      Fast Boot
      Game Boost
      ON/OFF Charge
      Platform Power Management
      Smart Backup
      Smart Keyboard
      System Information Viewer
      USB Blocker
    2. Support for Q-Flash
    3. Support for Xpress Install

  • Gói phần mềm

    1. Norton® Internet Security (OEM version)
    2. Realtek® 8118 Gaming LAN Bandwidth Control Utility

  • Hệ điều hành

    1. Support for Windows 10 64-bit

  • Hệ số khuôn

    1. Micro ATX Form Factor; 22.6cm x 17.4cm

Bo Mạch Chủ – Mainboard Gigabyte H310M M2 2.0 CHÍNH HÃNG VIỄN SƠN

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte H510M-H V2(box màu)

Bo Mạch Chủ – Mainboard Gigabyte H510M-H V2(box màu)

  • CPU

    LGA1200 package:
    1. 11th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors
    2. 10th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors / Intel® Core™ i3 processors/ Intel® Pentium® processors / Intel® Celeron® processors
    3. L3 cache varies with CPU
    (Please refer to "CPU Support List" for more information.)

  • Chipset

    1. Intel® H470 Express Chipset

  • Memory

    1. 11th Generation Intel® Core™ i9/i7/i5 processors:
      Support for DDR4 3200/3000/2933/2666/2400/2133 MHz memory modules
    2. 10th Generation Intel® Core™ i9/i7 processors:
      Support for DDR4 2933/2666/2400/2133 MHz memory modules
    3. 10th Generation Intel® Core™ i5/i3/Pentium®/Celeron® processors:
      Support for DDR4 2666/2400/2133 MHz memory modules
    4. 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
    5. Dual channel memory architecture
    6. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
    7. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    8. Support for Extreme Memory Profile (XMP) memory modules
    (Please refer "Memory Support List" for more information.)

  • Onboard Graphics

    Integrated Graphics Processor-Intel® HD Graphics support:
    1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
      * Support for HDMI 1.4 version and HDCP 2.3.
    2. 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
      * The D-Sub port is only available with the 10th Generation processors.
    (Graphics specifications may vary depending on CPU support.)

  • Audio

    1. Realtek® Audio CODEC
    2. High Definition Audio
    3. 2/4/5.1/7.1-channel
      * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.

  • LAN

    1. Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)

  • Expansion Slots

    CPU:
    1. 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16
    Chipset:
    1. 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1

  • Storage Interface

    Chipset:
    1. 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 3.0 x4/x2 SSD support)
    2. 4 x SATA 6Gb/s connectors
    RAID 0, RAID 1, RAID5, and RAID 10 support for NVMe SSD storage devices
    RAID 0, RAID 1, RAID5, and RAID 10 support for SATA storage devices

  • USB

    Chipset:
    1. 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
    2. 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)

  • Internal I/O Connectors

    1. 1 x 24-pin ATX main power connector
    2. 1 x 8-pin ATX 12V power connector
    3. 1 x CPU fan header
    4. 1 x system fan header
    5. 1 x RGB LED strip header
    6. 1 x M.2 Socket 3 connector
    7. 4 x SATA 6Gb/s connectors
    8. 1 x front panel header
    9. 1 x front panel audio header
    10. 1 x USB 3.2 Gen 1 header
    11. 1 x USB 2.0/1.1 header
    12. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
    13. 1 x serial port header
    14. 1 x Clear CMOS jumper

  • Back Panel Connectors

    1. 1 x PS/2 keyboard/mouse port
    2. 1 x D-Sub port
    3. 1 x HDMI port
    4. 2 x USB 3.2 Gen 1 ports
    5. 4 x USB 2.0/1.1 ports
    6. 1 x RJ-45 port
    7. 3 x audio jacks

  • I/O Controller

    1. iTE® I/O Controller Chip

  • H/W Monitoring

    1. Voltage detection
    2. Temperature detection
    3. Fan speed detection
    4. Fan fail warning
    5. Fan speed contro
      * Whether the fan speed control function is supported will depend on the cooler you install.

  • BIOS

    1. 1 x 128 Mbit flash
    2. Use of licensed AMI UEFI BIOS
    3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

  • Unique Features

    1. Support for APP Center
      * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
      @BIOS
      Ambient LED
      EasyTune
      Smart Backup
      System Information Viewer
    2. Support for Q-Flash
    3. Support for Xpress Install

  • Bundled Software

    1. Norton® Internet Security (OEM version)
    2. LAN bandwidth management software

  • Operating System

    1. Support for Windows 11 64-bit
    2. Support for Windows 10 64-bit

  • Form Factor

    1. Micro ATX Form Factor; 22.6cm x 18.5cm

Bo Mạch Chủ – Mainboard Gigabyte H510M-H V2(box màu)

Liên hệ
Nơi nhập dữ liệu

Bo Mạch Chủ – MainBoard GIGABYTE H610M H V2 DDR4

Sản phẩm Bo mạch chủ
Tên Hãng GIGABYTE
Model H610M H V2 DDR4
CPU hỗ trợ Hỗ trợ cho thế hệ thứ 12, 13 và 14 Intel® Core Socket LGA1700
Chipset H610
RAM hỗ trợ 1.Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modules
2.2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
3.Dual channel memory architecture
4.Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
5.Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
6.Support for Extreme Memory Profile (XMP) memory modules
Khe cắm mở rộng CPU:
1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
Chipset:
1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Ổ cứng hỗ trợ Chipset:
1.1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD support)
2.4 x SATA 6Gb/s connectors
Cổng kết nối (Internal) 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
2 x system fan headers
1 x M.2 Socket 3 connector
4 x SATA 6Gb/s connectors
1 x RGB LED strip header
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x serial port header
1 x Clear CMOS jumper
Cổng kết nối (Back Panel) 1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x D-Sub port
1 x HDMI port
2 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks
LAN / Wireless Realtek® GbE LAN chip (1 Gbps/100 Mbps)
Kích cỡ Micro ATX Form Factor; 23.0cm x 21.5cm

Bo Mạch Chủ – MainBoard GIGABYTE H610M H V2 DDR4

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte H610M H V3 DDR4 Chính hãng

Bo Mạch Chủ – Mainboard Gigabyte H610M H V3 DDR4 Chính hãng

Thương hiệu Gigabyte
Bảo hành 36 tháng
Tình trạng Mới 100%
Kích thước Micro ATX Form Factor; 23.0cm x 21.5cm
CPU hỗ trợ Socket LGA1700: Hỗ trợ cho các bộ vi xử lý Intel ® Core ™, Pentium ® Gold và Celeron ® thế hệ thứ 12 *
Bộ nhớ đệm L3 thay đổi tùy theo CPU
Chipset Intel ® H610 Express
RAM hỗ trợ Hỗ trợ các mô-đun bộ nhớ DDR4 3200/3000/2933/2666/2400/2133 MHz
2 x ổ cắm DDR4 DIMM hỗ trợ bộ nhớ hệ thống lên đến 64 GB (dung lượng 32 GB đơn DIMM)
Kiến trúc bộ nhớ kênh đôi
Hỗ trợ cho các mô-đun bộ nhớ DIMM 1Rx8 / 2Rx8 không đệm của ECC (hoạt động ở chế độ không phải ECC)
Hỗ trợ cho các mô-đun bộ nhớ DIMM 1Rx8 / 2Rx8 / 1Rx16 không có ECC Un-buffer
Hỗ trợ mô-đun bộ nhớ Extreme Memory Profile (XMP)
Âm thanh Realtek ® Audio CODEC
Âm thanh độ nét cao
2/4 / 5.1 / 7.1 kênh
LAN Intel® GbE LAN chip (1 Gbps/100 Mbps)
Khe cắm mở rộng 1 x Khe cắm PCI Express x16, chạy ở x16
* Để có hiệu suất tối ưu, nếu chỉ lắp một cạc đồ họa PCI Express, hãy đảm bảo lắp nó vào khe PCIEX16.
(Khe PCI Express x16 tuân theo tiêu chuẩn PCI Express 4.0.)
1 x Khe cắm PCI Express x1
(Khe cắm PCI Express x1 tuân theo tiêu chuẩn PCI Express 3.0.)
Giao diện lưu trữ 1 x đầu nối M.2 (Socket 3, M key, hỗ trợ SSD loại 2260/2280 PCIe 3.0 x4 / x2)
4 x đầu nối SATA 6Gb / s
Kết nối I/O bên trong 1 x đầu nối nguồn chính ATX 24 chân
1 x đầu nối nguồn ATX 12V 8 chân
1 x đầu nối M.2 Socket 3
4 x đầu nối SATA 6Gb / s
1 x đầu cắm quạt CPU
2 x đầu cắm quạt hệ thống
1 x đầu cắm dải LED RGB
1 x tiêu đề bảng điều khiển phía trước
1 x tiêu đề âm thanh bảng điều khiển phía trước
1 x đầu cắm USB 3.2 Thế hệ 1
2 x đầu cắm USB 2.0 / 1.1
1 x tiêu đề Mô-đun nền tảng đáng tin cậy (Chỉ dành cho mô-đun GC-TPM2.0 SPI / GC-TPM2.0 SPI 2.0)
1 x tiêu đề cổng nối tiếp
1 x Clear CMOS jumper
Kết nối bảng phía sau 1 x cổng bàn phím PS / 2
1 x cổng chuột PS / 2
1 x cổng D-Sub
1 x cổng HDMI 2.0
2 x cổng USB 3.2 Gen 1
4 x cổng USB 2.0 / 1.1
1 x cổng RJ-45
3 x giắc cắm âm thanh

Bo Mạch Chủ – Mainboard Gigabyte H610M H V3 DDR4 Chính hãng

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte H610M K DDR4

Bo Mạch Chủ – Mainboard Gigabyte H610M K DDR4

  • CPU
    1. LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors*
    2. L3 cache varies with CPU
    * Please refer to "CPU Support List" for more information.
  • Chipset
    1. Intel® H610 Express Chipset
  • Bộ nhớ
    1. Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modules
    2. 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
    3. Dual channel memory architecture
    4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
    5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    6. Support for Extreme Memory Profile (XMP) memory modules
    (Please refer "Memory Support List" for more information.)
  • Card đồ họa tích hợp
    Integrated Graphics Processor-Intel® HD Graphics support:
    1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
      * Support for HDMI 2.1 version and HDCP 2.3.
      ** Support native HDMI 2.1 TMDS compatible ports.
    (Graphics specifications may vary depending on CPU support.)
  • Âm thanh
    1. Realtek® Audio CODEC
    2. High Definition Audio
    3. 2/4/5.1/7.1-channel
      * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
  • LAN
    1. Realtek® GbE LAN chip (1 Gbps/100 Mbps)
  • Khe cắm mở rộng
    CPU:
    1. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
    Chipset:
    1. 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
  • Giao diện lưu trữ
    Chipset:
    1. 1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD support)
    2. 2 x SATA 6Gb/s connectors
  • USB
    Chipset:
    1. 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
    2. 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
  • Kết nối I/O bên trong
    1. 1 x 24-pin ATX main power connector
    2. 1 x 8-pin ATX 12V power connector
    3. 1 x CPU fan header
    4. 1 x system fan header
    5. 1 x M.2 Socket 3 connector
    6. 2 x SATA 6Gb/s connectors
    7. 1 x front panel header
    8. 1 x front panel audio header
    9. 1 x USB 3.2 Gen 1 header
    10. 1 x USB 2.0/1.1 header
    11. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
    12. 1 x Clear CMOS jumper
  • Kết nối bảng phía sau
    1. 1 x HDMI port
    2. 2 x USB 3.2 Gen 1 ports
    3. 4 x USB 2.0/1.1 ports
    4. 1 x RJ-45 port
    5. 3 x audio jacks
  • Điều khiển I/O
    1. iTE® I/O Controller Chip
  • Theo dõi phần cứng
    1. Voltage detection
    2. Temperature detection
    3. Fan speed detection
    4. Water cooling flow rate detection
    5. Fan fail warning
    6. Fan speed control
      * Whether the fan speed control function is supported will depend on the cooler you install.
  • BIOS
    1. 1 x 128 Mbit flash
    2. Use of licensed AMI UEFI BIOS
    3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
  • Tính năng duy nhất
    1. Support for APP Center
      * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
      @BIOS
      EasyTune
      Smart Backup
      System Information Viewer
    2. Support for Q-Flash
    3. Support for Xpress Install
  • Gói phần mềm
    1. Norton® Internet Security (OEM version)
    2. LAN bandwidth management software
  • Hệ điều hành
    1. Support for Windows 11 64-bit
    2. Support for Windows 10 64-bit
  • Hệ số khuôn
    1. Micro ATX Form Factor; 22.6cm x 18.5cm

Bo Mạch Chủ – Mainboard Gigabyte H610M K DDR4

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte H610M S2H V2 DDR4(White box) CHÍNH HÃNG VIỄN SƠN

Bo Mạch Chủ – Mainboard Gigabyte H610M S2H V2 DDR4(White box) CHÍNH HÃNG VIỄN SƠN

  • CPU

    1. LGA1700 socket: Support for 13th Generation Intel® Core™ Processors and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors*
    2. L3 cache varies with CPU
    * Please refer to "CPU Support List" for more information.

  • Chipset

    1. Intel® H610 Express Chipset

  • Bộ nhớ

    1. Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modules
    2. 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
    3. Dual channel memory architecture
    4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
    5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    6. upport for Extreme Memory Profile (XMP) memory modules
    (Please refer "Memory Support List" for more information.)

  • Card đồ họa tích hợp

    Integrated Graphics Processor-Intel® HD Graphics support:
    1. 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
    2. 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
      * The DVI-D port does not support D-Sub connection by adapter.
    3. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
      * Support for HDMI 2.0 version and HDCP 2.3.
    4. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
      * Support for DisplayPort 1.2 version and HDCP 2.3
    (Graphics specifications may vary depending on CPU support.)

  • Âm thanh

    1. Realtek® Audio CODEC
    2. High Definition Audio
    3. 2/4/5.1/7.1-channel
      * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.

  • LAN

    1. Realtek® GbE LAN chip (1 Gbps/100 Mbps)

  • Khe cắm mở rộng

    CPU:
    1. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
    Chipset:
    1. 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1

  • Giao diện lưu trữ

    Chipset:
    1. 1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD support)
    2. 4 x SATA 6Gb/s connectors

  • USB

    Chipset:
    1. 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
    2. 4 x USB 2.0/1.1 ports on the back panel
    Chipset+USB 2.0 Hub:
    1. 4 x USB 2.0/1.1 ports available through the internal USB headers

  • Kết nối I/O bên trong

    1. 1 x 24-pin ATX main power connector
    2. 1 x 8-pin ATX 12V power connector
    3. 1 x CPU fan header
    4. 2 x system fan headers
    5. 1 x M.2 Socket 3 connector
    6. 4 x SATA 6Gb/s connectors
    7. 1 x RGB LED strip header
    8. 1 x front panel header
    9. 1 x front panel audio header
    10. 1 x USB 3.2 Gen 1 header
    11. 2 x USB 2.0/1.1 headers
    12. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
    13. 1 x serial port header
    14. 1 x Clear CMOS jumper

  • Kết nối bảng phía sau

    1. 1 x PS/2 keyboard port
    2. 1 x PS/2 mouse port
    3. 1 x D-Sub port
    4. 1 x DVI-D port
    5. 1 x DisplayPort
    6. 1 x HDMI port
    7. 2 x USB 3.2 Gen 1 ports
    8. 4 x USB 2.0/1.1 ports
    9. 1 x RJ-45 port
    10. 3 x audio jacks

  • Điều khiển I/O

    1. iTE® I/O Controller Chip

  • Theo dõi phần cứng

    1. Voltage detection
    2. Temperature detection
    3. Fan speed detection
    4. Water cooling flow rate detection
    5. Fan fail warning
    6. Fan speed control
      * Whether the fan speed control function is supported will depend on the cooler you install.

  • BIOS

    1. 1 x 128 Mbit flash
    2. Use of licensed AMI UEFI BIOS
    3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

  • Tính năng duy nhất

    1. Support for APP Center
      * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
      @BIOS
      Ambient LED
      EasyTune
      Smart Backup
      System Information Viewer
    2. Support for Q-Flash
    3. Support for Xpress Install

  • Gói phần mềm

    1. Norton® Internet Security (OEM version)
    2. LAN bandwidth management software

  • Hệ điều hành

    1. Support for Windows 11 64-bit
    2. Support for Windows 10 64-bit

  • Hệ số khuôn

    1. Micro ATX Form Factor; 23.0cm x 21.5cm

Bo Mạch Chủ – Mainboard Gigabyte H610M S2H V2 DDR4(White box) CHÍNH HÃNG VIỄN SƠN

Liên hệ
Bo Mạch Chủ - MAINBOARD GIGABYTE H810M H DDR5

Bo Mạch Chủ – MAINBOARD GIGABYTE H810M H DDR5

  • CPU
  • Socket LGA1851: Hỗ trợ bộ xử lý Intel® Core™ Ultra
    (Truy cập trang web của GIGABYTE để xem danh sách CPU được hỗ trợ mới nhất).
    Bộ nhớ đệm L3 thay đổi tùy thuộc vào CPU.
  • Chipset
  • Bộ vi xử lý Intel® H810 Express
  • Bộ nhớ
  • Hỗ trợ các mô-đun bộ nhớ DDR5 6400/5600 MT/s
    2 khe cắm DIMM DDR5 hỗ trợ tối đa 128 GB (dung lượng DIMM đơn 64 GB) bộ nhớ hệ thống
    Kiến trúc bộ nhớ kênh đôi
    Hỗ trợ các mô-đun bộ nhớ ECC Un-buffered DIMM 1Rx8/2Rx8 (hoạt động ở chế độ không ECC)
    Hỗ trợ các mô-đun bộ nhớ non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16
    Hỗ trợ các mô-đun bộ nhớ Extreme Memory Profile (XMP)
    (Cấu hình CPU và bộ nhớ có thể ảnh hưởng đến các loại bộ nhớ được hỗ trợ, tốc độ dữ liệu và số lượng mô-đun DRAM, vui lòng tham khảo "Danh sách hỗ trợ bộ nhớ" trên trang web của GIGABYTE để biết thêm thông tin.)
  • Card đồ họa tích hợp
  • Bộ xử lý đồ họa tích hợp - Hỗ trợ đồ họa Intel® HD:
    - 1 cổng HDMI, hỗ trợ độ phân giải tối đa 4096x2160@60 Hz

    * Hỗ trợ chuẩn HDMI 2.1 và HDCP 2.3.


    - 1 cổng D-Sub, hỗ trợ độ phân giải tối đa 1920x1200@60 Hz
    (Thông số đồ họa có thể thay đổi tùy thuộc vào khả năng hỗ trợ của CPU).
  • Âm thanh
  • Bộ giải mã âm thanh Realtek® Audio CODEC
    Âm thanh độ nét cao
    2/4/5.1/7.1 kênh

    * Bạn có thể thay đổi chức năng của giắc cắm âm thanh bằng phần mềm âm thanh. Để cấu hình âm thanh 7.1 kênh, hãy truy cập phần mềm âm thanh để vào cài đặt âm thanh.


    Hỗ trợ đầu ra S/PDIF
  • VÀ
  • Chip mạng LAN Realtek® GbE (1 Gbps/100 Mbps/10 Mbps)
  • Khe cắm mở rộng
  • CPU:
    - 1 khe cắm PCI Express x16, hỗ trợ PCIe 4.0 và hoạt động ở chế độ x16 (PCIEX16)

    * Khe cắm PCIEX16 chỉ hỗ trợ card đồ họa hoặc ổ SSD NVMe.


    Chipset:
    - 1 khe cắm PCI Express x1, hỗ trợ PCIe 3.0 và hoạt động ở chế độ x1 (PCIEX1)
  • Giao diện lưu trữ
  • Chipset:
    - 1 x đầu nối M.2 (Socket 3, M key, loại 2280 PCIe 4.0 x4/x2 hỗ trợ SSD)
    - 4 x đầu nối SATA 6Gb/s
  • USB
  • Chipset:
    - 1 cổng USB Type-C® hỗ trợ USB 3.2 Gen 1, có sẵn thông qua đầu cắm USB bên trong
    - 3 cổng USB 3.2 Gen 1 (1 cổng ở mặt sau, 2 cổng có sẵn thông qua đầu cắm USB bên trong)
    - 3 cổng USB 2.0/1.1 (1 cổng ở mặt sau, 2 cổng có sẵn thông qua đầu cắm USB bên trong)
    Chipset + Hub USB 2.0:
    - 4 cổng USB 2.0/1.1 ở mặt sau
  • Kết nối I/O bên trong
  • 1 x đầu nối nguồn chính ATX 24 chân
    1 x đầu nối nguồn ATX 12V 8 chân
    1 x đầu cắm quạt CPU
    2 x đầu cắm quạt hệ thống 2
    x đầu cắm dải đèn LED RGB Gen2 có thể điều chỉnh
    1 x đầu nối M.2 Socket 3
    4 x đầu nối SATA 6Gb/s
    1 x đầu cắm bảng điều khiển phía trước
    1 x đầu cắm âm thanh bảng điều khiển phía trước
    1 x đầu cắm S/PDIF Out
    1 x đầu cắm USB Type-C®, hỗ trợ USB 3.2 Gen 1
    1 x đầu cắm USB 3.2 Gen 1
    1 x đầu cắm USB 2.0/1.1
    1 x đầu cắm Mô-đun Nền tảng Tin cậy (Chỉ dành cho mô-đun GC-TPM2.0 SPI V2)
    1 x đầu cắm cổng nối tiếp
    1 x jumper Xóa CMOS
  • Kết nối bảng phía sau
  • 1 cổng PS/2 cho bàn phím/chuột
    1 cổng HDMI (Lưu ý)
    1 cổng D-Sub
    1 cổng USB 3.2 Gen 1 5 cổng
    USB 2.0/1.1
    1 cổng RJ-45
    3 giắc cắm âm thanh

    (Lưu ý) Khả năng hỗ trợ thực tế có thể khác nhau tùy thuộc vào CPU.
  • Điều khiển I/O
  • Chip điều khiển I/O iTE®
  • Theo dõi phần cứng
  • Phát hiện
    điện áp Phát hiện nhiệt độ Phát hiện
    tốc độ quạt Phát hiện
    lưu lượng nước làm mát
    Cảnh báo lỗi quạt
    Điều khiển tốc độ quạt

    * Chức năng điều khiển tốc độ quạt có được hỗ trợ hay không sẽ phụ thuộc vào loại quạt bạn lắp đặt.

  • BIOS
  • 1 x bộ nhớ flash 256 Mbit.
    Sử dụng BIOS AMI UEFI được cấp phép.
    Hỗ trợ PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0.
  • Tính năng duy nhất
  • Hỗ trợ phần mềm GIGABYTE Control Center (GCC)

    * Các ứng dụng khả dụng trong GCC có thể khác nhau tùy thuộc vào kiểu bo mạch chủ. Các chức năng được hỗ trợ của mỗi ứng dụng cũng có thể khác nhau tùy thuộc vào thông số kỹ thuật của bo mạch chủ.


    Hỗ trợ Q-Flash,
    hỗ trợ Smart Backup.
  • Gói phần mềm

  • Phần mềm quản lý băng thông mạng LAN Norton® Internet Security (phiên bản OEM)
  • Hệ điều hành
  • Hỗ trợ Windows 11 64-bit
    Hỗ trợ Windows 10 64-bit

    * Trình điều khiển Intel® NPU chỉ được hỗ trợ trên Windows 11.

  • Hệ số khuôn
  • Chuẩn Micro ATX; kích thước 24,4cm x 21,5cm

Bo Mạch Chủ – MAINBOARD GIGABYTE H810M H DDR5

Liên hệ
Bo Mạch Chủ - MAINBOARD GIGABYTE H810M K DDR5

Bo Mạch Chủ – MAINBOARD GIGABYTE H810M K DDR5

  • CPU
  • Socket LGA1851: Hỗ trợ bộ xử lý Intel® Core™ Ultra
    (Truy cập trang web của GIGABYTE để xem danh sách CPU được hỗ trợ mới nhất).
    Bộ nhớ đệm L3 thay đổi tùy thuộc vào CPU.
  • Chipset
  • Bộ vi xử lý Intel® H810 Express
  • Bộ nhớ
  • Hỗ trợ các mô-đun bộ nhớ DDR5 6400/5600 MT/s
    2 khe cắm DIMM DDR5 hỗ trợ tối đa 128 GB (dung lượng DIMM đơn 64 GB) bộ nhớ hệ thống
    Kiến trúc bộ nhớ kênh đôi
    Hỗ trợ các mô-đun bộ nhớ ECC Un-buffered DIMM 1Rx8/2Rx8 (hoạt động ở chế độ không ECC)
    Hỗ trợ các mô-đun bộ nhớ non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16
    Hỗ trợ các mô-đun bộ nhớ Extreme Memory Profile (XMP)
    (Cấu hình CPU và bộ nhớ có thể ảnh hưởng đến các loại bộ nhớ được hỗ trợ, tốc độ dữ liệu và số lượng mô-đun DRAM, vui lòng tham khảo "Danh sách hỗ trợ bộ nhớ" trên trang web của GIGABYTE để biết thêm thông tin.)
  • Card đồ họa tích hợp
  • Bộ xử lý đồ họa tích hợp - Hỗ trợ đồ họa Intel® HD:
    - 1 cổng DisplayPort, hỗ trợ độ phân giải tối đa 3840x2160@60 Hz

    * Hỗ trợ DisplayPort phiên bản 2.1.


    - 1 cổng HDMI, hỗ trợ độ phân giải tối đa 4096x2160@60 Hz

    * Hỗ trợ chuẩn HDMI 2.1 và HDCP 2.3.


    (Thông số kỹ thuật đồ họa có thể khác nhau tùy thuộc vào khả năng hỗ trợ của CPU.)
  • Âm thanh
  • Bộ giải mã âm thanh Realtek® Audio CODEC
    Âm thanh độ nét cao
    2/4/5.1/7.1 kênh

    * Bạn có thể thay đổi chức năng của giắc cắm âm thanh bằng phần mềm âm thanh. Để cấu hình âm thanh 7.1 kênh, hãy truy cập phần mềm âm thanh để vào cài đặt âm thanh.

  • VÀ
  • Chip mạng LAN Realtek® GbE (1 Gbps/100 Mbps/10 Mbps)
  • Khe cắm mở rộng
  • CPU:
    - 1 khe cắm PCI Express x16, hỗ trợ PCIe 4.0 và hoạt động ở chế độ x16 (PCIEX16)

    * Khe cắm PCIEX16 chỉ hỗ trợ card đồ họa hoặc ổ SSD NVMe.


    Chipset:
    - 1 khe cắm PCI Express x1, hỗ trợ PCIe 3.0 và hoạt động ở chế độ x1 (PCIEX1)
  • Giao diện lưu trữ
  • Chipset:
    - 1 x đầu nối M.2 (Socket 3, M key, loại 2280 PCIe 4.0 x4/x2 hỗ trợ SSD)
    - 4 x đầu nối SATA 6Gb/s
  • USB
  • Chipset:
    - 4 cổng USB 3.2 Gen 1 (2 cổng ở mặt sau, 2 cổng có sẵn thông qua đầu cắm USB bên trong)
    - 6 cổng USB 2.0/1.1 (4 cổng ở mặt sau, 2 cổng có sẵn thông qua đầu cắm USB bên trong)
  • Kết nối I/O bên trong
  • 1 x đầu nối nguồn chính ATX 24 chân
    1 x đầu nối nguồn ATX 12V 8 chân
    1 x đầu cắm quạt CPU
    1 x đầu cắm quạt hệ thống
    1 x đầu nối M.2 Socket 3
    4 x đầu nối SATA 6Gb/s
    1 x đầu cắm bảng điều khiển phía trước
    1 x đầu cắm âm thanh bảng điều khiển phía trước
    1 x đầu cắm USB 3.2 Gen 1
    1 x đầu cắm USB 2.0/1.1
    1 x đầu cắm Mô-đun Nền tảng Tin cậy (Chỉ dành cho mô-đun GC-TPM2.0 SPI V2)
    1 x đầu cắm cổng nối tiếp
    1 x jumper Xóa CMOS
  • Kết nối bảng phía sau
  • 1 cổng DisplayPort (Lưu ý)
    1 cổng HDMI (Lưu ý)
    2 cổng USB 3.2 Gen 1
    4 cổng USB 2.0/1.1
    1 cổng RJ-45
    3 giắc cắm âm thanh

    (Lưu ý) Khả năng hỗ trợ thực tế có thể khác nhau tùy thuộc vào CPU.
  • Điều khiển I/O
  • Chip điều khiển I/O iTE®
  • Theo dõi phần cứng
  • Phát hiện
    điện áp Phát hiện nhiệt độ Phát hiện
    tốc độ quạt Phát hiện
    lưu lượng nước làm mát
    Cảnh báo lỗi quạt
    Điều khiển tốc độ quạt

    * Chức năng điều khiển tốc độ quạt có được hỗ trợ hay không sẽ phụ thuộc vào loại quạt bạn lắp đặt.

  • BIOS
  • 1 x bộ nhớ flash 256 Mbit.
    Sử dụng BIOS AMI UEFI được cấp phép.
    Hỗ trợ PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0.
  • Tính năng duy nhất
  • Hỗ trợ phần mềm GIGABYTE Control Center (GCC)

    * Các ứng dụng khả dụng trong GCC có thể khác nhau tùy thuộc vào kiểu bo mạch chủ. Các chức năng được hỗ trợ của mỗi ứng dụng cũng có thể khác nhau tùy thuộc vào thông số kỹ thuật của bo mạch chủ.


    Hỗ trợ Q-Flash,
    hỗ trợ Smart Backup.
  • Gói phần mềm

  • Phần mềm quản lý băng thông mạng LAN Norton® Internet Security (phiên bản OEM)
  • Hệ điều hành
  • Hỗ trợ Windows 11 64-bit
    Hỗ trợ Windows 10 64-bit

    * Trình điều khiển Intel® NPU chỉ được hỗ trợ trên Windows 11.

  • Hệ số khuôn
  • Chuẩn Micro ATX; kích thước 22,6cm x 18,5cm

Bo Mạch Chủ – MAINBOARD GIGABYTE H810M K DDR5

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte H81M-DS2 C.ty Renew 3 Năm

Bo Mạch Chủ – Mainboard Gigabyte H81M-DS2 C.ty Renew 3 Năm

Bo mạch chủ - Mainboard  GIGABYTE GIGABYTE H81M-DS2(V2.0) BOX MÀU CTY

Bo Mạch Chủ – Mainboard Gigabyte H81M-DS2 C.ty Renew 3 Năm

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte H81MDS2 (V2.0) CH VIỄN SƠN

Bo Mạch Chủ – Mainboard Gigabyte H81MDS2 (V2.0) CH VIỄN SƠN

Bo mạch chủ - Mainboard GIGABYTE GIGABYTE H81M-DS2(V2.0) VIỄN SƠN

Bo Mạch Chủ – Mainboard Gigabyte H81MDS2 (V2.0) CH VIỄN SƠN

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte H81MS2PV BOX MÀU CTY/3N

Bo Mạch Chủ – Mainboard Gigabyte H81MS2PV BOX MÀU CTY/3N

Bo Mạch Chủ – Mainboard Gigabyte H81MS2PV BOX MÀU CTY/3N

Liên hệ
Bo Mạch Chủ - MAINBOARD GIGABYTE MAINBOARD GIGABYTE B760M AORUS ELITE WIFI6E GEN5

Bo Mạch Chủ – MAINBOARD GIGABYTE MAINBOARD GIGABYTE B760M AORUS ELITE WIFI6E GEN5

  • Bộ xử lý
    Ổ cắm LGA1700: Hỗ trợ Bộ xử lý Intel® Core™, Pentium® Gold và Celeron® thế hệ thứ 14, 13 và 12
    (Truy cập trang web của GIGABYTE để biết danh sách hỗ trợ CPU mới nhất.)
    Bộ nhớ đệm L3 thay đổi tùy theo CPU
  • Bộ vi xử lý
    Chipset Intel® B760 Express
  • Ký ức
    Hỗ trợ cho các mô-đun bộ nhớ DDR5 7800(OC) / 7600(OC) / 7400(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5800(OC) / 5600(OC) / 5400(OC) / 5200(OC) / 4800 / 4000 MT/s
    4 x khe cắm DDR5 DIMM hỗ trợ bộ nhớ hệ thống lên đến 256 GB (dung lượng DIMM đơn 64 GB)
    Kiến trúc bộ nhớ kênh đôi
    Hỗ trợ cho các mô-đun bộ nhớ ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 (hoạt động ở chế độ không phải ECC)
    Hỗ trợ cho các mô-đun bộ nhớ non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16
    Hỗ trợ cho Mô-đun bộ nhớ Extreme Memory Profile (XMP)
    (Cấu hình CPU và bộ nhớ có thể ảnh hưởng đến các loại bộ nhớ được hỗ trợ, tốc độ dữ liệu và số lượng mô-đun DRAM, vui lòng tham khảo "Danh sách hỗ trợ bộ nhớ" trên trang web của GIGABYTE để biết thêm thông tin.)
  • Đồ họa tích hợp
    Bộ xử lý đồ họa tích hợp - Hỗ trợ đồ họa Intel® HD:
    - 1 cổng HDMI, hỗ trợ độ phân giải tối đa 4096x2160@60 Hz

    * Hỗ trợ phiên bản HDMI 2.1 và HDCP 2.3.
    ** Hỗ trợ các cổng tương thích HDMI 2.1 TMDS gốc.


    - 1 x DisplayPort, hỗ trợ độ phân giải tối đa 4096x2304@60 Hz

    * Hỗ trợ phiên bản DisplayPort 1.2 và HDCP 2.3


    (Thông số đồ họa có thể thay đổi tùy theo khả năng hỗ trợ của CPU.)
  • Âm thanh
    Realtek® Audio CODEC
    Âm thanh độ nét cao
    2/4/5.1/7.1 kênh

    * Bạn có thể thay đổi chức năng của giắc cắm âm thanh bằng phần mềm âm thanh. Để cấu hình âm thanh 7.1 kênh, hãy truy cập phần mềm âm thanh để cài đặt âm thanh.


    Hỗ trợ cho S/PDIF Out
  • Mạng LAN
    Chip LAN Realtek® 2.5GbE (2,5 Gbps/1 Gbps/100 Mbps)
  • Mô-đun truyền thông không dây
    Intel® Wi-Fi 6E AX210
    - WIFI a, b, g, n, ac, ax, hỗ trợ băng tần sóng mang 2,4/5/6 GHz
    - BLUETOOTH 5.3
    - Hỗ trợ chuẩn không dây 11ax 160MHz
    (Tốc độ dữ liệu thực tế có thể thay đổi tùy thuộc vào môi trường và thiết bị.)
  • Khe cắm mở rộng
    CPU:
    - 1 khe cắm PCI Express x16, hỗ trợ PCIe 5.0 và chạy ở x16 (PCIEX16)

    * Khe cắm PCIEX16 chỉ có thể hỗ trợ card đồ họa hoặc ổ SSD NVMe. Nếu chỉ lắp một card đồ họa, hãy đảm bảo lắp card đó vào khe cắm PCIEX16.


    Chipset:
    - 1 khe cắm PCI Express x16, hỗ trợ PCIe 4.0 và chạy ở tốc độ x4 (PCIEX4)
  • Giao diện lưu trữ
    CPU:
    - 1 x đầu nối M.2 (Ổ cắm 3, phím M, hỗ trợ SSD loại 2280 PCIe 4.0 x4/x2) (M2A_CPU)
    Bộ chip:
    - 1 x đầu nối M.2 (Ổ cắm 3, phím M, hỗ trợ SSD loại 22110/2280 PCIe 4.0 x4/x2) (M2P_SB)
    - 4 x đầu nối SATA 6Gb/s
    Hỗ trợ RAID 0, RAID 1, RAID 5 và RAID 10 cho các thiết bị lưu trữ SATA
  • USB
    Chipset:
    - 1 cổng USB Type-C® ở mặt sau, hỗ trợ USB 3.2 Gen 2x2
    - 1 cổng USB Type-C® hỗ trợ USB 3.2 Gen 2, có sẵn thông qua đầu cắm USB bên trong
    - 1 cổng USB 3.2 Gen 2 Type-A (màu đỏ) ở mặt sau
    - 1 cổng USB 3.2 Gen 1 ở mặt sau
    - 4 cổng USB 2.0/1.1 có sẵn thông qua đầu cắm USB bên trong
    Chipset + Hub USB 3.2 Gen 1:
    - 4 cổng USB 3.2 Gen 1 (2 cổng ở mặt sau, 2 cổng có sẵn thông qua đầu cắm USB bên trong)
    Chipset + Hub USB 2.0:
    - 4 cổng USB 2.0/1.1 ở mặt sau
  • Đầu nối I/O bên trong
    1 x đầu nối nguồn chính ATX 24 chân
    1 x đầu nối nguồn ATX 12V 8 chân
    1 x đầu nối nguồn ATX 12V 4 chân
    1 x đầu cắm quạt CPU
    3 x đầu cắm quạt hệ thống
    3 x đầu cắm dải đèn LED RGB Gen2 có thể định địa chỉ
    1 x đầu cắm dải đèn LED RGB
    2 x đầu nối M.2 Socket 3
    4 x đầu nối SATA 6Gb/s
    1 x đầu cắm mặt trước
    1 x đầu cắm âm thanh mặt trước
    1 x đầu cắm USB Type-C®, hỗ trợ USB 3.2 Gen 2
    1 x đầu cắm USB 3.2 Gen 1
    2 x đầu cắm USB 2.0/1.1
    2 x đầu nối card bổ sung Thunderbolt™
    1 x đầu cắm Trusted PlatformModule (Chỉ dành cho mô-đun GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2)
    1 x nút Q-Flash Plus
    1 x nút đặt lại
    1 x jumper đặt lại
    1 x Clear CMOS áo len
  • Đầu nối mặt sau
    2 x đầu nối ăng-ten (2T2R)
    1 x cổng USB Type-C®, hỗ trợ USB 3.2 Gen 2x2
    1 x cổng USB 3.2 Gen 2 Type-A (màu đỏ)
    3 x cổng USB 3.2 Gen 1
    4 x cổng USB 2.0/1.1
    1 x cổng HDMI (Lưu ý)
    1 x DisplayPort (Lưu ý)
    1 x cổng RJ-45
    1 x đầu nối quang S/PDIF Out
    2 x giắc cắm âm thanh

    (Lưu ý) Hỗ trợ thực tế có thể khác nhau tùy theo CPU.
  • Bộ điều khiển I/O
    Chip điều khiển I/O iTE®
  • Giám sát phần cứng
    Phát hiện điện áp
    Phát hiện nhiệt độ Phát hiện
    tốc độ quạt Phát
    hiện lưu lượng nước làm mát
    Cảnh báo lỗi quạt
    Kiểm soát tốc độ quạt

    * Chức năng điều khiển tốc độ quạt có được hỗ trợ hay không sẽ tùy thuộc vào quạt bạn lắp đặt.

  • BIOS
    1 x 256 Mbit flash
    Sử dụng AMI UEFI BIOS được cấp phép
    PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
  • Tính năng độc đáo
    Hỗ trợ cho Trung tâm điều khiển GIGABYTE (GCC)

    * Các ứng dụng khả dụng trong GCC có thể khác nhau tùy theo model bo mạch chủ. Chức năng được hỗ trợ của từng ứng dụng cũng có thể khác nhau tùy thuộc vào thông số kỹ thuật của bo mạch chủ.


    Hỗ trợ Q-Flash
    Hỗ trợ Q-Flash Plus
  • Phần mềm đóng gói

    Phần mềm quản lý băng thông LAN Norton® Internet Security (phiên bản OEM)
  • Hệ điều hành
    Hỗ trợ cho Windows 11 64-bit
    Hỗ trợ cho Windows 10 64-bit
  • Yếu tố hình thức
    Kích thước Micro ATX; 24,4cm x 24,4cm

Bo Mạch Chủ – MAINBOARD GIGABYTE MAINBOARD GIGABYTE B760M AORUS ELITE WIFI6E GEN5

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte MW51-HP0

Bo Mạch Chủ – Mainboard Gigabyte MW51-HP0

Intel® Xeon® W-series Processor Family
Intel® C422 Express Chipset
Quad Channel RDIMM/LRDIMM DDR4, 8 x DIMMs
Intel® VROC ready
ASMedia 2142 USB 3.1 Gen 3 controller
Realtek ALC1150 HD audio codec
2 x GbE LAN ports (Intel® I210)
8 x SATA III 6Gb/s ports from C422, supports SATA DOM
2 x SATA III 6Gb/s ports from Marvell® 88SE9172 controller
Ultra-Fast M.2 and U.2 with PCIe Gen3 x4 interface
4 x Full speed PCIe Gen3 x16 slots; total 7 x expansion PCIe slots

Bo Mạch Chủ – Mainboard Gigabyte MW51-HP0

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte TRX40 AORUS MASTER

Bo Mạch Chủ – Mainboard Gigabyte TRX40 AORUS MASTER

CPU AMD Socket sTRX4:
  1. Support 3rd Generation AMD Ryzen™ Threadripper™ processors
(Please refer "CPU Support List" for more information.)

Chipset

 AMD TRX40
Memory
  1. 8 x DDR4 DIMM sockets supporting up to 256 GB (32 GB single DIMM capacity) of system memory
  2. Quad Channel memory architecture
  3. Support for DDR4 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
  4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
  5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
  6. Support for Extreme Memory Profile (XMP) memory modules
  7.
Audio
  1. 1 x Realtek® ALC4050H codec+1 x Realtek® ALC1220-VB codec (Rear audio)
  2. 1 x Realtek® ALC4050H codec+1 x ESS SABRE9218 DAC chips (Front audio)
  3. Support for DTS:X® Ultra
  4. High Definition Audio
  5. 2/4/5.1/7.1-channel
  6. Support for S/PDIF Out
LAN
  1. 1 x Aquantia 5GbE LAN chip (5 Gbit/2.5 Gbit/1 Gbit/100 Mbit) (5GLAN)
  2. 1 x Intel® GbE LAN chip (10/100/1000 Mbit) (LAN)
Wireless Communication module Intel® Wi-Fi 6 AX200
  1. Wi-Fi 802.11a/b/g/n/ac/ax, supporting 2.4/5 GHz Dual-Band
  2. BLUETOOTH 5.0
  3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
    * Actual data rate may vary depending on environment and equipment.
Expansion Slots
  1. 2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
  2. 2 x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2)
  3. 1 x PCI Express x1 slot
    (All of the PCI Express slots conform to PCI Express 4.0 standard.)
Multi-Graphics Technology
  • Support for NVIDIA® Quad-GPU SLI™ and 3-Way/2-Way NVIDIA® SLI™ technologies
  • Support for AMD Quad-GPU CrossFire™ and 3-Way/2-Way AMD CrossFire™ technologies
Storage Interface Integrated in the CPU:
  1. 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support) (M2M)
  2. 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2Q)
Integrated in the Chipset:
  1. 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2P)
  2. 8 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, and RAID 10
USB Integrated in the CPU:
  1. 4 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
Integrated in the Chipset:
  1. 1 x USB Type-C™ port on the back panel, with USB 3.2 Gen 2 support
  2. 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
  3. 1 x USB Type-C™ port with USB 3.2 Gen 2 support, available through the internal USB header
  4. 4 x USB 3.2 Gen 1 ports available through the internal USB headers
Chipset+2 USB 2.0 Hubs:
  1. 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
Internal I/O Connectors
  1. 1 x 24-pin ATX main power connector
  2. 2 x 8-pin ATX 12V power connectors
  3. 1 x CPU fan header
  4. 1 x water cooling CPU fan header
  5. 2 x system fan headers
  6. 4 x system fan/water cooling pump headers
  7. 2 x addressable LED strip headers
  8. 2 x RGB LED strip headers
  9. 3 x M.2 Socket 3 connectors
  10. 8 x SATA 6Gb/s connectors
  11. 1 x front panel header
  12. 1 x front panel audio header
  13. 1 x USB Type-C™ port, with USB 3.2 Gen 2 support
  14. 2 x USB 3.2 Gen 1 headers
  15. 2 x USB 2.0/1.1 headers
  16. 1 x noise detection header
  17. 1 x GIGABYTE add-in card connector
  18. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
  19. 1 x power button
  20. 1 x reset button
  21. 2 x BIOS switches
  22. 2 x temperature sensor headers
  23. 1 x Clear CMOS jumper
  24. Voltage Measurement Points
Back Panel Connectors
  1. 1 x Q-Flash Plus button
  2. 1 x Clear CMOS button
  3. 2 x SMA antenna connectors (2T2R)
  4. 1 x USB Type-C™ port, with USB 3.1 Gen 2 support
  5. 5 x USB 3.2 Gen 2 Type-A ports (red)
  6. 2 x USB 2.0/1.1 ports
  7. 2 x RJ-45 ports
  8. 1 x optical S/PDIF Out connector
  9. 5 x audio jacks
I/O Controller iTE® I/O Controller Chip
H/W Monitoring
  1. Voltage detection
  2. Temperature detection
  3. Fan speed detection
  4. Water cooling flow rate detection
  5. Overheating warning
  6. Fan fail warning
  7. Fan speed control
    * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
  8. Noise detection
BIOS
  1. 2 x 128 Mbit flash
  2. Use of licensed AMI UEFI BIOS
  3. Support for DualBIOS™
  4. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features
  • Support for APP Center
    * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
    @BIOS
    AutoGreen
    Cloud Station EasyTune
    Fast Boot
    Game Boost
    RGB Fusion
    Smart Backup
    Smart Keyboard
    Smart Survey
    System Information Viewer
    USB Blocker
    USB TurboCharger
  • Support for Q-Flash Plus
  • Support for Q-Flash
  • Support for Xpress Install
Bundled Software
  1. Norton® Internet Security (OEM version)
  2. cFosSpeed
  3. XSplit Gamecaster + Broadcaster (12 months license)
Operating System Support for Windows 10 64-bit
Form Factor E-ATX Form Factor; 30.5cm x 26.9cm

Bo Mạch Chủ – Mainboard Gigabyte TRX40 AORUS MASTER

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte TRX40 AORUS PRO WIFI

Bo Mạch Chủ – Mainboard Gigabyte TRX40 AORUS PRO WIFI

CPU AMD Socket sTRX4:
Support 3rd Generation AMD Ryzen™ Threadripper™ processors

Chipset

 AMD TRX40
Memory
  1. 8 x DDR4 DIMM sockets supporting up to 256 GB (32 GB single DIMM capacity) of system memory
  2. Quad Channel memory architecture
  3. Support for DDR4 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
  4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
  5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
  6. Support for Extreme Memory Profile (XMP) memory modules
Audio
  1. Realtek® ALC4050H codec+ ALC1220-VB codec
  2. Support for DTS:X® Ultra
  3. High Definition Audio
  4. 2/4/5.1/7.1-channel
  5. Support for S/PDIF Out
LAN Intel® GbE LAN chip (10/100/1000 Mbit)
Wireless Communication module Intel® Wi-Fi 6 AX200
  1. Wi-Fi 802.11a/b/g/n/ac/ax, supporting 2.4/5 GHz Dual-Band
  2. BLUETOOTH 5.0
  3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
    * Actual data rate may vary depending on environment and equipment.
Expansion Slots
  1. 2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
  2. 2 x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2)
  3. 1 x PCI Express x1 slot
    (All of the PCI Express slots conform to PCI Express 4.0 standard.)
Multi-Graphics Technology
  • Support for AMD Quad-GPU CrossFire™ and 3-Way/2-Way AMD CrossFire™ technologies
  • Support for NVIDIA® Quad-GPU SLI™ and3-Way/2-Way NVIDIA® SLI™ technologies
Storage Interface CPU:
  1. 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support) (M2M)
  2. 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2Q)
Chipset:
  1. 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2P)
  2. 8 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, and RAID 10
USB CPU:
  1. 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
  2. 1 x USB Type-C™ port on the back panel, with USB 3.2 Gen 2 support
Chipset:
  1. 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
  2. 1 x USB Type-C™ port with USB 3.2 Gen 2/Gen 1 support, available through the internal USB header
  3. 4 x USB 3.2 Gen 1 ports available through the internal USB headers
Chipset+2 USB 2.0 Hubs:
  1. 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
Internal I/O Connectors
  1. 1 x 24-pin ATX main power connector
  2. 1 x 8-pin ATX 12V power connector
  3. 1 x 4-pin ATX 12V power connector
  4. 1 x CPU fan header
  5. 1 x water cooling CPU fan header
  6. 2 x system fan headers
  7. 4 x system fan/water cooling pump headers
  8. 2 x addressable LED strip headers
  9. 2 x RGB LED strip headers
  10. 3 x M.2 Socket 3 connectors
  11. 8 x SATA 6Gb/s connectors
  12. 1 x front panel header
  13. 1 x front panel audio header
  14. 1 x USB Type-C™ header, with USB 3.2 Gen 1/Gen 2 support
  15. 2 x USB 3.2 Gen 1 headers
  16. 2 x USB 2.0/1.1 headers
  17. 1 x GIGABYTE add-in card connector
  18. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
  19. 2 x temperature sensor headers
  20. 1 x Clear CMOS jumper
Back Panel Connectors
  1. 4 x USB 2.0/1.1 ports
  2. 1 x Q-Flash Plus button
  3. 5 x USB 3.2 Gen 2 Type-A ports (red)
  4. 1 x USB Type-C™ port, with USB 3.2 Gen 2 support
  5. 1 x RJ-45 port
  6. 2 x SMA antenna connectors (2T2R)
  7. 1 x optical S/PDIF Out connector
  8. 5 x audio jacks
I/O Controller iTE® I/O Controller Chip
H/W Monitoring
  1. Voltage detection
  2. Temperature detection
  3. Fan speed detection
  4. Water cooling flow rate detection
  5. Overheating warning
  6. Fan fail warning
  7. Fan speed control
    * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
BIOS
  1. 2 x 128 Mbit flash
  2. Use of licensed AMI UEFI BIOS
  3. Support for DualBIOS™
  4. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features
  1. Support for APP Center
    * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
    @BIOS
    AutoGreen
    Cloud Station
    EasyTune
    Fast Boot
    Game Boost
    ON/OFF Charge
    RGB Fusion
    Smart Backup
    Smart Keyboard
    Smart Survey
    System Information Viewer
    USB Blocker
  2. Support for Q-Flash Plus
  3. Support for Q-Flash
  4. Support for Xpress Install
Bundled Software
  1. Norton® Internet Security (OEM version)
  2. cFosSpeed
  3. XSplit Gamecaster + Broadcaster (12 months license)
Operating System Support for Windows 10 64-bit
Form Factor ATX Form Factor; 30.5cm x 24.4cm

Bo Mạch Chủ – Mainboard Gigabyte TRX40 AORUS PRO WIFI

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte TRX40 AORUS XTREME

Bo Mạch Chủ – Mainboard Gigabyte TRX40 AORUS XTREME

CPU AMD Socket sTRX4:
  1. Support 3rd Generation AMD Ryzen™ Threadripper™ processors
(Please refer "CPU Support List" for more information.)

Chipset

 AMD TRX40
Memory
  1. 8 x DDR4 DIMM sockets supporting up to 256 GB (32 GB single DIMM capacity) of system memory
  2. Quad Channel memory architecture
  3. Support for DDR4 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
  4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
  5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
  6. Support for Extreme Memory Profile (XMP) memory modules
Audio
  1. Realtek® ALC4050H codec+Realtek® ALC1220-VB codec (rear panel audio)
  2. Realtek® ALC4050H codec+ESS SABRE9218 DAC (front panel audio)
  3. Support for DTS:X® Ultra
  4. High Definition Audio
  5. 2/4/5.1/7.1-channel
  6. Support for S/PDIF Out
LAN Intel® 10GbE LAN chip (10 Gbit/5 Gbit/2.5 Gbit/1 Gbit/100 Mbit), supporting 2 RJ-45 ports
Wireless Communication module Intel® Wi-Fi 6 AX200
  1. Wi-Fi 802.11a/b/g/n/ac/ax, supporting 2.4/5 GHz Dual-Band
  2. BLUETOOTH 5.0
  3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
    * Actual data rate may vary depending on environment and equipment.
Expansion Slots
  1. 2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)
  2. 2 x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2)
    (The PCIEX16 and PCIEX8 slots conform to PCI Express 4.0 standard.)
Multi-Graphics Technology
  1. Support for AMD Quad-GPU CrossFire™ and 4-Way/3-Way/2-Way AMD CrossFire™ technologies
  2. Support for NVIDIA® Quad-GPU SLI™ and 4-Way/3-Way/2-Way NVIDIA® SLI™ technologies
Storage Interface CPU:
  1. 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support) (M2M)
  2. 1 x M.2 connector (Socket 3, M key, type 2280/22110 SATA and PCIe 4.0 x4/x2 SSD support) (M2Q)
Chipset:
  1. 1 x M.2 connector (Socket 3, M key, type 2280/22110 SATA and PCIe 4.0 x4/x2 SSD support) (M2P)
  2. 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2C_SOCKET)
  3. 8 x SATA 6Gb/s connectors (SATA3 0~7)
    * Refer to "1-9 Internal Connectors," for the installation notices for the M.2 and SATA connectors.
Support for RAID 0, RAID 1, and RAID 10

ASMedia® SATA 6Gb/s Controller:
  1. 2 x SATA 6Gb/s connectors (SATA3 8, 9), supporting AHCI mode only
USB CPU:
  1. 4 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
Chipset:
  1. 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
  2. 1 x USB Type-C™ port with USB 3.2 Gen 2 support, available through the internal USB header
  3. 4 x USB 3.2 Gen 1 ports available through the internal USB headers
Chipset+1 USB 2.0 Hub:
  1. 4 x USB 2.0/1.1 ports available through the internal USB headers (with the included front USB header extention cable)
Chipset+ASMedia® USB 3.2 Gen 2 Controller:
  1. 1 x USB Type-C™ port on the back panel, with USB 3.2 Gen 2 support
  2. 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
Internal I/O Connectors
  1. 1 x 24-pin ATX main power connector
  2. 2 x 8-pin ATX 12V power connectors
  3. 1 x OC_PEG power connector
  4. 1 x CPU fan header
  5. 1 x water cooling CPU fan header
  6. 2 x system fan headers
  7. 3 x system fan/water cooling pump headers
  8. 2 x addressable LED strip headers
  9. 2 x RGB LED strip headers
  10. 4 x M.2 Socket 3 connectors
  11. 10 x SATA 6Gb/s connectors
  12. 1 x front panel header
  13. 1 x front panel audio header
  14. 1 x USB Type-C™ header, with USB 3.2 Gen 2 support
  15. 2 x USB 3.2 Gen 1 headers
  16. 1 x USB 2.0/1.1 header
  17. 1 x GIGABYTE add-in card connector
  18. 1 x noise detection header
  19. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
  20. 1 x power button
  21. 1 x reset button
  22. 2 x temperature sensor headers
  23. 2 x BIOS switches
  24. Voltage Measurement Points
  25.
Back Panel Connectors
  1. 1 x Q-Flash Plus button
  2. 1 x Clear CMOS button
  3. 2 x SMA antenna connectors (2T2R)
  4. 1 x USB Type-C™ port, with USB 3.2 Gen 2 support
  5. 7 x USB 3.2 Gen 2 Type-A ports (red)
  6. 2 x RJ-45 ports
  7. 1 x optical S/PDIF Out connector
  8. 5 x audio jacks
I/O Controller iTE® I/O Controller Chip
H/W Monitoring
  1. Voltage detection
  2. Temperature detection
  3. Fan speed detection
  4. Water cooling flow rate detection
  5. Overheating warning
  6. Fan fail warning
  7. Fan speed control
    * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
  8. Noise detection
BIOS
  1. 2 x 128 Mbit flash
  2. Use of licensed AMI UEFI BIOS
  3. Support for DualBIOS™
  4. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features
  1. Support for APP Center
    * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
    @BIOS
    AutoGreen
    Cloud Station
    EasyTune
    Fast Boot
    Game Boost
    RGB Fusion
    Smart Backup
    Smart Keyboard
    Smart Survey
    System Information Viewer
    USB Blocker
    USB TurboCharger
  2. Support for Q-Flash Plus
  3. Support for Q-Flash
  4. Support for Xpress Install
Bundled Software
  1. Norton® Internet Security (OEM version)
  2. cFosSpeed
  3. XSplit Gamecaster + Broadcaster (12 months license)
Operating System Support for Windows 10 64-bit
Form Factor

XL-ATX Form Factor; 32.5cm x 27.5cm

Bo Mạch Chủ – Mainboard Gigabyte TRX40 AORUS XTREME

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte TRX40 DESIGNARE

Bo Mạch Chủ – Mainboard Gigabyte TRX40 DESIGNARE

Sản phẩm Mainboard - Bo mạch chủ
Tên Hãng Gigabyte
Model TRX40 DESIGNARE
CPU hỗ trợ AMD Socket sTRX4:
Support 3rd Generation AMD Ryzen™ Threadripper™ processors
Chipset AMD TRX40
RAM hỗ trợ

8 x DDR4 DIMM sockets supporting up to 256 GB (32 GB single DIMM capacity) of system memory

Quad Channel memory architecture

Support for DDR4 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules

Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules

Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for Extreme Memory Profile (XMP) memory modules
Âm Thanh

Realtek® ALC4050H codec+ Realtek® ALC1220-VB codec

Support for DTS:X® Ultra

High Definition Audio

2/4/5.1/7.1-channel

Support for S/PDIF Out
LAN / Wireless / Bluetooth

2 x Intel® GbE LAN chip (10/100/1000 Mbit)

Intel® Wi-Fi 6 AX200

Wi-Fi 802.11a/b/g/n/ac/ax, supporting 2.4/5 GHz Dual-Band

BLUETOOTH 5.0

Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
* Actual data rate may vary depending on environment and equipment.
Khe cắm mở rộng

2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2)

2 x PCI Express x16 slots, running at x8 (PCIEX8_1, PCIEX8_2)

1 x PCI Express x1 slot
(All of the PCI Express slots conform to PCI Express 4.0 standard.)

Công nghệ đa card đồ họa

Support for AMD Quad-GPU CrossFire™ and 4-Way/3-Way/2-Way AMD CrossFire™ technologies

Support for NVIDIA® Quad-GPU SLI™ and 4-Way/3-Way/2-Way NVIDIA® SLI™ technologies
Ổ cứng hỗ trợ

CPU:

1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support) (M2M)

1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 4.0 x4/x2 SSD support) (M2Q)

Chipset:

1 x M.2 connector (Socket 3, M key, type 2280/22110 SATA and PCIe 4.0 x4/x2 SSD support) (M2P)

1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2C)

8 x SATA 6Gb/s connectors

Support for RAID 0, RAID 1, and RAID 10
USB

CPU:

4 x USB 3.2 Gen 2 Type-A ports (red) on the back panel

Chipset:

1 x USB Type-C™ port on the back panel, with USB 3.2 Gen 2 support

1 x USB Type-C™ port with USB 3.2 Gen 2 support, available through the internal USB header

1 x USB 3.2 Gen 2 Type-A port (red) on the back panel

4 x USB 3.2 Gen 1 ports available through the internal USB headers

Chipset+2 USB 2.0 Hubs:

6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
Cổng kết nối (Bên Trong)

1 x 24-pin ATX main power connector

2 x 8-pin ATX 12V power connectors

1 x OC_PEG power connector

1 x CPU fan header

1 x water cooling CPU fan header

2 x system fan headers

4 x system fan/water cooling pump headers

2 x addressable LED strip headers

2 x RGB LED strip headers

4 x M.2 Socket 3 connectors

8 x SATA 6Gb/s connectors

1 x front panel header

1 x front panel audio header

1 x USB Type-C™ header, with USB 3.2 Gen 2 support

2 x USB 3.2 Gen 1 headers

2 x USB 2.0/1.1 headers

1 x GIGABYTE GC-TITAN RIDGE Add-in Card Connector

1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)

1 x power button

1 x reset button

2 x temperature sensor headers

1 x Clear CMOS jumper
Cổng kết nối (Phía Sau)

1 x Q-Flash Plus button

1 x Clear CMOS button

1 x USB Type-C™ port, with USB 3.2 Gen 2 support

5 x USB 3.2 Gen 2 Type-A ports (red)

2 x USB 2.0/1.1 ports

2 x RJ-45 ports

2 x SMA antenna connectors (2T2R)

1 x optical S/PDIF Out connector

5 x audio jacks
Điều khiển I/O

iTE® I/O Controller Chip

Theo dõi phần cứng

Voltage detection

Temperature detection

Fan speed detection

Water cooling flow rate detection

Overheating warning

Fan fail warning

Fan speed control
* Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
BIOS

2 x 128 Mbit flash

Use of licensed AMI UEFI BIOS

Support for DualBIOS™

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Tính năng duy nhất

Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
@BIOS
AutoGreen
Cloud Station
EasyTune
Fast Boot
Game Boost
RGB Fusion
Smart Backup
Smart Keyboard
Smart Survey
System Information Viewer
USB Blocker
USB TurboCharger

Support for Q-Flash Plus

Support for Q-Flash

Support for Xpress Install
Kích cỡ XL-ATX Form Factor; 32.5cm x 26.9cm

Bo Mạch Chủ – Mainboard Gigabyte TRX40 DESIGNARE

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte WRX80-SU8-IPMI

Bo Mạch Chủ – Mainboard Gigabyte WRX80-SU8-IPMI

  • CPU

    1. Ryzen™ Threadripper™ PRO 3000WX (up to 64C)
    2. Single sWRX8 4094 socket; CPU TDP supports up to 280W

  • Chipset

    1. AMD WRX80 Chipset

  • Memory

    1. 8 x DDR4 DIMM slots supports
    2. 8 channels memory architecture (1 DIMM per channel)
    3. Support up to DDR4 3200/2933/2600 MHz
    4. Support for UDIMM (ECC), RDIMM, 3DS RDIMM and LRDIMM memory modules
    5. Support system memory capacity up to 1024GB

  • Audio

    1. Realtek® ALC1220-VB codec
    2. High Definition Audio
    3. 2/4/5.1/7.1-channel
    4. Support for S/PDIF Out

  • LAN

    1. Dual Intel® X550 10GbE LAN
    2. Dual Intel® i210AT GbE LAN (NCSI MLAN)

  • Expansion Slots

    (Slot7) PCIe x16 (running at Gen4 x16)
    (Slot6) PCIe x16 (running at Gen4 x16)
    (Slot5) PCIe x16 (running at Gen4 x16)
    (Slot4) PCIe x16 (running at Gen4 x16)
    (Slot3) PCIe x16 (running at Gen4 x16)
    (Slot2) PCIe x16 (running at Gen4 x8)
    (Slot1) PCIe x16 (running at Gen4 x16)

  • Storage Interface

    1. 4 x SATA 6Gb/s connectors (support software RAID 0; RAID1; RAID5; RAID10)
    2. 2 x M.2 Connectors (Socket 3; M key; Form Factor 2242/2280 ; Supports PCIe gen4 x4 or SATA mode)
    3. 2 x slimSAS (PCIe gen4 x4 or 4x SATAIII) + 1 x slimSAS (PCIe gen4 x4) connectors

  • USB

    1. 1 x USB Type-C™ port on the back panel, with USB 3.2 Gen 2 support
    2. 5 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
    3. 1 x USB Type-C™ header onboard, with USB3.2 Gen2 support
    4. 2 x USB 3.2 Gen 1 header onboard
    5. 1 x USB 3.2 Gen 1 vertical connector onboard
    6. 1 x USB 2.0 header on board

  • Internal I/O Connectors

    1. 1 x 24-pin ATX main power connector
    2. 1 x 8-pin ATX 12V CPU power connector
    3. 1 x 8-pin ATX 12V GPU power connector
    4. 1 x CPU fan header
    5. 6 x system fan headers
    6. 4 x SATA 6Gb/s connectors
    7. 2 x M.2 Socket 3 connectors
    8. 3 x slimSAS connectors
    9. 1 x front panel header
    10. 1 x front panel audio header
    11. 1 x USB Type-C™ header, with USB 3.2 Gen 2 support
    12. 1 x USB 3.2 Gen 1 vertical connector
    13. 2 x USB 3.2 Gen 1 header
    14. 1 x USB 2.0 header
    15. 1 x Thunderbolt™ add-in card connector
    16. 1 x Trusted Platform Module(TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
    17. 1 x serial port header
    18. 1 x chassis intrusion header
    19. 1 x Clear CMOS jumper
    20. 2 x SATA SGPIO headers
    21. 1 x BMC_VGA jumper
    22. 1 x BMC_WATCHD jumper
    23. 1 x SMB_IPMB connector
    24. 1 x PMBUS header
    25. 1 x Speaker

  • Back Panel Connectors

    1. 1 x D-sub port
    2. 1 x serial port
    3. 1 x USB 3.2 Gen 2 Type-C port (red)
    4. 5 x USB 3.2 Gen 2 Type-A port (red)
    5. 2 x GbE RJ-45 ports
    6. 2 x 10GbE RJ-45 ports
    7. 1 x optical S/PDIF Out connector
    8. 5 x audio jacks

  • I/O Controller

    1. ASPEED® AST2500 BMC chip

  • H/W Monitoring

    1. Voltage detection
    2. Temperature detection
    3. Fan speed detection
    4. Fan speed control
      * Whether the fan speed control function is supported will depend on the fan you install.

  • Operating Properties

    1. Operating temperature: 10°C to 40°C
    2. Operating humidity: 8 - 80%
    3. Non-operating temperature: -40°C to 70°C
    4. Non-operating humidity: 5% - 95%

  • Form Factor

    1. CEB Form Factor; 30.5cm x 26.7cm

  • Support OS

    1. Windows 10
    2. Linux

Bo Mạch Chủ – Mainboard Gigabyte WRX80-SU8-IPMI

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte X399 AORUS EXTREME(AMD)

Bo Mạch Chủ – Mainboard Gigabyte X399 AORUS EXTREME(AMD)

  • Supports AMD 2nd Generation Ryzen™ Threadripper™ and 1st Generation Ryzen™ Threadripper™ Processors
  • Quad Channel ECC/ Non-ECC Unbuffered DDR4, 8 DIMMs, Up to 3600MHz+(OC)/ 3466MHz+(OC)
  • Server-Class Digital Power PWM Design & Ultra Durable™ Solid Pin Power Connectors
  • Cutting-edge Thermal Design with Fins-Array Heatsink and Direct Touch Heatpipe
  • 4-Way Graphics Support with Dual Armor and Ultra Durable™ Design
  • Triple Ultra-Fast NVMe PCIe Gen3 x4 M.2 with Triple Thermal Guard
  • Dual Intel GbE LAN with cFosSpeed Internet Accelerator + AQUANTIA® 10GbE BASE-T LAN
  • ALC1220-VB Enhance 114dB(Rear)/ 110dB(Front) SNR in Microphone with ESS 9118 SABRE HiFi DAC
  • Intel® Dual Band 802.11ac WIFI + Bluetooth 4.2
  • RGB FUSION with Multi-Zone Digital LED Light Show Design, Supports Addressable LED & RGB LED Strips
  • Smart Fan 5 Features Multiple Temperature Sensors and Hybrid Fan Headers with FAN STOP
  • Precise Digital USB Fuse Design for Stronger Protection
  • Ultra Durable™ NanoCarbon Base Plate & I/O Shield Armor
  • Rear Power/Reset/Clear CMOS Buttons
  • APP Center Including EasyTune™ and Cloud Station™ Utilities

Bo Mạch Chủ – Mainboard Gigabyte X399 AORUS EXTREME(AMD)

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte X570S AERO G

Bo Mạch Chủ – Mainboard Gigabyte X570S AERO G

  • CPU

    1. AMD Socket AM4, support for: AMD Ryzen™ 5000 Series Processors/ AMD Ryzen™ 4000 G-Series Processors/ AMD Ryzen™ 3000 Series Processors/ AMD Ryzen™ 3000 G-Series Processors/ AMD Ryzen™ 2000 Series Processors/ AMD Ryzen™ 2000 G-Series Processors
    (Please refer "CPU Support List" for more information.)

  • Chipset

    1. AMD X570

  • Memory

    1. AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 3000 Series Processors:
      Support for DDR4 3200/2933/2667/2400/2133 MHz memory modules
    2. AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000 Series Processors/AMD Ryzen™ 2000 G-Series Processors:
      Support for DDR4 2933/2667/2400/2133 MHz memory modules
    3. 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
    4. Dual channel memory architecture
    5. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
    6. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    7. Support for Extreme Memory Profile (XMP) memory modules
    (Please refer "Memory Support List" for more information.)

  • Onboard Graphics

    Integrated Graphics Processor:
    1. 1 x USB Type-C® port, supporting USB Type-C® and DisplayPort video outputs and a maximum resolution of 4096x2304@60 Hz
      * Support for drawing tablets and 20V@3A of power delivery.
      * Support for DisplayPort 1.4 version and HDCP 2.3
    2. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
      * Support for HDMI 2.1 version, HDCP 2.3, and HDR.
    Maximum shared memory of 16 GB
    * For AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000 G-Series Processors only.

  • Audio

    1. Realtek® ALC1220-VB Audio CODEC
      * The back panel line out jack supports DSD audio.
    2. Support for DTS:X® Ultra
    3. High Definition Audio
    4. 2/4/5.1/7.1-channel
    5. Support for S/PDIF Out

  • LAN

    1. Intel® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

  • Wireless Communication module

    Intel® Wi-Fi 6 AX200
    1. WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz Dual-Band
    2. BLUETOOTH 5.1
    3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
      * Actual data rate may vary depending on environment and equipment.

  • Expansion Slots

    1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
    1. AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors support PCIe 4.0 x16 mode
    2. AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 2000 Series Processors support PCIe 3.0 x16 mode
    3. AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000 G-Series Processors support PCIe 3.0 x8 mode
    1 x PCI Express x16 slot (PCIEX8), integrated in the CPU:
    1. AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors support PCIe 4.0 x8 mode
    2. AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 2000 Series Processors support PCIe 3.0 x8 mode
    3. AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000 G-Series Processors do not support this slot
      * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
      * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode.
    1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset:
    1. Supporting PCIe 4.0* /3.0 x4 mode
      * For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors only.
      * The PCIEX4 slot shares bandwidth with the M2C_SB connector. The PCIEX4 slot becomes unavailable when a device is installed in the M2C_SB connector.

  • Multi-Graphics Technology

    1. Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies
    * For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 3000 Series Processors/AMD Ryzen™ 2000 Series Processors only.

  • Storage Interface

    1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2280/22110 SSDs:
    1. AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors support SATA and PCIe 4.0 x4/x2 SSDs
    2. AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 3000 G-Series Processors/ AMD Ryzen™ 2000 Series Processors/AMD Ryzen™ 2000 G-Series Processors support SATA and PCIe 3.0 x4/x2 SSDs
    1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2280/22110 SSDs:
    1. Supporting PCIe 4.0* /3.0 x4/x2 SSDs
      * For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors only.
    1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2280/22110 SSDs:
    1. Supporting SATA and PCIe 4.0* /3.0 x4/x2 SSDs
      * For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors only.
    1 x M.2 connector (M2D_SB), integrated in the Chipset, supporting Socket 3, M key, type 2280/22110 SSDs:
    1. Supporting SATA and PCIe 4.0* /3.0 x4/x2 SSDs
      * For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors only.
    6 x SATA 6Gb/s connectors, integrated in the Chipset:
    1. Support for RAID 0, RAID 1, and RAID 10
      * Refer to "1-8 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

  • USB

    CPU:
    1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 1 support
    2. 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
    3. 2 x USB 3.2 Gen 1 ports on the back panel
    Chipset+ASMedia® USB 3.2 Gen 2x2 Controller:
    1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2x2 support
    Chipset:
    1. 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
    2. 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
    3. 4 x USB 3.2 Gen 1 ports available through the internal USB headers
    Chipset+2 USB 2.0 Hubs:
    1. 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

  • Internal I/O Connectors

    1. 1 x 24-pin ATX main power connector
    2. 1 x 8-pin ATX 12V power connector
    3. 1 x 4-pin ATX 12V power connector
    4. 1 x CPU fan header
    5. 1 x water cooling CPU fan header
    6. 4 x system fan headers
    7. 2 x system fan/water cooling pump headers
    8. 2 x addressable LED strip headers
    9. 2 x RGB LED strip headers
    10. 1 x CPU cooler LED strip/RGB LED strip header
    11. 4 x M.2 Socket 3 connectors
    12. 6 x SATA 6Gb/s connectors
    13. 1 x front panel header
    14. 1 x front panel audio header
    15. 1 x USB Type-C® header, with USB 3.2 Gen 2 support
    16. 2 x USB 3.2 Gen 1 headers
    17. 2 x USB 2.0/1.1 headers
    18. 1 x noise detection header
    19. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
    20. 1 x Thunderbolt™ add-in card connector
    21. 1 x serial port header
    22. 1 x Clear CMOS jumper
    23. 2 x temperature sensor headers
    24. 1 x Q-Flash Plus button

  • Back Panel Connectors

    1. 2 x USB 2.0/1.1 ports
    2. 2 x SMA antenna connectors (2T2R)Š Š 1 x HDMI port
    3. 1 x DisplayPort In port
    4. 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support
    5. 1 x USB Type-C® port, with USB 3.2 Gen 1 support
    6. 4 x USB 3.2 Gen 2 Type-A ports (red)
    7. 2 x USB 3.2 Gen 1 ports
    8. 1 x RJ-45 port
    9. 1 x optical S/PDIF Out connector
    10. 5 x audio jacks

  • I/O Controller

    1. iTE® I/O Controller Chip

  • H/W Monitoring

    1. Voltage detection
    2. Temperature detection
    3. Fan speed detection
    4. Water cooling flow rate detection
    5. Fan fail warning
    6. Fan speed control
      * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
    7. Noise detection

  • BIOS

    1. 1 x 256 Mbit flash
    2. Use of licensed AMI UEFI BIOS
    3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

  • Unique Features

    1. Support for APP Center
      * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
      @BIOS
      EasyTune
      Fast Boot
      Game Boost
      ON/OFF Charge
      RGB Fusion
      Smart Backup
      System Information Viewer
    2. Support for Q-Flash Plus
    3. Support for Q-Flash
    4. Support for Xpress Install

  • Bundled Software

    1. Norton® Internet Security (OEM version)
    2. cFosSpeed

  • Operating System

    1. Support for Windows 10 64-bit

  • Form Factor

    1. ATX Form Factor; 30.5cm x 24.4cm

Bo Mạch Chủ – Mainboard Gigabyte X570S AERO G

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte X570S AORUS ELITE

Bo Mạch Chủ – Mainboard Gigabyte X570S AORUS ELITE

  • Hãng sản xuất: Gigabyte
  • Tình trạng: mới 100%
  • Bảo hành: 36 tháng
  • Khe ram tối đa: 4 khe
  • Hỗ trợ RAM: DDR4 , tối đa 128GB
  • Chuẩn mainboard: ATX
  • Socket: AM4 , Chipset : X570
  • CPU hỗ trợ:
    – AMD Socket AM4, hỗ trợ: AMD Ryzen ™ 5000 Series / Ryzen ™ 5000 G-Series / AMD Ryzen ™ 4000 G-Series / AMD Ryzen ™ 3000 Series / AMD Ryzen ™ 3000 G-Series / AMD Ryzen ™ 2000 Series / AMD Ryzen ™ Bộ xử lý 2000 G-Series
  • RAM hỗ trợ:
    – Bộ xử lý AMD Ryzen ™ 5000 G-Series:
    Hỗ trợ DDR4 5300 (OC) / 5100 (OC) / 5000 (OC) / 4866 (OC) / 4600 (OC) / 4400 (OC) / 4300 (OC) / 4266 (OC ) / 4133 (OC) / 4000 (OC) / 3866 (OC) / 3800 (OC) / 3733 (OC) / 3600 (OC) / 3466 (OC) / 3400 (OC) / 3333 (OC) / 3300 (OC) ) / 3200/2933/2667/2400/2133 MHz mô-đun bộ nhớ
    – Bộ xử lý AMD Ryzen ™ 5000 Series:
    Hỗ trợ DDR4 5100 (OC) / 5000 (OC) / 4866 (OC) / 4600 (OC) / 4400 (OC) / 4300 (OC) / 4266 (OC) / 4133 (OC) / 4000 (OC) / 3866 (OC) / 3800 (OC) / 3733 (OC) / 3600 (OC) / 3466 (OC) / 3400 (OC) / 3333 (OC) / 3300 (OC) / 3200/2933/2667 / 2400/2133 MHz mô-đun bộ nhớ
    – Bộ xử lý AMD Ryzen ™ 4000 G-Series:
    Hỗ trợ DDR4 5400 (OC) / 5200 (OC) / 5000 (OC) / 4866 (OC) / 4600 (OC) / 4400 (OC) / 4300 (OC) / 4266 (OC ) / 4133 (OC) / 4000 (OC) / 3866 (OC) / 3800 (OC) / 3733 (OC) / 3600 (OC) / 3466 (OC) / 3400 (OC) / 3333 (OC) / 3300 (OC) ) / 3200/2933/2667/2400/2133 MHz mô-đun bộ nhớ
    – Bộ xử lý AMD Ryzen ™ 3000 Series:
    Hỗ trợ DDR4 5200 (OC) / 5000 (OC) / 4866 (OC) / 4600 (OC) / 4400 (OC) / 4300 (OC) / 4266 (OC) / 4133 (OC) / 4000 (OC) / 3866 (OC) / 3800 (OC) / 3733 (OC) / 3600 (OC) / 3466 (OC) / 3400 (OC) / 3333 (OC) / 3300 (OC) / 3200/2933/2667 / 2400/2133 MHz mô-đun bộ nhớ
    – Bộ xử lý AMD Ryzen ™ 3000 G-Series / Bộ xử lý AMD Ryzen ™ 2000 Series / Bộ xử lý AMD Ryzen ™ 2000 G-Series:
    Hỗ trợ DDR4 3600 (OC) / 3466 (OC) / 3400 (OC) / 3333 (OC) / 3300 ( Các mô-đun bộ nhớ OC) / 3200 (OC) / 2933/2667/2400/2133 MHz
    – 4 x ổ cắm DDR4 DIMM hỗ trợ bộ nhớ hệ thống lên đến 128 GB (32 GB dung lượng DIMM đơn)
    Kiến trúc bộ nhớ kênh đôi
    Hỗ trợ cho các mô-đun bộ nhớ DIMM 1Rx8 / 2Rx8 không đệm của ECC
    Hỗ trợ cho các mô-đun bộ nhớ DIMM 1Rx8 / 2Rx8 / 1Rx16 không có bộ đệm ECC Un-buffer
    Hỗ trợ mô-đun bộ nhớ Extreme Memory Profile (XMP)
  • Âm thanh
    – Realtek ® ALC1220-VB codec
    * Giắc cắm đầu ra của bảng điều khiển phía sau hỗ trợ âm thanh DSD.
    – Âm thanh độ nét cao
    – 2/4 / 5.1 / 7.1 kênh
    – Hỗ trợ S / PDIF Out
  • LAN: Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
  • Khe mở rộng:
    – 1 x khe cắm PCI Express x16 (PCIEX16), được tích hợp trong CPU:
    Bộ xử lý AMD Ryzen ™ 5000 Series / 3000 Series hỗ trợ chế độ PCIe 4.0 x16
    Bộ xử lý AMD Ryzen ™ 5000 G-Series / 4000 G-Series / 2000 Series hỗ trợ chế độ PCIe 3.0 x16
    Bộ xử lý AMD Ryzen ™ 3000 G-Series / 2000 G-Series hỗ trợ chế độ PCIe 3.0 x8
    * Để có hiệu suất tối ưu, nếu chỉ lắp một card đồ họa PCI Express, hãy đảm bảo lắp nó vào khe PCIEX16.
    – 1 x khe cắm PCI Express x16 (PCIEX4), được tích hợp trong Chipset:
    Hỗ trợ chế độ PCIe 4.0 (Lưu ý) / 3.0 x4
    – 1 x khe cắm PCI Express x16 (PCIEX2), được tích hợp trong Chipset:
    Hỗ trợ chế độ PCIe 4.0 (Lưu ý) / 3.0 x2
    * Khe PCIEX4 chia sẻ băng thông với khe PCIEX2. Khi khe PCIEX2 được điền, khe PCIEX4 sẽ hoạt động ở chế độ lên đến x2.
  • Công nghệ đa đồ họa:
    – Hỗ trợ công nghệ AMD Quad-GPU CrossFire ™ và AMD CrossFire ™ 2 chiều
    (Lưu ý) Chỉ dành cho Bộ xử lý AMD Ryzen ™ 5000 Series / 5000 G-Series / 4000 G-Series / 3000 Series / 2000 Series.
  • Lưu trữ
    – 1 x đầu nối M.2 (M2A_CPU), tích hợp trong CPU, hỗ trợ Socket 3, M key, SSD loại 2260/2280/22110:
    Bộ xử lý AMD Ryzen ™ 5000 Series / 3000 Series hỗ trợ SSD SATA và PCIe 4.0 x4 / x2
    Bộ xử lý AMD Ryzen ™ 5000 G-Series / 4000 G-Series / 3000 G-Series / 2000 Series / 2000 G-Series hỗ trợ SSD SATA và PCIe 3.0 x4 / x2
    – 2 x đầu nối M.2 (M2B_SB / M2C_SB), tích hợp trong Chipset, hỗ trợ Socket 3, phím M, SSD loại 2260/2280/22110:
    Hỗ trợ SSD SATA và PCIe 4.0 (Lưu ý) / 3.0 x4 / x2
    – 6 x đầu nối SATA 6Gb / s, tích hợp trong Chipset:
    Hỗ trợ RAID 0, RAID 1 và RAID 10
  • Cổng I/O nội bộ:
    – 1 x đầu nối nguồn chính ATX 24 chân
    – 1 x đầu nối nguồn ATX 12V 8 chân
    – 1 x đầu cắm quạt CPU
    – 1 x đầu cắm quạt tản nhiệt nước CPU
    – 3 x đầu cắm quạt hệ thống
    – 1 x đầu cắm quạt hệ thống / máy bơm làm mát nước
    – 2 x đầu cắm dải LED có thể định địa chỉ
    – 2 x đầu cắm dải LED RGB
    – 1 x dải LED làm mát CPU / đầu cắm dải LED RGB
    – 3 x đầu nối M.2 Socket 3
    – 6 x đầu nối SATA 6Gb / s
    – 1 x bảng điều khiển phía trước
    – 1 x âm thanh bảng điều khiển phía trước
    – 1 x đầu cắm USB Type-C ® , với hỗ trợ USB 3.2 Gen 2
    – 2 x đầu cắm USB 3.2 Thế hệ 1
    – 2 x đầu cắm USB 2.0 / 1.1
    – 1 x Mô-đun (TPM) (chân 2×6, chỉ dành cho mô-đun GC-TPM2.0_S)
    – 1 x đầu nối thẻ bổ trợ Thunderbolt ™
    – 1 x Clear CMOS jumper
  • Cổng I/O:
    – 4 x cổng USB 2.0 / 1.1
    – 1 x cổng HDMI
    – 4 x cổng USB 3.2 Gen 1
    – 1 x nút Q-Flash Plus
    – 1 x cổng USB Type-C®, với hỗ trợ USB 3.2 Gen 2×2
    – 3 x Cổng USB 3.2 Gen 2 Loại A (màu đỏ)
    – 1 x cổng RJ-45
    – 1 x đầu nối quang S / PDIF Out
    – 5 x giắc cắm âm thanh

Bo Mạch Chủ – Mainboard Gigabyte X570S AORUS ELITE

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte X570S AORUS MASTER

Bo Mạch Chủ – Mainboard Gigabyte X570S AORUS MASTER

  • CPU

    1. AMD Socket AM4, support for: AMD Ryzen™ 5000 Series Processors/ AMD Ryzen™ 4000 G-Series Processors/ AMD Ryzen™ 3000 Series Processors/ AMD Ryzen™ 3000 G-Series Processors/ AMD Ryzen™ 2000 Series Processors/ AMD Ryzen™ 2000 G-Series Processors
    (Please refer "CPU Support List" for more information.)

  • Chipset

    1. AMD X570

  • Memory

    1. AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 4000 G-Series Processors/ AMD Ryzen™ 3000 Series Processors:
      Support for DDR4 3200/2933/2667/2400/2133 MHz memory modules
    2. AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000 Series Processors/ AMD Ryzen™ 2000 G-Series Processors:
      Support for DDR4 2933/2667/2400/2133 MHz memory modules
    3. 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
    4. Dual channel memory architecture
    5. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
    6. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    7. Support for Extreme Memory Profile (XMP) memory modules
    (Please refer "Memory Support List" for more information.)

  • Audio

    1. Realtek® ALC1220-VB audio CODEC
      * The front panel line out jack supports DSD audio.
    2. ESS SABRE9118 DAC chip
    3. Support for DTS:X® Ultra
    4. High Definition Audio
    5. 2/4/5.1/7.1-channel
    6. Support for S/PDIF Out

  • LAN

    1. Intel® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

  • Wireless Communication module

    Intel® Wi-Fi 6E AX210
    1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
    2. BLUETOOTH 5.2
    3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
      * Actual data rate may vary depending on environment and equipment.

  • Expansion Slots

    1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
    1. AMDRyzen™ 5000 Series Processors/AMDRyzen™ 3000 Series Processors support PCIe 4.0 x16 mode
    2. AMDRyzen™ 4000G-SeriesProcessors/AMDRyzen™ 2000 Series Processors support PCIe 3.0 x16 mode
    3. AMDRyzen™ 3000G-SeriesProcessors/AMDRyzen™ 2000 G-Series Processors support PCIe 3.0 x8 mode
    1 x PCI Express x16 slot (PCIEX8), integrated in the CPU:
    1. AMDRyzen™ 5000 Series Processors/AMDRyzen™ 3000 Series Processors support PCIe 4.0 x8 mode
    2. AMDRyzen™ 4000G-SeriesProcessors/AMDRyzen™ 2000 Series Processors support PCIe 3.0 x8 mode
    3. AMDRyzen™ 3000G-SeriesProcessors/AMDRyzen™ 2000 G-Series Processors do not support this slot
      * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
      * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode.
    1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset:
    1. Supporting PCIe 4.0* /3.0 x4 mode
      * For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors only.
      * The PCIEX4 slot shares bandwidth with the M2C_SB connector. The PCIEX4 slot becomes unavailable when a device is installed in the M2C_SB connector.

  • Multi-Graphics Technology

    1. Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies
    For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 3000 Series Processors/AMD Ryzen™ 2000 Series Processors only.

  • Storage Interface

    1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2280/22110 SSDs:
    1. AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors support SATA and PCIe 4.0 x4/x2 SSDs
    2. AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 3000 G-Series Processors/AMDRyzen™ 2000SeriesProcessors/AMDRyzen™ 2000 G-Series Processors support SATA and PCIe 3.0 x4/x2 SSDs
    1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2280/22110 SSDs:
    1. Supporting PCIe 4.0* /3.0 x4/x2 SSDs
      * For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors only.
    2 x M.2 connectors (M2C_SB/M2D_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2280/22110 SSDs:
    1. Supporting SATA and PCIe 4.0* /3.0 x4/x2 SSDs
      * For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors only.
    6 x SATA 6Gb/s connectors, integrated in the Chipset:
    1. Support for RAID 0, RAID 1, and RAID 10
      * Refer to "1-9 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

  • USB

    CPU:
    1. 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
    2. 2 x USB 3.2 Gen 1 ports on the back panel
    Chipset+ASMedia® USB 3.2 Gen 2x2 Controller:
    1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2x2 support
    Chipset:
    1. 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
    2. 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
    3. 4 x USB 3.2 Gen 1 ports, available through the internal USB headers
    Chipset+2 USB 2.0 Hubs:
    1. 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

  • Internal I/O Connectors

    1. 1 x 24-pin ATX main power connector
    2. 2 x 8-pin ATX 12V power connectors
    3. 1 x CPU fan header
    4. 1 x water cooling CPU fan header
    5. 4 x system fan headers
    6. 4 x system fan/water cooling pump headers
    7. 2 x addressable LED strip headers
    8. 2 x RGB LED strip headers
    9. 1 x CPU cooler LED strip/RGB LED strip header
    10. 4 x M.2 Socket 3 connectors
    11. 6 x SATA 6Gb/s connectors
    12. 1 x front panel header
    13. 1 x front panel audio header
    14. 1 x USB Type-C® header, with USB 3.2 Gen 2 support
    15. 2 x USB 3.2 Gen 1 headers
    16. 2 x USB 2.0/1.1 headers
    17. 1 x noise detection header
    18. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
    19. 1 x Thunderbolt™ add-in card connector
    20. 2 x temperature sensor headers
    21. 1 x power button
    22. 1 x reset button
    23. 1 x Clear CMOS jumper
    24. Voltage Measurement Points

  • Back Panel Connectors

    1. 1 x Q-Flash Plus button
    2. 1 x Clear CMOS button
    3. 2 x SMA antenna connectors (2T2R)
    4. 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support
    5. 5 x USB 3.2 Gen 2 Type-A ports (red)
    6. 2 x USB 3.2 Gen 1 ports
    7. 4 x USB 2.0/1.1 ports
    8. 1 x RJ-45 port
    9. 1 x optical S/PDIF Out connector
    10. 5 x audio jacks

  • I/O Controller

    1. iTE® I/O Controller Chip

  • H/W Monitoring

    1. Voltage detection
    2. Temperature detection
    3. Fan speed detection
    4. Water cooling flow rate detection
    5. Overheating warning
    6. Fan fail warning
    7. Fan speed control
      * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
    8. Noise detection

  • BIOS

    1. 1 x 256 Mbit flash
    2. Use of licensed AMI UEFI BIOS
    3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

  • Unique Features

    1. Support for APP Center
      * Available applications in APP Center may vary by motherboard model. Supported functions of each applicationmay also vary depending onmotherboard specifications.
      @BIOS
      EasyTune
      Fast Boot
      Game Boost
      ON/OFF Charge
      RGB Fusion
      Smart Backup
      System Information Viewer
    2. Support for Q-Flash Plus
    3. Support for Q-Flash
    4. Support for Xpress Install

  • Bundled Software

    1. Norton® Internet Security (OEM version)
    2. cFosSpeed

  • Operating System

    1. Support for Windows 10 64-bit

  • Form Factor

    1. ATX Form Factor; 30.5cm x 24.4cm

Bo Mạch Chủ – Mainboard Gigabyte X570S AORUS MASTER

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte X570S GAMING X

Bo Mạch Chủ – Mainboard Gigabyte X570S GAMING X

  • CPU

    1. AMD Socket AM4, support for: AMD Ryzen™ 5000 Series Processors/ AMD Ryzen™ 4000 G-Series Processors/ AMD Ryzen™ 3000 Series Processors/ AMD Ryzen™ 3000 G-Series Processors/ AMD Ryzen™ 2000 Series Processors/ AMD Ryzen™ 2000 G-Series Processors
    (Please refer "CPU Support List" for more information.)

  • Chipset

    1. AMD X570

  • Memory

    1. AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 3000 Series Processors:
      Support for DDR4 3200/2933/2667/2400/2133 MHz memory modules
    2. AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000 Series Processors/AMD Ryzen™ 2000 G-Series Processors:
      Support for DDR4 2933/2667/2400/2133 MHz memory modules
    3. 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
    4. Dual channel memory architecture
    5. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
    6. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    7. Support for Extreme Memory Profile (XMP) memory modules
    (Please refer "Memory Support List" for more information.)

  • Onboard Graphics

    Integrated Graphics Processor:
    1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
      * Support for HDMI 2.1 version, HDCP 2.3, and HDR.
    Maximum shared memory of 16 GB

    (Note) For AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000 G-Series Processors only.

  • Audio

    1. Realtek® Audio CODEC
    2. High Definition Audio
    3. 2/4/5.1/7.1-channel

  • LAN

    1. Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

  • Expansion Slots

    1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
    1. AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors support PCIe 4.0 x16 mode
    2. AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 2000 Series Processors support PCIe 3.0 x16 mode
    3. AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000 G-Series Processors support PCIe 3.0 x8 mode
      * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
    1 x PCI Express x16 slot (PCIEX2), integrated in the Chipset:
    1. Supporting PCIe 4.0(Note)/3.0 x2 mode
      * The PCIEX2 slot shares bandwidth with the SATA3 4, 5 connectors. The SATA3 4, 5 connectors will become unavailable when a device is installed in the PCIEX2 slot.
    2 x PCI Express x1 slots, integrated in the Chipset, supporting PCIe 4.0(Note)/3.0

    (Note) For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors only.

  • Storage Interface

    1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs:
    1. AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors support SATA and PCIe 4.0 x4/x2 SSDs
    2. AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000 Series Processors/AMD Ryzen™ 2000 G-Series Processors support SATA and PCIe 3.0 x4/x2 SSDs
    1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs:
    1. Supporting PCIe 4.0(Note)/3.0 x4/x2 SSDs
    1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs:
    1. Supporting SATA and PCIe 4.0(Note)/3.0 x4/x2 SSDs
    6 x SATA 6Gb/s connectors, integrated in the Chipset:
    1. Support for RAID 0, RAID 1, and RAID 10
    (Note) For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors only.

  • USB

    CPU:
    1. 4 x USB 3.2 Gen 1 ports on the back panel
    Chipset:
    1. 2 x USB Type-C® ports, with USB 3.2 Gen 2 support (1 port on the back panel, 1 port available through the internal USB header)
    2. 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
    3. 2 x USB 3.2 Gen 1 ports available through the internal USB header
    4. 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)

  • Internal I/O Connectors

    1. 1 x 24-pin ATX main power connector
    2. 1 x 8-pin ATX 12V power connector
    3. 1 x CPU fan header
    4. 1 x water cooling CPU fan header
    5. 3 x system fan headers
    6. 1 x system fan/water cooling pump header
    7. 1 x CPU cooler LED strip/RGB LED strip header
    8. 2 x addressable LED strip headers
    9. 2 x RGB LED strip headers
    10. 6 x SATA 6Gb/s connectors
    11. 3 x M.2 Socket 3 connectors
    12. 1 x front panel header
    13. 1 x front panel audio header
    14. 1 x USB Type-C® header, with USB 3.2 Gen 2 support
    15. 1 x USB 3.2 Gen 1 header
    16. 2 x USB 2.0/1.1 headers
    17. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
    18. 1 x Clear CMOS jumper
    ＊All fan headers are subject to support AIO_Pump, Pump and high performance fan with the capability of delivering up to 2A/12V @ 24W.

  • Back Panel Connectors

    1. 2 x USB 2.0/1.1 ports
    2. 1 x PS/2 keyboard/mouse port
    3. 1 x HDMI port
    4. 4 x USB 3.2 Gen 1 ports
    5. 1 x Q-Flash Plus button
    6. 1 x USB 3.2 Gen 2 Type-A port (red)
    7. 1 x USB Type-C® port, with USB 3.2 Gen 2 support
    8. 1 x RJ-45 port
    9. 6 x audio jacks

  • I/O Controller

    1. iTE® I/O Controller Chip

  • H/W Monitoring

    1. Voltage detection
    2. Temperature detection
    3. Fan speed detection
    4. Water cooling flow rate detection
    5. Fan fail warning
    6. Fan speed control
      * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.

  • BIOS

    1. 1 x 256 Mbit flash
    2. Use of licensed AMI UEFI BIOS
    3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

  • Unique Features

    1. Support for APP Center
      * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
      @BIOS
      EasyTune
      Fast Boot
      Game Boost
      ON/OFF Charge
      RGB Fusion
      Smart Backup
      System Information Viewer
    2. Support for Q-Flash Plus
    3. Support for Q-Flash
    4. Support for Xpress Install

  • Bundled Software

    1. Norton® Internet Security (OEM version)
    2. Realtek® 8125 Gaming LAN Bandwidth Control Utility

  • Operating System

    1. Support for Windows 10 64-bit

  • Form Factor

    1. ATX Form Factor; 30.5cm x 24.4cm

Bo Mạch Chủ – Mainboard Gigabyte X570S GAMING X

Liên hệ
Bo Mạch Chủ - Mainboard Gigabyte X570SI AORUS PRO AX

Bo Mạch Chủ – Mainboard Gigabyte X570SI AORUS PRO AX

  • CPU

    1. AMD Socket AM4, support for: AMD Ryzen™ 5000 Series Processors/ AMD Ryzen™ 4000 G-Series Processors/ AMD Ryzen™ 3000 Series Processors/ AMD Ryzen™ 3000 G-Series Processors/ AMD Ryzen™ 2000 Series Processors/ AMD Ryzen™ 2000 G-Series Processors
    (Please refer "CPU Support List" for more information.)

  • Chipset

    1. AMD X570

  • Memory

    1. AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 3000 Series Processors:
      Support for DDR4 3200/2933/2667/2400/2133 MHz memory modules
    2. AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000 Series Processors/AMD Ryzen™ 2000 G-Series Processors:
      Support for DDR4 2933/2667/2400/2133 MHz memory modules
    3. 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
    4. Dual channel memory architecture
    5. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
    6. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
    7. Support for Extreme Memory Profile (XMP) memory modules
    (Please refer "Memory Support List" for more information.)

  • Onboard Graphics

    Integrated Graphics Processor:
    1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
      * Support for HDMI 2.1 version, HDCP 2.3, and HDR.
    Maximum shared memory of 16 GB
    For AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000 G-Series Processors only.

  • Audio

    1. Realtek® ALC1220-VB Audio CODEC
      * The back panel line out jack supports DSD audio.
    2. Support for DTS:X® Ultra
    3. High Definition Audio
    4. 2/4/5.1/7.1-channel
    5. Support for S/PDIF Out

  • LAN

    1. Intel® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

  • Wireless Communication module

    Intel® Wi-Fi 6 AX200
    1. WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz Dual-Band
    2. BLUETOOTH 5.1
    3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
      * Actual data rate may vary depending on environment and equipment.

  • Expansion Slots

    1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
    1. AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors support PCIe 4.0 x16 mode
    2. AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 2000 Series Processors support PCIe 3.0 x16 mode
    3. AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000 G-Series Processors support PCIe 3.0 x8 mode
    1 x PCI Express x16 slot (PCIEX8), integrated in the CPU:
    1. AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors support PCIe 4.0 x8 mode
    2. AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 2000 Series Processors support PCIe 3.0 x8 mode
    3. AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000 G-Series Processors do not support this slot.
      * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
      * The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated, the PCIEX16 slot operates at up to x8 mode.
    1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset:
    1. Supporting PCIe 4.0*/3.0 x4 mode
      * For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors only.

  • Multi-Graphics Technology

    1. Support forAMDQuad-GPU CrossFire™ and 2-WayAMD CrossFire™ technologies
    For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 3000 Series Processors/AMD Ryzen™ 2000 Series Processors only

  • Storage Interface

    1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2280/22110 SSDs:
    1. AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors support SATA and PCIe 4.0 x4/x2 SSDs
    2. AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 2000 Series Processors/AMD Ryzen™ 2000 G-Series Processors support SATA and PCIe 3.0 x4/x2 SSDs
    1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2280/22110 SSDs:
    1. Supporting PCIe 4.0*/3.0 x4/x2 SSDs
      * For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors only.
    1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2280/22110 SSDs:
    1. Supporting SATA and PCIe 4.0*/3.0 x4/x2 SSDs
      * For AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 3000 Series Processors only.
    6 x SATA 6Gb/s connectors, integrated in the Chipset:
    1. Support for RAID 0, RAID 1, and RAID 10
      * Refer to "1-8 Internal Connectors," for the installation notices for the M.2 and SATA connectors.

  • USB

    CPU:
    1. 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
    2. 3 x USB 3.2 Gen 1 ports on the back panel
    Chipset+ASMedia® USB 3.2 Gen 2x2 Controller:
    1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2x2 support
    Chipset:
    1. 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
    2. 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
    3. 4 x USB 3.2 Gen 1 ports available through the internal USB headers
    Chipset+2 USB 2.0 Hubs:
    1. 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

  • Internal I/O Connectors

    1. 1 x 24-pin ATX main power connector
    2. 1 x 8-pin ATX 12V power connector
    3. 1 x 4-pin ATX 12V power connector
    4. 1 x CPU fan header
    5. 1 x water cooling CPU fan header
    6. 4 x system fan headers
    7. 2 x system fan/water cooling pump headers
    8. 2 x addressable LED strip headers
    9. 2 x RGB LED strip headers
    10. 1 x CPU cooler LED strip/RGB LED strip header
    11. 3 x M.2 Socket 3 connectors
    12. 6 x SATA 6Gb/s connectors
    13. 1 x front panel header
    14. 1 x front panel audio header
    15. 1 x USB Type-C® header, with USB 3.2 Gen 2 support
    16. 2 x USB 3.2 Gen 1 headers
    17. 2 x USB 2.0/1.1 headers
    18. 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
    19. 1 x Thunderbolt™ add-in card connector
    20. 1 x Clear CMOS jumper
    21. 2 x temperature sensor headers

  • Back Panel Connectors

    1. 4 x USB 2.0/1.1 ports
    2. 2 x SMA antenna connectors (2T2R)
    3. 1 x HDMI port
    4. 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support
    5. 4 x USB 3.2 Gen 2 Type-A ports (red)
    6. 3 x USB 3.2 Gen 1 ports
    7. 1 x RJ-45 port
    8. 1 x optical S/PDIF Out connector
    9. 5 x audio jacks

  • I/O Controller

    1. iTE® I/O Controller Chip

  • H/W Monitoring

    1. Voltage detection
    2. Temperature detection
    3. Fan speed detection
    4. Water cooling flow rate detection
    5. Overheating warning
    6. Fan fail warning
    7. Fan speed control
      * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.

  • BIOS

    1. 1 x 256 Mbit flash
    2. Use of licensed AMI UEFI BIOS
    3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

  • Unique Features

    1. Support for APP Center
      * Available applications in APP Center may vary by motherboard model. Supported functions of each applicationmay also vary depending onmotherboard specifications.
      @BIOS
      EasyTune
      Fast Boot
      Game Boost
      ON/OFF Charge
      RGB Fusion
      Smart Backup
      System Information Viewer
    2. Support for Q-Flash Plus
    3. Support for Q-Flash
    4. Support for Xpress Install

  • Bundled Software

    1. Norton® Internet Security (OEM version)
    2. cFosSpeed

  • Operating System

    1. Support for Windows 10 64-bit

  • Form Factor

    1. ATX Form Factor; 30.5cm x 24.4cm

Bo Mạch Chủ – Mainboard Gigabyte X570SI AORUS PRO AX

Liên hệ
